MAX3098EBCSE / The MAX3098EBCSE+ is a robust <strong>full-duplex RS-485/RS-422 transceiver</strong> from <strong>Analog Devices (Maxim Integrated)</strong>, designed for reliable high-speed differential data communication in industrial, automation, instrumentation, and networking applications. It combines low-power operation, high ESD immunity, and excellent noise tolerance to ensure dependable performance in electrically harsh environments. <br><br>This device supports <strong>full-duplex communication</strong>, allowing simultaneous data transmission and reception over differential bus networks. Its balanced driver and receiver architecture provides excellent signal integrity for long-distance communication links and multidrop network topologies. <br><br>The MAX3098EBCSE+ incorporates advanced protection features including <strong>±15kV ESD protection</strong> on communication pins, helping safeguard connected equipment from electrostatic discharge events and improving system reliability. The transceiver is optimized for operation in industrial environments where transient disturbances are common. <br><br>The device supports data rates up to <strong>10Mbps</strong>, making it suitable for high-speed serial communication systems requiring reliable differential signaling. Its fail-safe receiver design ensures a defined logic state when bus inputs are open, shorted, or idle, reducing communication errors and simplifying system implementation. <br><br>Operating from a single <strong>5V supply</strong>, the MAX3098EBCSE+ delivers low power consumption while maintaining excellent communication performance. The transceiver also features low-current shutdown functionality for power-sensitive applications. <br><br>Packaged in a compact <strong>16-pin narrow SOIC surface-mount package</strong>, the device enables efficient PCB layouts and supports automated assembly processes for high-volume manufacturing. <br><br>The <strong>MAX3098EBCSE+</strong> is widely used in <strong>industrial automation systems, PLCs, building control networks, process control equipment, data acquisition systems, security systems, factory communication networks, instrumentation platforms, and RS-485/RS-422 communication interfaces</strong>, where reliable high-speed differential communication and strong ESD protection are required.
MAX3098EBCSE

Description: The MAX3098EBCSE+ is a robust full-duplex RS-485/RS-422 transceiver from ...
Package: TUBE | MOQ: 1000 | MPQ: 50

HMC452ST89ETR / The HMC452ST89ETR is a high-linearity <strong>1W MMIC RF power amplifier</strong> developed by <strong>Analog Devices</strong>, utilizing advanced <strong>InGaP HBT technology</strong> to deliver excellent gain, output power, and efficiency across a wide frequency range. It is designed for wireless infrastructure, fixed wireless access, RF communication systems, and broadband transmitter applications requiring reliable medium-power amplification. <br><br>This device operates over a broad frequency range of <strong>400MHz to 2.2GHz</strong>, making it suitable for multiple wireless standards and RF system architectures. The amplifier delivers gain levels of up to <strong>21dB</strong> at lower frequencies while maintaining strong performance throughout its operating band. <br><br>The HMC452ST89ETR provides a typical <strong>1W output power capability</strong> with output power at 1dB compression reaching approximately <strong>31.5dBm</strong>. Its high linearity performance enables output IP3 levels up to <strong>+49dBm</strong>, supporting demanding communication systems that require low signal distortion and high dynamic range. <br><br>Operating from a single <strong>+5V supply</strong>, the amplifier requires only a minimal number of external components, simplifying RF design and reducing overall system complexity. The device also offers excellent power-added efficiency, making it suitable for power-sensitive wireless applications. <br><br>The HMC452ST89ETR features a compact <strong>SOT-89 surface-mount package</strong>, allowing efficient PCB utilization while maintaining strong thermal and RF performance. Its integrated design helps reduce component count and accelerate development of broadband RF subsystems. <br><br>The <strong>HMC452ST89ETR</strong> is widely used in <strong>GSM, GPRS, EDGE, CDMA, W-CDMA, fixed wireless equipment, wireless infrastructure, CATV systems, cable modems, RF transmitters, communication repeaters, and broadband RF amplification applications</strong>, where high output power, linearity, and wideband operation are essential.
HMC452ST89ETR

Description: The HMC452ST89ETR is a high-linearity 1W MMIC RF power amplifier develope ...
Package: T&R | MOQ: 500 | MPQ: 500

ADR3412ARJZ-R7 / The ADR3412ARJZ-R7 is a high-performance <strong>1.2V precision voltage reference</strong> from <strong>Analog Devices</strong>, engineered to deliver exceptional accuracy, low noise, and long-term stability in demanding analog and mixed-signal applications. Its precision architecture makes it an ideal reference source for measurement, instrumentation, and data conversion systems. <br><br>This device provides a highly accurate <strong>1.2V output voltage</strong> with excellent initial accuracy and low temperature coefficient, ensuring stable operation across a wide range of environmental conditions. The precise output helps maximize the performance of high-resolution analog circuits and precision sensing applications. <br><br>The ADR3412ARJZ-R7 features <strong>low output noise, excellent line regulation, and high power supply rejection</strong>, making it well suited for use with precision ADCs, DACs, operational amplifiers, and sensor interface circuits. These characteristics help improve signal integrity and overall system accuracy. <br><br>Operating from a broad supply voltage range, the device combines high precision with <strong>low quiescent current consumption</strong>, enabling its use in both portable and line-powered equipment. Its efficient design supports applications where power efficiency and measurement accuracy are equally important. <br><br>The voltage reference incorporates advanced trimming and compensation techniques that provide <strong>excellent long-term stability and low drift performance</strong>, reducing calibration requirements and improving reliability throughout the product lifecycle. <br><br>Packaged in a compact <strong>6-pin SOT-23 surface-mount package</strong>, the ADR3412ARJZ-R7 allows designers to implement precision analog functions in space-constrained PCB layouts without sacrificing performance. <br><br>The <strong>ADR3412ARJZ-R7</strong> is widely used in <strong>data acquisition systems, industrial instrumentation, precision measurement equipment, medical electronics, process control systems, sensor conditioning modules, calibration instruments, and high-resolution ADC and DAC applications</strong>, where a stable and accurate reference voltage is critical for system performance.
ADR3412ARJZ-R7

Description: The ADR3412ARJZ-R7 is a high-performance 1.2V precision voltage reference ...
Package: T&R | MOQ: 3000 | MPQ: 3000

ADR3425ARJZ-R7 / The ADR3425ARJZ-R7 is a high-accuracy <strong>2.5V precision voltage reference</strong> from <strong>Analog Devices</strong>, designed to provide a stable and low-noise reference voltage for precision measurement, data acquisition, instrumentation, and industrial control applications. Its advanced design delivers excellent long-term stability and accuracy, making it suitable for high-performance analog systems. <br><br>This device provides a precise <strong>2.5V output voltage</strong> with excellent initial accuracy and very low temperature drift, helping maintain measurement integrity across varying environmental conditions. The reference is optimized for applications that require consistent voltage performance over time and temperature. <br><br>The ADR3425ARJZ-R7 features <strong>low output noise and high power supply rejection</strong>, making it ideal for use with high-resolution ADCs, DACs, sensor interfaces, and precision signal conditioning circuits. Its low-noise characteristics help improve overall system accuracy and signal quality. <br><br>The device operates from a wide input voltage range and incorporates internal circuitry that ensures reliable startup and stable operation. Its low quiescent current consumption makes it suitable for both portable and line-powered equipment. <br><br>Designed for demanding precision applications, the ADR3425ARJZ-R7 offers <strong>excellent line regulation, load regulation, and long-term stability</strong>, enabling consistent performance in calibration systems, industrial instrumentation, medical devices, and automated test equipment. <br><br>The component is supplied in a compact <strong>6-pin SOT-23 surface-mount package</strong>, allowing implementation in space-constrained PCB designs while maintaining high analog performance. <br><br>The <strong>ADR3425ARJZ-R7</strong> is widely used in <strong>data acquisition systems, industrial automation equipment, precision instrumentation, medical electronics, process control systems, sensor measurement platforms, high-resolution ADC and DAC circuits, and calibration equipment</strong>, where a stable and accurate reference voltage is critical for system performance.
ADR3425ARJZ-R7

Description: The ADR3425ARJZ-R7 is a high-accuracy 2.5V precision voltage reference fr ...
Package: T&R | MOQ: 3000 | MPQ: 3000

ADM1278-1ACPZ-RL / The ADM1278-1ACPZ-RL is an advanced <strong>hot swap controller and digital power monitoring IC</strong> from <strong>Analog Devices</strong>, designed to provide safe board insertion, inrush current control, and comprehensive power monitoring in high-availability electronic systems. It combines precision measurement capabilities with robust protection functions, making it ideal for telecommunications, networking, industrial, and server applications. <br><br>This device supports operating voltages up to <strong>80V</strong> and enables controlled startup of power rails by regulating inrush current during live insertion events. Its integrated hot swap functionality helps protect connectors, backplanes, and downstream circuitry from damaging current surges. <br><br>The ADM1278-1ACPZ-RL incorporates high-accuracy monitoring of <strong>voltage, current, power, and accumulated energy</strong>, allowing system designers to implement detailed power management and diagnostic functions. Measured data can be accessed through a <strong>PMBus-compatible digital interface</strong>, simplifying system monitoring and remote management. <br><br>Integrated protection features include <strong>overcurrent protection, undervoltage detection, overvoltage monitoring, power limiting, fault management, and programmable shutdown control</strong>. These capabilities improve system reliability and help prevent damage during abnormal operating conditions. <br><br>The device supports external N-channel MOSFET control and offers programmable fault response settings, allowing flexible implementation across a wide range of power architectures. Its precision telemetry functions make it particularly suitable for intelligent power distribution and energy-aware system designs. <br><br>Packaged in a compact <strong>32-pin LFCSP package</strong>, the ADM1278-1ACPZ-RL provides a space-efficient solution for high-density circuit boards while maintaining excellent electrical and thermal performance. <br><br>The <strong>ADM1278-1ACPZ-RL</strong> is widely used in <strong>telecommunications equipment, enterprise servers, storage systems, industrial automation platforms, networking infrastructure, intelligent power distribution units, and high-reliability embedded systems</strong>, where controlled power sequencing, fault protection, and detailed power monitoring are essential.
ADM1278-1ACPZ-RL

Description: The ADM1278-1ACPZ-RL is an advanced hot swap controller and digital power monitori ...
Package: T&R | MOQ: 1500 | MPQ: 1500

ADP5054ACPZ-R7 / The ADP5054ACPZ-R7 is a highly integrated <strong>quad buck regulator power management IC (PMIC)</strong> from <strong>Analog Devices</strong>, designed to provide efficient multi-rail power conversion for FPGA, processor, networking, industrial, and embedded computing applications. By integrating four high-performance switching regulators into a single package, it helps reduce board space and simplify power supply design. <br><br>This device supports an input voltage range of <strong>4.5V to 15.5V</strong>, allowing direct connection to a wide variety of power sources without requiring additional preregulators. The integrated architecture enables the generation of multiple regulated voltage rails from a single supply source. <br><br>Channels 1 and 2 support programmable output current configurations of up to <strong>6A per channel</strong>, while Channels 3 and 4 provide up to <strong>2.5A per channel</strong>. Parallel operation is also supported, allowing Channels 1 and 2 to deliver up to <strong>12A</strong> combined output current and Channels 3 and 4 to provide up to <strong>5A</strong> combined output current. <br><br>The ADP5054ACPZ-R7 offers a programmable switching frequency from <strong>250kHz to 2MHz</strong> and supports synchronization to an external clock source, enabling optimization of efficiency, EMI performance, and overall power system design. Additional features include <strong>power-good monitoring, precision enable inputs, soft-start control, overcurrent protection, undervoltage lockout, and thermal shutdown protection</strong>. <br><br>Its low-noise architecture and high integration level make it particularly suitable for powering sensitive digital processors, FPGAs, communication modules, and high-performance embedded systems. <br><br>Packaged in a compact <strong>48-pin LFCSP surface-mount package</strong>, the ADP5054ACPZ-R7 enables high-density PCB layouts while maintaining excellent thermal and electrical performance. <br><br>The <strong>ADP5054ACPZ-R7</strong> is widely used in <strong>FPGA power supplies, processor power management, industrial automation equipment, networking hardware, wireless infrastructure, security systems, medical electronics, and embedded computing platforms</strong>, where efficient multi-output power conversion and compact system design are essential.
ADP5054ACPZ-R7

Description: The ADP5054ACPZ-R7 is a highly integrated quad buck regulator power management IC ...
Package: T&R | MOQ: 750 | MPQ: 750

MIMXRT1061DVL6B / The MIMXRT1061DVL6B is a high-performance <strong>i.MX RT crossover microcontroller</strong> from <strong>NXP Semiconductors</strong>, combining the real-time responsiveness of a microcontroller with the processing capabilities typically associated with application processors. Built around the powerful <strong>ARM Cortex-M7 core</strong>, it delivers exceptional performance for advanced embedded systems, industrial automation, human-machine interfaces, and intelligent edge devices. <br><br>This device operates at frequencies up to <strong>600MHz</strong>, providing substantial computational power for complex control algorithms, digital signal processing, graphics handling, and communication-intensive applications. The MCU integrates <strong>1MB of on-chip Flash memory</strong> and <strong>512KB of SRAM</strong>, enabling efficient execution of sophisticated embedded software platforms. <br><br>The MIMXRT1061DVL6B includes a rich set of communication interfaces such as <strong>Ethernet, USB 2.0 OTG, CAN, SPI, I²C, UART, SDIO, and GPIO peripherals</strong>, allowing seamless connectivity across industrial, consumer, and IoT applications. Its advanced peripheral integration reduces system complexity while improving overall design flexibility. <br><br>The device incorporates high-performance timers, PWM modules, ADCs, watchdog functions, and external memory interfaces that support SDRAM, NOR Flash, NAND Flash, and serial memory expansion. These features make it suitable for applications requiring fast data processing and extensive peripheral control. <br><br>Designed for demanding embedded environments, the MIMXRT1061DVL6B supports industrial temperature operation and advanced power management capabilities. Its crossover architecture enables deterministic real-time behavior while maintaining application-level processing performance. <br><br>Packaged in a compact <strong>144-pin LQFP package</strong>, the device offers a high pin count and extensive peripheral access while simplifying PCB design and assembly processes. <br><br>The <strong>MIMXRT1061DVL6B</strong> is widely used in <strong>industrial automation systems, motor control platforms, robotics, smart gateways, HMI devices, medical equipment, IoT edge controllers, consumer electronics, audio processing systems, and high-performance embedded applications</strong>, where real-time responsiveness and powerful processing capabilities are required.
MIMXRT1061DVL6B

Description: The MIMXRT1061DVL6B is a high-performance i.MX RT crossover microcontroller ...
Package: TRAY | MOQ: 240 | MPQ: 60

MCIMX6Y2CVM08AB / The MCIMX6Y2CVM08AB is a highly integrated <strong>i.MX 6ULL applications processor</strong> from <strong>NXP Semiconductors</strong>, built around a high-efficiency <strong>ARM Cortex-A7 core</strong> operating at speeds up to <strong>800MHz</strong>. It is designed for embedded Linux systems, industrial control platforms, smart gateways, human-machine interfaces, and connected IoT devices that require low power consumption and reliable processing performance. <br><br>This processor integrates a rich set of peripheral interfaces, including <strong>Ethernet, USB, UART, SPI, I²C, CAN, SDIO, GPIO, and PWM controllers</strong>, enabling flexible connectivity for industrial automation, networking, and intelligent embedded applications. Its optimized architecture allows developers to build cost-effective systems while maintaining strong processing capabilities. <br><br>The MCIMX6Y2CVM08AB includes support for <strong>external DDR memory interfaces</strong> and offers extensive multimedia and system integration features that simplify hardware design. The processor is optimized for embedded operating systems such as Linux and real-time software platforms used in industrial and commercial products. <br><br>Designed for long-term reliability, the device operates across an extended temperature range suitable for industrial environments. Advanced power management functions help reduce energy consumption while maintaining system responsiveness for always-on and connected applications. <br><br>The processor incorporates multiple security and system management features that support secure boot, device authentication, and robust embedded system operation. These capabilities make it suitable for applications requiring dependable connectivity and long operational lifetimes. <br><br>Packaged in a compact <strong>289-ball MAPBGA package</strong>, the MCIMX6Y2CVM08AB enables high-density PCB designs while providing excellent electrical performance and signal integrity. <br><br>The <strong>MCIMX6Y2CVM08AB</strong> is widely used in <strong>industrial automation systems, HMI panels, IoT gateways, smart home controllers, medical equipment, POS terminals, networking devices, embedded Linux computers, and intelligent edge processing platforms</strong>, where low power consumption, connectivity, and reliable embedded processing are essential.
MCIMX6Y2CVM08AB

Description: The MCIMX6Y2CVM08AB is a highly integrated i.MX 6ULL applications processor ...
Package: TRAY | MOQ: 480 | MPQ: 480

FS32K146HFT0VLLT / The FS32K146HFT0VLLT is a highly integrated <strong>32-bit automotive microcontroller</strong> from <strong>NXP Semiconductors</strong>, built around the powerful <strong>ARM Cortex-M4F processor core</strong> with floating-point unit support. Designed for automotive and industrial embedded applications, it delivers an optimal balance of processing capability, communication interfaces, and real-time control functionality. <br><br>The device operates at clock frequencies up to <strong>112MHz</strong> and integrates <strong>512KB of embedded Flash memory</strong> along with <strong>64KB of SRAM</strong>, providing sufficient memory resources for complex control algorithms, communication stacks, and automotive software platforms. <br><br>The FS32K146HFT0VLLT features an extensive set of communication peripherals, including <strong>CAN FD, FlexCAN, LIN, SPI, I²C, and UART interfaces</strong>, enabling efficient integration into vehicle networks, industrial automation systems, and intelligent control platforms. <br><br>Its advanced analog subsystem includes <strong>12-bit ADCs, timers, PWM modules, watchdog functions, and system monitoring capabilities</strong>, making the device suitable for motor control, sensor processing, battery management, and power conversion applications. The integrated floating-point unit accelerates mathematical computations and digital control tasks. <br><br>Developed for demanding automotive environments, the microcontroller supports <strong>AEC-Q100 automotive qualification</strong> and incorporates features that assist in the implementation of functional safety architectures. Multiple low-power operating modes help reduce energy consumption while maintaining system responsiveness. <br><br>Housed in a compact <strong>100-pin LQFP package</strong>, the FS32K146HFT0VLLT offers a high level of integration while simplifying PCB design and manufacturing processes. <br><br>The <strong>FS32K146HFT0VLLT</strong> is widely used in <strong>body control modules, automotive gateways, electric vehicle subsystems, motor drives, battery management systems, industrial automation equipment, smart sensors, and embedded control applications</strong>, where reliable real-time performance and advanced communication capabilities are essential.
FS32K146HFT0VLLT

Description: The FS32K146HFT0VLLT is a highly integrated 32-bit automotive microcontroller ...
Package: TRAY | MOQ: 180 | MPQ: 90

FS32K146HAT0MLLT / The FS32K146HAT0MLLT is a high-performance <strong>32-bit automotive-grade microcontroller</strong> from <strong>NXP Semiconductors</strong>, based on the <strong>ARM Cortex-M4F core</strong> with integrated floating-point unit capabilities. Designed for advanced automotive and industrial embedded systems, it combines processing performance, communication flexibility, and functional safety support within a highly integrated platform. <br><br>The device operates at frequencies up to <strong>112MHz</strong> and integrates <strong>1MB of embedded Flash memory</strong> together with <strong>128KB of SRAM</strong>, providing ample resources for complex real-time control applications, communication gateways, body electronics, and motor control systems. <br><br>The FS32K146HAT0MLLT incorporates a rich set of communication peripherals, including <strong>CAN FD, FlexCAN, LIN, SPI, I²C, UART, and Ethernet-ready connectivity options</strong>, enabling seamless integration into modern automotive network architectures and industrial control systems. <br><br>Advanced analog functionality includes <strong>12-bit ADCs, timers, PWM modules, watchdog circuits, and system monitoring features</strong>, making the device suitable for precision sensing, power management, and control applications. The integrated floating-point unit further enhances computational efficiency for digital control and signal processing tasks. <br><br>Built to meet demanding automotive requirements, the microcontroller supports <strong>AEC-Q100 qualification</strong> and includes hardware mechanisms that assist with functional safety implementation. Its low-power operating modes help optimize energy consumption in battery-powered and always-on vehicle subsystems. <br><br>The device is supplied in a compact <strong>100-pin LQFP package</strong>, offering a balance between I/O capability and PCB space efficiency while supporting high-volume manufacturing environments. <br><br>The <strong>FS32K146HAT0MLLT</strong> is widely used in <strong>automotive body control modules, gateway controllers, battery management systems, motor control units, industrial automation equipment, electric vehicle subsystems, smart sensors, and embedded control platforms</strong>, where reliable real-time processing and robust communication capabilities are required.
FS32K146HAT0MLLT

Description: The FS32K146HAT0MLLT is a high-performance 32-bit automotive-grade microcontroller ...
Package: TRAY | MOQ: 180 | MPQ: 90

UT2304G-AE3-R-VB / The UT2304G-AE3-R-VB is a compact <strong>N-channel enhancement mode power MOSFET</strong> manufactured by <strong>VBsemi</strong>, designed for efficient low-voltage switching and power management applications. Its advanced trench MOSFET structure provides low conduction losses, fast switching performance, and reliable operation in space-constrained electronic systems. <br><br>This device features a <strong>20V drain-to-source voltage rating</strong> and supports continuous drain currents up to <strong>6A</strong>, making it suitable for battery-powered products, portable electronics, power distribution circuits, and embedded control applications. The low <strong>RDS(on)</strong> characteristic helps improve efficiency while minimizing heat generation during operation. <br><br>The UT2304G-AE3-R-VB is optimized for <strong>low gate drive voltage operation</strong>, enabling direct control from microcontrollers, logic ICs, and modern low-voltage digital systems. Its low gate charge also contributes to reduced switching losses and improved performance in high-frequency designs. <br><br>The device offers excellent switching characteristics for applications such as <strong>load switching, PWM control, DC-DC converters, battery protection circuits, LED drivers, and power management modules</strong>. The integrated body diode further enhances flexibility in power conversion and switching topologies. <br><br>Designed for reliable operation, the UT2304G-AE3-R-VB supports an extended operating temperature range and delivers stable electrical performance across a variety of industrial and consumer environments. <br><br>Packaged in a miniature <strong>SOT-23 surface-mount package</strong>, the device enables high-density PCB layouts while maintaining excellent electrical characteristics and manufacturing compatibility. <br><br>The <strong>UT2304G-AE3-R-VB</strong> is widely used in <strong>portable electronics, battery-powered devices, DC-DC converters, power management circuits, embedded systems, industrial controllers, consumer products, and general-purpose switching applications</strong>, where compact size, low power loss, and dependable performance are required.
UT2304G-AE3-R-VB

Description: The UT2304G-AE3-R-VB is a compact N-channel enhancement mode power MOSFET ...
Package: T&R | MOQ: 3000 | MPQ: 3000

UT2304G-AE3-R / The UT2304G-AE3-R is a compact <strong>N-channel enhancement mode power MOSFET</strong> from <strong>Unisonic Technologies (UTC)</strong>, designed for efficient low-voltage power switching and load management applications. Utilizing advanced trench MOSFET technology, it delivers low on-resistance, fast switching performance, and excellent efficiency in space-constrained electronic designs. <br><br>This device features a <strong>20V drain-to-source voltage rating</strong> and supports continuous drain currents up to <strong>6A</strong>, making it suitable for battery-powered products, power distribution circuits, and portable electronic equipment. Its low <strong>RDS(on)</strong> characteristic helps minimize conduction losses and improve overall power efficiency. <br><br>The UT2304G-AE3-R is optimized for operation with <strong>low gate drive voltages</strong>, allowing direct interface with modern microcontrollers, logic circuits, and embedded control systems. The low gate charge design also contributes to reduced switching losses in high-frequency applications. <br><br>Its fast switching characteristics and robust electrical performance make it well suited for <strong>DC-DC converters, PWM control circuits, load switches, battery protection systems, and power management modules</strong>. The integrated body diode further enhances its usefulness in switching and power conversion topologies. <br><br>The device operates across a wide temperature range of <strong>-55°C to +150°C</strong>, providing reliable performance in industrial and consumer electronic environments. <br><br>Packaged in a miniature <strong>SOT-23 surface-mount package</strong>, the UT2304G-AE3-R enables high-density PCB layouts while maintaining excellent electrical and thermal performance. <br><br>The <strong>UT2304G-AE3-R</strong> is widely used in <strong>portable electronics, battery-powered devices, power management circuits, DC-DC converters, LED drivers, embedded control systems, industrial electronics, and general-purpose switching applications</strong>, where compact size, low power loss, and reliable operation are essential.
UT2304G-AE3-R

Description: The UT2304G-AE3-R is a compact N-channel enhancement mode power MOSFET fr ...
Package: T&R | MOQ: 3000 | MPQ: 3000

IXTP90N055T2 / The IXTP90N055T2 is a high-performance <strong>N-channel TrenchT2 power MOSFET</strong> from <strong>Littelfuse (IXYS)</strong>, engineered for efficient power switching and high-current control applications. Better version of IRLZ44N MOSfet. Its advanced trench technology delivers low conduction losses, fast switching performance, and excellent thermal characteristics, making it suitable for demanding industrial and power conversion systems. <br><br>This device features a <strong>55V drain-to-source voltage rating</strong> and supports continuous drain currents up to <strong>90A</strong>, enabling reliable operation in high-power electronic designs. The MOSFET offers an ultra-low <strong>RDS(on) of 8.4mΩ maximum</strong>, significantly reducing power dissipation and improving overall system efficiency. <br><br>The IXTP90N055T2 incorporates an <strong>avalanche-rated rugged structure</strong> that provides enhanced reliability under transient and inductive load conditions. Its optimized switching characteristics and low gate charge contribute to improved performance in high-frequency power applications. <br><br>The device supports a maximum <strong>power dissipation of 150W</strong> and operates across an extended junction temperature range of <strong>-55°C to +175°C</strong>, ensuring stable operation in harsh industrial environments. The integrated body diode features fast recovery characteristics, making the MOSFET suitable for synchronous rectification and power conversion topologies. <br><br>Packaged in the industry-standard <strong>TO-220AB through-hole package</strong>, the IXTP90N055T2 provides excellent thermal performance and simplifies heatsink attachment for high-power designs. <br><br>The <strong>IXTP90N055T2</strong> is widely used in <strong>DC-DC converters, motor control systems, battery chargers, power supplies, synchronous rectifiers, industrial automation equipment, renewable energy systems, and high-current switching applications</strong>, where low on-resistance and reliable power handling are critical.
IXTP90N055T2

Description: The IXTP90N055T2 is a high-performance N-channel TrenchT2 power MOSFET fr ...
Package: TUBE | MOQ: 1000 | MPQ: 50

ADIS16505-2BMLZ / The ADIS16505-2BMLZ is a high-precision <strong>6 degrees of freedom MEMS inertial measurement unit (IMU)</strong> developed by <strong>Analog Devices</strong>, integrating a triaxial gyroscope and a triaxial accelerometer within a compact industrial-grade module. It is optimized for applications requiring accurate motion sensing, orientation measurement, stabilization, and navigation performance. <br><br>This device combines a <strong>±500°/s gyroscope dynamic range</strong> with a <strong>±8g accelerometer measurement range</strong>, enabling precise detection of angular velocity and linear acceleration in demanding motion-control systems. The integrated signal conditioning architecture helps deliver stable and repeatable sensor outputs across a broad range of operating conditions. <br><br>The ADIS16505-2BMLZ is supplied with extensive <strong>factory calibration for sensitivity, bias, alignment, linear acceleration effects, and point-of-percussion compensation</strong>, reducing development effort and improving system-level accuracy. This calibration approach minimizes integration complexity compared with discrete sensor implementations. <br><br>Communication is provided through a <strong>SPI-compatible digital interface</strong>, allowing efficient connectivity with microcontrollers, embedded processors, DSPs, and FPGA-based control systems. Additional features include programmable operation modes, synchronization capabilities, diagnostic functions, and built-in self-test support for enhanced system reliability. <br><br>The module operates from a <strong>3.0V to 3.6V supply voltage</strong> and supports an industrial operating temperature range of <strong>-40°C to +105°C</strong>. Its rugged construction offers excellent resistance to mechanical shock and vibration, making it suitable for harsh environments. <br><br>Packaged in a compact <strong>100-ball BGA module measuring approximately 15mm × 15mm</strong>, the ADIS16505-2BMLZ provides a space-efficient solution for advanced motion sensing applications. <br><br>The <strong>ADIS16505-2BMLZ</strong> is widely used in <strong>navigation systems, robotics, industrial automation, autonomous vehicles, unmanned platforms, stabilization equipment, smart agriculture machinery, instrumentation systems, and virtual or augmented reality applications</strong>, where highly accurate inertial measurement data is required.
ADIS16505-2BMLZ

Description: The ADIS16505-2BMLZ is a high-precision 6 degrees of freedom MEMS inertial measure ...
Package: TRAY | MOQ: 1 | MPQ: 1

IRF4905PBF / The IRF4905PBF is a high-current <strong>P-channel HEXFET power MOSFET</strong> from <strong>Infineon Technologies</strong>, engineered for efficient power switching and load management applications. Its combination of high current capability, low on-resistance, and rugged construction makes it suitable for a wide range of industrial, automotive, and power conversion systems. <br><br>This device features a <strong>drain-to-source voltage rating of -55V</strong> and supports continuous drain currents up to <strong>-74A</strong>, allowing it to handle demanding power control applications with excellent efficiency. The MOSFET utilizes advanced process technology to achieve an extremely low <strong>RDS(on) of 20mΩ maximum</strong>, reducing conduction losses and improving thermal performance. <br><br>The IRF4905PBF offers <strong>fast switching characteristics</strong> and a fully avalanche-rated design, enabling reliable operation in circuits exposed to inductive loads and transient conditions. Its robust electrical performance makes it ideal for motor control, battery-powered equipment, DC-DC converters, and high-side switching applications. <br><br>The device supports a maximum <strong>gate-to-source voltage of ±20V</strong> and operates across an extended junction temperature range of up to <strong>+175°C</strong>, ensuring stable performance in harsh operating environments. <br><br>Packaged in the industry-standard <strong>TO-220AB through-hole package</strong>, the IRF4905PBF provides excellent thermal dissipation and simplifies integration into power electronics designs requiring efficient heat management. <br><br>The <strong>IRF4905PBF</strong> is widely used in <strong>motor drives, battery management systems, power supplies, automotive electronics, inverter circuits, DC power distribution systems, and industrial power control equipment</strong>, where high-current switching performance and reliability are essential.
IRF4905PBF

Description: The IRF4905PBF is a high-current P-channel HEXFET power MOSFET from ...
Package: TUBE | MOQ: 500 | MPQ: 50

P4SMAJ5.0A_R1_00001 / The P4SMAJ5.0A_R1_00001 is a robust <strong>400W transient voltage suppressor (TVS) diode</strong> manufactured by <strong>PANJIT</strong>, designed to protect sensitive electronic circuits from voltage spikes, ESD events, and transient surge conditions. Its fast response characteristics make it suitable for a wide range of industrial, consumer, and communication equipment. <br><br>This device features a <strong>5V reverse stand-off voltage</strong> and a <strong>6.4V to 7.0V breakdown voltage range</strong>, providing effective overvoltage protection for low-voltage power rails and signal lines. During transient events, it limits the voltage to a maximum <strong>9.2V clamping voltage</strong>, helping prevent damage to downstream components. <br><br>The P4SMAJ5.0A_R1_00001 supports a <strong>peak pulse power dissipation of 400W (10/1000µs waveform)</strong> and can handle surge currents up to <strong>43.5A</strong>, making it suitable for applications exposed to electrical disturbances and inductive switching transients. <br><br>Built as a <strong>unidirectional TVS diode</strong>, the device offers low leakage current and high reliability while maintaining excellent protection performance. Its glass-passivated junction structure enhances long-term stability and operational durability. <br><br>The component is supplied in a compact <strong>DO-214AC (SMA) surface-mount package</strong>, enabling efficient PCB layout and automated assembly processes. It operates across an extended temperature range of <strong>-55°C to +150°C</strong>, supporting demanding industrial and automotive-adjacent environments. <br><br>The <strong>P4SMAJ5.0A_R1_00001</strong> is widely used in <strong>power supplies, industrial controllers, communication interfaces, embedded systems, consumer electronics, networking equipment, and general-purpose circuit protection applications</strong>, where reliable transient voltage suppression is essential.
P4SMAJ5.0A_R1_00001

Description: The P4SMAJ5.0A_R1_00001 is a robust 400W transient voltage suppressor (TVS) diode ...
Package: T&R | MOQ: 1800 | MPQ: 1800

ADIS16507-2BMLZ / The ADIS16507-2BMLZ is a precision <strong>6 degrees of freedom MEMS inertial measurement unit (IMU)</strong> from <strong>Analog Devices</strong>, integrating a triaxial gyroscope and a triaxial accelerometer in a compact industrial-grade sensor module. It is designed for accurate motion sensing, stabilization, navigation, robotics, and platform control applications. <br><br>This device provides a gyroscope measurement range of <strong>±500°/s</strong> and an accelerometer measurement range of <strong>±40g</strong>, making it suitable for dynamic systems that require reliable angular rate and acceleration data. <br><br>The ADIS16507-2BMLZ includes factory calibration for key parameters such as <strong>sensitivity, bias, alignment, linear acceleration effects, and point of percussion</strong>, helping reduce system-level calibration effort and improving measurement consistency across operating conditions. <br><br>Communication is handled through a <strong>SPI digital interface</strong>, allowing straightforward integration with microcontrollers, DSPs, FPGAs, and embedded processing platforms. Its register-based architecture supports efficient data collection, configuration, and diagnostics. <br><br>The module operates across an extended temperature range of <strong>-40°C to +105°C</strong>, supporting demanding industrial and embedded environments. It is supplied in a <strong>100-BGA surface-mount module</strong> with an approximate body size of <strong>15mm × 15mm</strong>. <br><br>The <strong>ADIS16507-2BMLZ</strong> is commonly used in <strong>navigation systems, autonomous equipment, robotics, UAVs, platform stabilization, vibration monitoring, motion control, and industrial instrumentation</strong>, where compact size and precision inertial sensing are required.
ADIS16507-2BMLZ

Description: The ADIS16507-2BMLZ is a precision 6 degrees of freedom MEMS inertial measurement ...
Package: TRAY | MOQ: 2 | MPQ: 84

DMP3099L-7 / The DMP3099L-7 is a compact and efficient <strong>P-channel enhancement mode MOSFET</strong> developed by <strong>Diodes Incorporated</strong>, designed for low-voltage power switching and load management applications. It is optimized for high-efficiency operation in portable and embedded electronic systems. <br><br>The device supports a maximum <strong>drain-source voltage of 30V</strong> and provides continuous drain current capability up to approximately <strong>3.6A</strong>, making it suitable for power distribution, battery management, and load switching applications. <br><br>The DMP3099L-7 features a low <strong>RDS(on)</strong> characteristic, typically around <strong>55mΩ</strong> at appropriate gate drive voltage, helping reduce conduction losses and improve overall system efficiency. Its logic-level gate operation allows direct interfacing with low-voltage microcontrollers and digital logic circuits. <br><br>Designed for fast switching performance, the MOSFET provides low gate charge and optimized capacitance characteristics, supporting efficient high-speed switching in DC-DC converters and power management circuits. <br><br>The device incorporates rugged avalanche characteristics and reliable thermal performance for stable operation under demanding load conditions. It also supports operation across a wide junction temperature range, making it suitable for industrial and consumer applications. <br><br>Packaged in a compact <strong>SOT-23 surface-mount package</strong>, the DMP3099L-7 is ideal for high-density PCB layouts and portable electronic designs where board space is limited. <br><br>The <strong>DMP3099L-7</strong> is widely used in <strong>battery-powered devices, portable electronics, load switching circuits, DC-DC converters, power management systems, and embedded control applications</strong>, where compact size and efficient switching performance are required.
DMP3099L-7

Description: The DMP3099L-7 is a compact and efficient P-channel enhancement mode MOSFET ...
Package: T&R | MOQ: 3000 | MPQ: 3000

ATTINY40-SU / The ATTINY40-SU is a compact and low-power <strong>8-bit AVR microcontroller</strong> developed by <strong>Microchip Technology</strong>, designed for cost-sensitive embedded control applications requiring minimal board space and efficient power consumption. It belongs to the tinyAVR family and utilizes an optimized <strong>RISC-based AVR architecture</strong> for fast and efficient instruction execution. <br><br>The device integrates <strong>4KB of in-system programmable Flash memory</strong>, along with SRAM and EEPROM resources for embedded firmware execution and non-volatile data storage. It supports operating frequencies up to approximately <strong>12 MHz</strong> using an internal oscillator, reducing the need for external clock components. <br><br>The ATTINY40-SU operates from a supply voltage range of approximately <strong>1.8V to 5.5V</strong>, making it suitable for battery-powered and low-voltage electronic systems. It also includes multiple low-power sleep modes to help minimize energy consumption during standby operation. <br><br>The microcontroller integrates several useful peripherals including <strong>GPIO ports, timer/counter modules, watchdog timer, analog comparator, interrupt controller, and USART communication support</strong>, enabling implementation of compact sensing, control, and communication applications. <br><br>Designed for embedded applications with limited PCB space, the ATTINY40-SU is packaged in a compact <strong>14-pin SOIC surface-mount package</strong>, allowing efficient automated assembly and simplified board layout. <br><br>The device supports in-system programming and debug functionality, improving firmware development flexibility and reducing production complexity for embedded system manufacturers. <br><br>The <strong>ATTINY40-SU</strong> is widely used in <strong>portable electronics, sensor interfaces, LED control systems, industrial automation, consumer electronics, battery-powered devices, and compact embedded applications</strong>, where low power consumption and small package size are essential.
ATTINY40-SU

Description: The ATTINY40-SU is a compact and low-power 8-bit AVR microcontroller deve ...
Package: TUBE | MOQ: 1056 | MPQ: 96

ATTINY9-TS8R / The ATTINY9-TS8R is an ultra-compact and energy-efficient <strong>8-bit AVR microcontroller</strong> developed by <strong>Microchip Technology</strong>, designed for low-cost embedded control and portable electronic applications. It belongs to the tinyAVR family and provides efficient processing capability in extremely space-constrained designs. <br><br>The device integrates <strong>1KB of in-system programmable Flash memory</strong> along with SRAM resources for embedded firmware execution and simple control applications. It utilizes an optimized <strong>AVR RISC architecture</strong>, enabling fast instruction execution with low power consumption. <br><br>The ATTINY9-TS8R supports operating frequencies up to approximately <strong>12 MHz</strong> using its internal oscillator, minimizing the need for external timing components and simplifying PCB design. <br><br>The microcontroller operates from a supply voltage range of approximately <strong>1.8V to 5.5V</strong>, making it suitable for low-voltage and battery-powered electronic systems. It also includes multiple low-power sleep modes to reduce energy consumption during standby operation. <br><br>The device integrates useful peripherals including <strong>GPIO ports, timer/counter modules, watchdog timer, analog comparator, and interrupt functionality</strong>, enabling implementation of compact sensing, timing, and control applications with minimal external components. <br><br>Packaged in a miniature <strong>TSOT-23-6 / SOT-23-6 surface-mount package</strong>, the ATTINY9-TS8R is optimized for highly compact PCB layouts and portable embedded devices. <br><br>The <strong>ATTINY9-TS8R</strong> is widely used in <strong>portable electronics, LED drivers, sensor modules, wearable devices, battery-powered products, industrial control systems, and compact embedded applications</strong>, where low power consumption and extremely small package size are critical.
ATTINY9-TS8R

Description: The ATTINY9-TS8R is an ultra-compact and energy-efficient 8-bit AVR microcontrolle ...
Package: T&R | MOQ: 3000 | MPQ: 3000

ATTINY10-TS8R / The ATTINY10-TS8R is a compact and energy-efficient <strong>8-bit AVR microcontroller</strong> developed by <strong>Microchip Technology</strong>, designed for low-cost embedded control and portable electronic applications. It belongs to the tinyAVR family and provides efficient processing capability in extremely space-constrained designs. <br><br>The device integrates <strong>1KB of in-system programmable Flash memory</strong>, along with SRAM and EEPROM resources for flexible program execution and non-volatile data storage. It operates with an advanced <strong>RISC-based AVR CPU architecture</strong>, enabling efficient instruction execution with low power consumption. <br><br>The ATTINY10-TS8R supports operating frequencies up to approximately <strong>12 MHz</strong> and includes an internal oscillator, reducing the need for external clock components in compact embedded systems. <br><br>The microcontroller operates from a supply voltage range of approximately <strong>1.8V to 5.5V</strong>, making it suitable for battery-powered and low-voltage applications. It also features multiple low-power sleep modes that help minimize energy consumption during standby operation. <br><br>The device integrates useful peripherals including <strong>GPIO ports, timer/counter modules, watchdog timer, analog comparator, and ADC functionality</strong>, allowing implementation of sensing, timing, and simple control applications without additional external ICs. <br><br>Designed for compact PCB layouts, the ATTINY10-TS8R is packaged in an <strong>8-pin SOIC surface-mount package</strong>, enabling easy integration into small embedded designs and consumer electronics. <br><br>The <strong>ATTINY10-TS8R</strong> is widely used in <strong>portable devices, sensor modules, LED control systems, industrial controllers, smart home electronics, battery-powered applications, and compact embedded systems</strong>, where low power consumption and minimal board space are critical.
ATTINY10-TS8R

Description: The ATTINY10-TS8R is a compact and energy-efficient 8-bit AVR microcontroller ...
Package: T&R | MOQ: 3000 | MPQ: 3000

W25Q16JVSNIQ / The W25Q16JVSNIQ is a high-performance <strong>16Mbit serial NOR Flash memory</strong> developed by <strong>Winbond</strong>, designed for embedded firmware storage, execute-in-place applications, and non-volatile data retention systems. It utilizes a high-speed <strong>SPI and Quad SPI (QSPI) serial interface</strong>, enabling efficient communication with microcontrollers, processors, DSPs, and FPGA platforms. <br><br>The device provides a memory organization of <strong>2M × 8-bit</strong> and supports serial clock frequencies up to approximately <strong>133 MHz</strong>, allowing high-speed read access and accelerated data throughput in Quad SPI operation for performance-sensitive embedded systems. <br><br>The W25Q16JVSNIQ operates from a supply voltage range of approximately <strong>2.7V to 3.6V</strong>, making it suitable for low-power and portable electronics. It also includes deep power-down functionality and low standby current operation to help reduce overall system energy consumption. <br><br>The Flash memory supports flexible erase and programming functions including <strong>4KB sector erase, 32KB/64KB block erase, chip erase, and page programming operations</strong>, enabling efficient firmware updates and memory management. Internal program and erase control logic simplify external controller implementation. <br><br>Advanced integrated features such as <strong>JEDEC standard identification, hardware and software write protection, security registers, suspend/resume functionality, and SFDP support</strong> improve compatibility, data integrity, and system flexibility in embedded designs. <br><br>The device also supports execute-in-place (XiP) operation, enabling processors to directly execute firmware stored in external Flash memory without requiring large RAM resources, helping reduce system cost and complexity. <br><br>Packaged in a compact <strong>8-pin SOIC wide-body surface-mount package</strong>, the W25Q16JVSNIQ is optimized for automated PCB assembly and robust embedded system integration. <br><br>The <strong>W25Q16JVSNIQ</strong> is widely used in <strong>industrial controllers, communication systems, IoT devices, consumer electronics, BIOS storage, embedded platforms, and FPGA configuration applications</strong>, where reliable high-speed serial Flash memory is required.
W25Q16JVSNIQ

Description: The W25Q16JVSNIQ is a high-performance 16Mbit serial NOR Flash memory dev ...
Package: T&R | MOQ: 2080 | MPQ: 2080

W25Q16JVSSIQ / The W25Q16JVSSIQ is a high-performance <strong>16Mbit serial NOR Flash memory</strong> developed by <strong>Winbond</strong>, designed for firmware storage, embedded code execution, and non-volatile data retention applications. It utilizes a high-speed <strong>SPI and Quad SPI (QSPI) serial interface</strong>, enabling fast communication with microcontrollers, DSPs, FPGAs, and embedded processors. <br><br>The device provides a memory organization of <strong>2M × 8-bit</strong> and supports high-speed clock frequencies up to approximately <strong>133 MHz</strong>, with enhanced throughput available in Quad SPI mode for high-performance embedded applications and execute-in-place (XiP) functionality. <br><br>The W25Q16JVSSIQ operates from a supply voltage range of approximately <strong>2.7V to 3.6V</strong>, making it suitable for low-power and portable electronic systems. It also includes low standby current and deep power-down operating modes to minimize energy consumption in battery-powered applications. <br><br>The Flash memory supports flexible erase and programming operations including <strong>4KB sector erase, 32KB/64KB block erase, chip erase, and page program functions</strong>, enabling efficient firmware management and secure field updates. Integrated internal control logic simplifies external system implementation and improves overall reliability. <br><br>Advanced features such as <strong>JEDEC standard identification, hardware/software write protection, security registers, suspend/resume operations, and serial flash discoverable parameters (SFDP)</strong> improve system compatibility, operational flexibility, and data security. <br><br>The device also supports execute-in-place operation, enabling processors to directly execute firmware from external Flash memory without copying the code into RAM, reducing memory requirements and system cost. <br><br>Packaged in a compact <strong>8-pin SOIC surface-mount package</strong>, the W25Q16JVSSIQ is optimized for automated PCB assembly and compact embedded system layouts. <br><br>The <strong>W25Q16JVSSIQ</strong> is widely used in <strong>industrial automation, communication devices, IoT systems, consumer electronics, embedded controllers, BIOS storage, and FPGA configuration applications</strong>, where reliable high-speed serial non-volatile memory is required.
W25Q16JVSSIQ

Description: The W25Q16JVSSIQ is a high-performance 16Mbit serial NOR Flash memory dev ...
Package: T&R | MOQ: 2080 | MPQ: 2080

W25X40CLSSIG / The W25X40CLSSIG is a compact and reliable <strong>4Mbit serial NOR Flash memory</strong> developed by <strong>Winbond</strong>, designed for firmware storage, embedded code execution, and non-volatile data retention applications. It utilizes a high-speed <strong>SPI-compatible serial interface</strong>, enabling efficient communication with microcontrollers, DSPs, and embedded processors. <br><br>The device provides a memory organization of <strong>512K × 8-bit</strong> and supports serial clock frequencies up to approximately <strong>104 MHz</strong>, allowing fast read access and efficient firmware execution in embedded systems. <br><br>The W25X40CLSSIG operates from a supply voltage range of approximately <strong>2.7V to 3.6V</strong>, making it suitable for low-power and portable electronic applications. It also supports deep power-down mode and low standby current operation to reduce overall system energy consumption. <br><br>The Flash memory supports flexible erase and programming operations including <strong>sector erase, block erase, chip erase, and page program functions</strong>, enabling efficient firmware updates and memory management. Internal program and erase controllers simplify external system design and improve reliability. <br><br>Advanced features such as <strong>write protection mechanisms, JEDEC standard identification, status registers, and suspend/resume functionality</strong> improve compatibility, security, and operational flexibility in embedded applications. <br><br>The device is optimized for execute-in-place (XiP) applications, allowing processors to directly access and execute stored firmware without requiring large external RAM resources. <br><br>Packaged in a compact <strong>8-pin SOIC surface-mount package</strong>, the W25X40CLSSIG is ideal for automated PCB assembly and high-density embedded system designs. <br><br>The <strong>W25X40CLSSIG</strong> is widely used in <strong>industrial controllers, consumer electronics, IoT modules, communication devices, BIOS storage, embedded systems, and FPGA configuration applications</strong>, where reliable serial non-volatile memory is required.
W25X40CLSSIG

Description: The W25X40CLSSIG is a compact and reliable 4Mbit serial NOR Flash memory ...
Package: T&R | MOQ: 2080 | MPQ: 2080

W25Q80DVSSIG / The W25Q80DVSSIG is a reliable and high-speed <strong>8Mbit serial NOR Flash memory</strong> developed by <strong>Winbond</strong>, designed for firmware storage, embedded code execution, and non-volatile data retention applications. It utilizes a high-performance <strong>SPI and Quad SPI (QSPI) serial interface</strong>, enabling efficient communication with microcontrollers, DSPs, FPGAs, and embedded processors. <br><br>The device provides a memory organization of <strong>1M × 8-bit</strong> and supports high-speed serial clock frequencies up to approximately <strong>104 MHz</strong>, with enhanced throughput available in Quad SPI mode for fast data transfer and execute-in-place (XiP) functionality. <br><br>The W25Q80DVSSIG operates from a supply voltage range of approximately <strong>2.7V to 3.6V</strong>, making it suitable for low-power and battery-operated electronic systems. It also includes low standby current and deep power-down operating modes to help minimize energy consumption. <br><br>The Flash memory supports flexible erase and programming operations including <strong>4KB sector erase, 32KB/64KB block erase, chip erase, and page program functions</strong>, allowing efficient firmware management and field updates. Integrated internal control logic simplifies system implementation and reduces processor overhead. <br><br>Advanced features such as <strong>JEDEC standard identification, hardware/software write protection, security registers, suspend/resume functionality, and serial flash discoverable parameters (SFDP)</strong> improve system compatibility, reliability, and data security. <br><br>The W25Q80DVSSIG also supports execute-in-place capability, enabling processors to directly execute program code from external Flash memory without requiring full code loading into RAM. <br><br>Packaged in a compact <strong>8-pin SOIC surface-mount package</strong>, the W25Q80DVSSIG is optimized for automated assembly and space-efficient PCB designs. <br><br>The <strong>W25Q80DVSSIG</strong> is widely used in <strong>embedded systems, industrial controllers, communication equipment, consumer electronics, IoT modules, BIOS storage, and FPGA configuration applications</strong>, where reliable high-speed non-volatile memory is required.
W25Q80DVSSIG

Description: The W25Q80DVSSIG is a reliable and high-speed 8Mbit serial NOR Flash memory ...
Package: T&R | MOQ: 2080 | MPQ: 2080

W25X10CLSNIG / The W25X10CLSNIG is a compact and reliable <strong>1Mbit serial NOR Flash memory</strong> developed by <strong>Winbond</strong>, designed for code storage, firmware memory, and embedded data retention applications. It utilizes a high-speed <strong>SPI-compatible serial interface</strong>, enabling efficient communication with microcontrollers, DSPs, and embedded processors. <br><br>The device provides a memory organization of <strong>128K × 8-bit</strong> and supports standard SPI operation with clock frequencies up to approximately <strong>104 MHz</strong>, allowing fast read and programming performance in embedded systems. <br><br>The W25X10CLSNIG operates from a supply voltage range of approximately <strong>2.7V to 3.6V</strong>, making it suitable for low-power and battery-operated electronic designs. It also supports low standby current operation, helping reduce overall system power consumption. <br><br>This Flash memory incorporates flexible erase and programming architecture, including <strong>sector erase, block erase, and chip erase functions</strong>, enabling efficient memory management and firmware updates. It also supports page program operations with internal program and erase control logic for simplified system integration. <br><br>The device includes advanced features such as <strong>write protection mechanisms, status registers, deep power-down mode, and JEDEC standard identification</strong>, improving system security, compatibility, and reliability in embedded applications. <br><br>Packaged in a compact <strong>8-pin SOIC surface-mount package</strong>, the W25X10CLSNIG is optimized for space-constrained PCB layouts and automated assembly processes. <br><br>The <strong>W25X10CLSNIG</strong> is widely used in <strong>embedded systems, industrial controllers, consumer electronics, communication devices, IoT modules, BIOS storage, and firmware memory applications</strong>, where reliable non-volatile serial memory is required.
W25X10CLSNIG

Description: The W25X10CLSNIG is a compact and reliable 1Mbit serial NOR Flash memory ...
Package: TUBE | MOQ: 500 | MPQ: 100

TLP785(D4B-T6,F / The TLP785(D4B-T6,F is a highly reliable <strong>phototransistor output optocoupler</strong> developed by <strong>Toshiba</strong>, designed for electrical isolation between low-voltage control circuits and high-voltage power systems. It integrates a <strong>gallium arsenide infrared LED and a silicon phototransistor</strong> within a compact isolated package. <br><br>The device provides an isolation voltage of approximately <strong>5000Vrms</strong>, helping protect sensitive electronic circuits against voltage transients, noise, and ground potential differences in industrial and power applications. It is widely used for safe signal transmission across isolated domains. <br><br>The TLP785(D4B-T6,F features a <strong>phototransistor DC output structure</strong> with a collector-emitter voltage rating of approximately <strong>80V</strong> and output current capability up to <strong>50mA</strong>, enabling flexible interfacing with logic and control circuits. <br><br>The optocoupler offers a <strong>current transfer ratio (CTR) range from 200% to 400%</strong> for the D4B rank version, ensuring stable and predictable switching characteristics in signal isolation applications. It also provides fast switching performance with typical rise and fall times around <strong>2µs to 3µs</strong>. <br><br>Designed for robust industrial operation, the device supports an operating temperature range of approximately <strong>-55°C to +110°C</strong> and includes high insulation resistance for long-term reliability under demanding environmental conditions. <br><br>The TLP785(D4B-T6,F is packaged in a compact <strong>4-pin DIP package with gull-wing SMD lead form</strong>, allowing efficient automated PCB assembly while maintaining strong creepage and clearance distances for reinforced isolation designs. <br><br>The <strong>TLP785(D4B-T6,F</strong> is widely used in <strong>switching power supplies, industrial automation systems, microcontroller interfaces, solid-state relays, signal isolation circuits, communication interfaces, and embedded control applications</strong>, where reliable galvanic isolation and stable switching performance are required.
TLP785(D4B-T6,F

Description: The TLP785(D4B-T6,F is a highly reliable phototransistor output optocoupler ...
Package: T&R | MOQ: 4000 | MPQ: 4000

BFR93AWH6327XTSA1 / The BFR93AWH6327XTSA1 is a high-frequency <strong>NPN RF transistor</strong> developed by <strong>Infineon Technologies</strong>, designed for wideband amplification and RF signal processing applications in communication and industrial systems. It is optimized for low-noise and high-gain operation across VHF and UHF frequency ranges. <br><br>The device features a <strong>transition frequency (fT) of approximately 6 GHz</strong>, enabling efficient amplification in high-frequency RF circuits. Its low parasitic capacitance and optimized silicon structure support stable operation in broadband amplifier and oscillator designs. <br><br>The BFR93AWH6327XTSA1 operates with collector-emitter voltages up to approximately <strong>12V</strong> and supports collector currents around <strong>30mA</strong>, making it suitable for low-power RF amplification and signal conditioning applications. <br><br>Designed for low-noise performance, the transistor provides excellent gain characteristics and high linearity, helping improve signal quality in RF front-end circuits. It is commonly used in applications requiring low distortion and reliable high-frequency amplification. <br><br>The device is housed in a compact <strong>SOT-323 surface-mount package</strong>, allowing efficient PCB layout in space-constrained RF and wireless communication systems. Its small package size also helps minimize parasitic effects in high-frequency circuit designs. <br><br>The BFR93AWH6327XTSA1 supports operation across a wide temperature range and offers reliable thermal and electrical performance in demanding environments. <br><br>The <strong>BFR93AWH6327XTSA1</strong> is widely used in <strong>RF amplifiers, wireless communication equipment, antenna amplifiers, VHF/UHF receivers, oscillators, signal conditioning circuits, and broadband RF applications</strong>, where stable high-frequency transistor performance is required.
BFR93AWH6327XTSA1

Description: The BFR93AWH6327XTSA1 is a high-frequency NPN RF transistor developed by ...
Package: T&R | MOQ: 3000 | MPQ: 3000

HF62F-005-1HT / The HF62F-005-1HT is a compact and reliable <strong>miniature electromagnetic power relay</strong> developed by <strong>Hongfa</strong>, designed for switching signal and medium-power loads in industrial, consumer, and embedded electronic applications. It features a <strong>single-pole single-throw normally open (SPST-NO) contact configuration</strong>, providing dependable switching performance in compact PCB-based systems. <br><br>The relay operates with a <strong>5V DC coil voltage</strong> and is optimized for low coil power consumption while maintaining stable contact switching characteristics. Its miniature footprint allows efficient use of PCB space in compact electronic equipment and control modules. <br><br>The HF62F-005-1HT supports switching currents up to approximately <strong>5A</strong> depending on load conditions and contact configuration, making it suitable for switching small motors, lamps, solenoids, communication lines, and power control circuits. <br><br>Designed for long operational reliability, the relay provides high insulation resistance and strong dielectric strength between coil and contacts, improving electrical safety and long-term stability in demanding environments. It also offers high mechanical endurance for repetitive switching applications. <br><br>The device features a <strong>sealed through-hole PCB mounting structure</strong>, helping protect the internal contact system against dust, humidity, and solder flux contamination during automated manufacturing processes. <br><br>The HF62F-005-1HT operates across a wide environmental temperature range and maintains stable performance under varying industrial and commercial operating conditions. Its compact construction and reliable switching behavior make it ideal for embedded switching applications. <br><br>The <strong>HF62F-005-1HT</strong> is widely used in <strong>industrial automation systems, smart home devices, communication equipment, control boards, household appliances, power management modules, and embedded electronic applications</strong>, where compact and dependable relay switching is required.
HF62F-005-1HT

Description: The HF62F-005-1HT is a compact and reliable miniature electromagnetic power relay ...
Package: TRAY | MOQ: 1000 | MPQ: 100

HF32FA-T/024-HSL2 / The HF32FA-T/024-HSL2 is a compact and reliable <strong>miniature electromagnetic power relay</strong> developed by <strong>Hongfa</strong>, designed for efficient load switching in industrial, consumer, and embedded electronic applications. It features a <strong>single-pole single-throw normally open (SPST-NO) contact configuration</strong>, providing dependable switching performance for power control systems. <br><br>The relay operates with a <strong>24V DC coil voltage</strong> and is optimized for low coil power consumption and stable switching characteristics. Its slim relay structure allows efficient PCB utilization in compact electronic designs and high-density control modules. <br><br>The HF32FA-T/024-HSL2 supports switching currents up to approximately <strong>10A</strong> depending on load conditions, making it suitable for controlling lighting systems, motors, HVAC equipment, power supplies, and automation devices. <br><br>Designed for long operational life, the relay provides high insulation resistance and strong dielectric strength between coil and contact sections, helping improve safety and reliability in electrically demanding environments. It also offers strong resistance to vibration and mechanical shock for industrial applications. <br><br>The device utilizes a <strong>sealed through-hole PCB mounting structure</strong>, improving resistance against dust, humidity, and solder flux contamination during manufacturing and long-term operation. Its compact form factor supports automated assembly processes and efficient thermal management. <br><br>The HF32FA-T/024-HSL2 operates across a wide environmental temperature range and maintains stable contact performance under repetitive switching conditions, making it suitable for industrial and commercial electronic systems. <br><br>The <strong>HF32FA-T/024-HSL2</strong> is widely used in <strong>industrial automation, smart home systems, control panels, HVAC controllers, power management equipment, consumer electronics, and embedded switching applications</strong>, where compact and reliable relay switching is required.
HF32FA-T/024-HSL2

Description: The HF32FA-T/024-HSL2 is a compact and reliable miniature electromagnetic power re ...
Package: TRAY | MOQ: 500 | MPQ: 100

HF115F-I-005-1HS3A / The HF115F-I-005-1HS3A is a compact and durable <strong>miniature electromagnetic power relay</strong> developed by <strong>Hongfa</strong>, designed for reliable switching of high-current electrical loads in industrial, automotive, and consumer electronic applications. It features a <strong>single-pole single-throw normally open (SPST-NO) contact configuration</strong>, providing efficient on/off load control. <br><br>The relay operates with a <strong>5V DC coil voltage</strong> and is optimized for low coil power consumption while maintaining strong switching performance. Its compact design enables easy integration into PCB-based control systems and embedded switching modules. <br><br>The HF115F-I-005-1HS3A supports switching currents up to approximately <strong>16A</strong> depending on load type and operating conditions, making it suitable for controlling motors, lighting systems, power supplies, solenoids, and household appliances. <br><br>Designed for long-term reliability, the relay provides high dielectric strength and strong insulation resistance between coil and contact sections, helping improve operational safety in electrically demanding environments. It also offers long mechanical and electrical service life under repetitive switching conditions. <br><br>The device features a <strong>sealed through-hole PCB mounting structure</strong>, improving resistance to dust, humidity, and solder flux contamination during automated manufacturing processes. Its robust mechanical construction enhances vibration and shock resistance in industrial systems. <br><br>The HF115F-I-005-1HS3A operates over a wide temperature range and maintains stable switching characteristics under varying environmental conditions, making it suitable for both commercial and industrial applications. <br><br>The <strong>HF115F-I-005-1HS3A</strong> is widely used in <strong>industrial automation systems, smart home devices, HVAC controllers, automotive electronics, power management equipment, and embedded control applications</strong>, where reliable high-current relay switching is required.
HF115F-I-005-1HS3A

Description: The HF115F-I-005-1HS3A is a compact and durable miniature electromagnetic power re ...
Package: TRAY | MOQ: 500 | MPQ: 100

HF105F-1-024D-1HS / The HF105F-1-024D-1HS is a compact and durable <strong>miniature electromagnetic power relay</strong> developed by <strong>Hongfa</strong>, designed for reliable switching of high-current loads in industrial, consumer, and embedded electronic systems. It features a <strong>single-pole double-throw (SPDT) contact configuration</strong>, enabling flexible switching between normally open and normally closed contacts. <br><br>The relay operates with a <strong>24V DC coil voltage</strong> and provides stable switching performance with low coil power consumption, making it suitable for automation and control applications. Its compact structure allows efficient PCB integration while maintaining strong electrical isolation between coil and contacts. <br><br>The HF105F-1-024D-1HS supports switching currents up to approximately <strong>10A</strong> depending on load conditions, enabling reliable control of motors, lamps, power supplies, solenoids, and household appliances. <br><br>Designed for long operational life, the relay offers high mechanical endurance and reliable contact performance under repetitive switching conditions. It also provides strong dielectric strength and insulation resistance, helping improve system safety and reliability in industrial environments. <br><br>The device features a <strong>sealed through-hole PCB mounting structure</strong>, improving resistance against dust and flux contamination during automated soldering processes. Its compact footprint makes it suitable for high-density PCB layouts and embedded control systems. <br><br>The relay supports operation across a wide temperature range and is designed to maintain stable performance under varying environmental conditions. <br><br>The <strong>HF105F-1-024D-1HS</strong> is widely used in <strong>industrial automation, household appliances, smart home systems, HVAC controllers, power management modules, automotive electronics, and embedded switching applications</strong>, where dependable high-current relay control is required.
HF105F-1-024D-1HS

Description: The HF105F-1-024D-1HS is a compact and durable miniature electromagnetic power rel ...
Package: TRAY | MOQ: 500 | MPQ: 100

HF115F-005-1HS1 / The HF115F-005-1HS1 is a compact and reliable <strong>miniature high-power electromagnetic relay</strong> developed by <strong>Hongfa</strong>, designed for switching high-current loads in industrial, consumer, and automotive electronic systems. It features a <strong>single-pole double-throw (SPDT) contact configuration</strong>, enabling flexible switching between normally open and normally closed circuits. <br><br>The relay operates with a <strong>5V DC coil voltage</strong> and provides excellent switching capability for both AC and DC loads. Its high-contact capacity makes it suitable for applications requiring stable and durable load switching performance. <br><br>The HF115F-005-1HS1 supports switching currents up to approximately <strong>16A</strong> depending on load conditions and contact material configuration, allowing reliable control of motors, power supplies, heaters, and other high-power devices. <br><br>Designed with high insulation strength and strong dielectric performance, the relay offers excellent electrical isolation between the coil and contact sections. It also provides long mechanical and electrical service life, helping improve reliability in continuous switching applications. <br><br>The device features a compact <strong>PCB through-hole mounting design</strong>, enabling efficient board integration while maintaining strong mechanical stability. Its sealed construction improves resistance against dust and environmental contamination in industrial environments. <br><br>The HF115F-005-1HS1 operates over a wide temperature range and provides low coil power consumption, supporting efficient and stable operation in embedded and industrial control systems. <br><br>The <strong>HF115F-005-1HS1</strong> is widely used in <strong>industrial automation, household appliances, power management systems, HVAC equipment, automotive electronics, smart control modules, and embedded switching applications</strong>, where dependable high-current relay switching is required.
HF115F-005-1HS1

Description: The HF115F-005-1HS1 is a compact and reliable miniature high-power electromagnetic ...
Package: TRAY | MOQ: 500 | MPQ: 100

SN74HCT244PWR / The SN74HCT244PWR is a high-speed <strong>octal buffer and line driver</strong> developed by <strong>Texas Instruments</strong>, designed to improve signal integrity and drive capability in digital systems. It features <strong>eight non-inverting buffer channels</strong> organized into two groups with independent output-enable controls for flexible bus interfacing. <br><br>The device utilizes <strong>HCT CMOS technology with TTL-compatible input thresholds</strong>, allowing seamless interfacing between TTL and CMOS logic families. It operates from a standard <strong>5V supply voltage</strong> and provides low power consumption with high noise immunity. <br><br>The SN74HCT244PWR supports <strong>3-state outputs</strong>, enabling direct connection to shared buses and data lines without bus contention. Each output can be placed into a high-impedance state using the dedicated enable inputs, simplifying multiplexed digital system design. <br><br>The buffer offers fast propagation delays, typically in the range of <strong>10 ns to 20 ns</strong>, making it suitable for high-speed digital signal buffering and transmission applications. It also provides balanced output drive capability for improved signal quality over longer PCB traces. <br><br>Designed for robust operation, the device includes input clamp diodes that help protect against transient voltages and support interfacing with higher-voltage signals through current-limiting resistors. The IC also supports an operating temperature range suitable for industrial and commercial applications. <br><br>Packaged in a compact <strong>20-pin TSSOP surface-mount package</strong>, the SN74HCT244PWR is optimized for space-efficient PCB layouts and automated assembly processes. <br><br>The <strong>SN74HCT244PWR</strong> is widely used in <strong>microprocessor systems, memory interfacing, bus-oriented architectures, embedded control systems, industrial electronics, and digital communication applications</strong>, where reliable high-speed buffering and line driving are required.
SN74HCT244PWR

Description: The SN74HCT244PWR is a high-speed octal buffer and line driver developed ...
Package: T&R | MOQ: 2000 | MPQ: 2000

SMAZ24-TP / The SMAZ24-TP is a reliable <strong>24V surface-mount Zener diode</strong> developed by <strong>Diodes Incorporated</strong>, designed for voltage regulation, voltage reference generation, and overvoltage protection in electronic circuits. It provides stable reverse breakdown characteristics and fast response for protecting sensitive components from voltage spikes. <br><br>The device features a nominal <strong>Zener breakdown voltage of 24V</strong> and supports power dissipation around <strong>1W</strong>, making it suitable for a wide range of industrial, consumer, and embedded electronic applications. Its silicon planar junction construction ensures stable electrical performance and long operational life. <br><br>The SMAZ24-TP offers low leakage current and low dynamic impedance, helping maintain stable regulation characteristics under varying load and temperature conditions. It is commonly used in voltage clamping and reference circuits where consistent voltage regulation is required. <br><br>Designed for robust operation, the diode supports an operating temperature range of approximately <strong>-55°C to +150°C</strong>, ensuring dependable performance in harsh industrial and automotive environments. It also provides strong surge capability and thermal reliability. <br><br>The device is packaged in a compact <strong>SMA (DO-214AC) surface-mount package</strong>, enabling efficient automated PCB assembly and compact board layouts for modern electronic systems. <br><br>The <strong>SMAZ24-TP</strong> is widely used in <strong>power supply circuits, voltage reference applications, industrial control systems, communication devices, consumer electronics, and embedded protection systems</strong>, where stable voltage regulation and overvoltage protection are essential.
SMAZ24-TP

Description: The SMAZ24-TP is a reliable 24V surface-mount Zener diode developed by ...
Package: T&R | MOQ: 5000 | MPQ: 5000

SMAZ24-13-F / The SMAZ24-13-F is a reliable <strong>24V surface-mount Zener diode</strong> developed by <strong>Diodes Incorporated</strong>, designed for voltage regulation, reference generation, and overvoltage protection in electronic circuits. It provides stable breakdown voltage characteristics and fast response for protecting sensitive components. <br><br>The device features a nominal <strong>Zener voltage of 24V</strong> and is optimized for low leakage current and stable regulation performance across a wide operating range. Its silicon planar construction ensures reliable electrical behavior and long-term stability in demanding applications. <br><br>The SMAZ24-13-F supports a typical <strong>power dissipation capability around 1W</strong>, making it suitable for voltage clamping and regulation functions in industrial, consumer, and embedded systems. It also offers low dynamic impedance, improving voltage stability during varying load conditions. <br><br>Designed for robust operation, the diode operates across an extended temperature range of approximately <strong>-55°C to +150°C</strong>, ensuring dependable performance in harsh environments. The device also provides excellent surge handling capability and thermal reliability. <br><br>The SMAZ24-13-F is packaged in a compact <strong>SMA (DO-214AC) surface-mount package</strong>, enabling efficient automated assembly and compact PCB layouts for high-density electronic designs. <br><br>The <strong>SMAZ24-13-F</strong> is widely used in <strong>power supplies, voltage reference circuits, industrial control systems, consumer electronics, communication devices, and embedded protection applications</strong>, where stable voltage regulation and circuit protection are required.
SMAZ24-13-F

Description: The SMAZ24-13-F is a reliable 24V surface-mount Zener diode developed by ...
Package: T&R | MOQ: 5000 | MPQ: 5000

SMAJ24CA-TR / The SMAJ24CA-TR is a reliable <strong>bidirectional transient voltage suppressor (TVS) diode</strong> developed by <strong>Littelfuse</strong>, designed to protect sensitive electronic circuits from voltage transients caused by ESD, inductive switching, and lightning surge events. It provides fast clamping action and high surge capability for robust circuit protection. <br><br>The device features a <strong>stand-off voltage of 24V</strong> and is capable of dissipating peak pulse power up to approximately <strong>400W</strong> under specified surge conditions, making it suitable for protecting industrial, automotive, and communication interfaces. <br><br>The SMAJ24CA-TR utilizes a <strong>bidirectional protection structure</strong>, allowing protection of AC signals and data lines regardless of polarity. It offers low leakage current and fast response time, typically in the picosecond range, helping minimize damage to downstream circuitry during transient events. <br><br>This TVS diode is designed with a low incremental surge resistance, enabling effective voltage clamping and improved protection efficiency during high-energy transient conditions. It also complies with common surge immunity requirements used in industrial and automotive electronics. <br><br>The device supports operation across a wide temperature range of approximately <strong>-55°C to +150°C</strong>, ensuring reliable protection performance in harsh environments. Its glass-passivated junction construction improves long-term stability and durability. <br><br>Packaged in a compact <strong>SMA (DO-214AC) surface-mount package</strong>, the SMAJ24CA-TR is optimized for automated assembly and space-efficient PCB layouts. <br><br>The <strong>SMAJ24CA-TR</strong> is widely used in <strong>power supplies, industrial control systems, automotive electronics, communication interfaces, consumer electronics, and embedded systems</strong>, where reliable transient voltage protection is required.
SMAJ24CA-TR

Description: The SMAJ24CA-TR is a reliable bidirectional transient voltage suppressor (TVS) dio ...
Package: T&R | MOQ: 5000 | MPQ: 5000

ADSP-21489KSWZ-4B / The ADSP-21489KSWZ-4B is a high-performance <strong>SHARC® floating-point digital signal processor (DSP)</strong> developed by <strong>Analog Devices</strong>, optimized for advanced audio processing, industrial control, and real-time signal processing applications. It belongs to the fourth-generation SHARC processor family and utilizes a powerful <strong>SIMD (Single Instruction Multiple Data) architecture</strong> for high computational efficiency. <br><br>The processor operates at core clock speeds up to approximately <strong>450 MHz</strong> and delivers performance levels around <strong>2700 MFLOPS</strong>, making it highly suitable for complex DSP algorithms including filtering, FFT analysis, and multichannel audio processing. <br><br>The ADSP-21489KSWZ-4B supports both <strong>32-bit fixed-point and 32-/40-bit floating-point arithmetic</strong>, enabling high dynamic range and precise numerical processing in professional audio and industrial systems. It integrates approximately <strong>5 Mbit of on-chip RAM</strong>, reducing the need for external memory in many embedded applications. <br><br>The device includes dedicated hardware accelerators such as <strong>FIR, IIR, and FFT processing engines</strong>, significantly improving signal-processing throughput while reducing CPU load. It also features the advanced <strong>Variable Instruction Set Architecture (VISA)</strong>, helping reduce code size and improve memory efficiency. <br><br>For system connectivity, the processor integrates multiple communication interfaces including <strong>SPI, I²C, UART/USART, SPORT serial ports, DAI (Digital Applications Interface), and external SDR SDRAM interface support</strong>, enabling flexible integration into high-end embedded systems. <br><br>The ADSP-21489KSWZ-4B operates with a <strong>1.1V core supply and 3.3V I/O supply</strong>, balancing high processing performance with optimized power efficiency. It also supports industrial operating temperature ranges suitable for demanding environments. <br><br>Packaged in a compact <strong>100-pin LQFP exposed-pad surface-mount package</strong>, the ADSP-21489KSWZ-4B provides excellent thermal performance and efficient PCB integration for space-sensitive designs. <br><br>The <strong>ADSP-21489KSWZ-4B</strong> is widely used in <strong>professional audio equipment, automotive audio systems, industrial automation, digital mixing consoles, communication systems, medical instrumentation, and embedded real-time signal processing platforms</strong>, where high-speed floating-point DSP capability is required.
ADSP-21489KSWZ-4B

Description: The ADSP-21489KSWZ-4B is a high-performance SHARC® floating-point digital signal ...
Package: TRAY | MOQ: 120 | MPQ: 40

ADP150AUJZ-2.8-R7 / The ADP150AUJZ-2.8-R7 is a high-performance <strong>ultralow noise CMOS low dropout (LDO) linear regulator</strong> developed by <strong>Analog Devices</strong>, designed for noise-sensitive analog, RF, and portable electronic applications. It delivers a fixed output voltage of <strong>2.8V</strong> with excellent power supply rejection and low output noise characteristics. <br><br>The device supports an input voltage range from approximately <strong>2.2V to 5.5V</strong> and provides up to <strong>150mA output current</strong>, making it suitable for powering precision analog circuits, RF transceivers, sensors, and battery-powered systems. <br><br>The ADP150AUJZ-2.8-R7 features exceptionally low output noise performance of approximately <strong>9 µV RMS</strong> and high <strong>power supply rejection ratio (PSRR)</strong>, helping minimize ripple and switching noise in sensitive signal chains. This makes it particularly effective in RF and mixed-signal applications. <br><br>The regulator operates with a very low <strong>dropout voltage of approximately 105mV at 150mA load</strong>, improving efficiency in low-headroom battery-powered designs. It also includes a low quiescent current of approximately <strong>140 µA</strong>, helping extend battery life in portable devices. <br><br>Designed for robust operation, the device integrates multiple protection features including <strong>current limiting, thermal shutdown, and under-voltage lockout</strong>, ensuring safe and stable operation under varying load conditions. <br><br>The ADP150AUJZ-2.8-R7 is stable with small ceramic capacitors, simplifying PCB layout and reducing external component requirements. It also supports fast startup characteristics for responsive power sequencing applications. <br><br>Packaged in a compact <strong>5-pin TSOT-23 surface-mount package</strong>, the ADP150AUJZ-2.8-R7 is ideal for compact and high-density PCB designs. <br><br>The <strong>ADP150AUJZ-2.8-R7</strong> is widely used in <strong>RF modules, wireless communication systems, portable electronics, medical devices, instrumentation equipment, and low-noise analog power supply applications</strong>, where clean and stable voltage regulation is essential.
ADP150AUJZ-2.8-R7

Description: The ADP150AUJZ-2.8-R7 is a high-performance ultralow noise CMOS low dropout (LDO) ...
Package: T&R | MOQ: 3000 | MPQ: 3000

AD7606BSTZ-RL / The AD7606BSTZ-RL is a high-performance <strong>16-bit simultaneous sampling analog-to-digital converter (ADC)</strong> developed by <strong>Analog Devices</strong>, designed for precision multi-channel data acquisition systems. It integrates <strong>8 simultaneously sampled analog input channels</strong>, enabling accurate synchronized measurement of multiple signals in industrial and instrumentation applications. <br><br>The device utilizes a <strong>SAR (Successive Approximation Register) ADC architecture</strong> and supports throughput rates up to approximately <strong>200 kSPS per channel</strong>, providing fast and deterministic signal conversion for real-time systems. It includes integrated analog front-end circuitry, simplifying external signal conditioning requirements. <br><br>The AD7606BSTZ-RL supports true bipolar analog input ranges of <strong>±10V and ±5V</strong> with an integrated analog clamp protection circuit capable of tolerating input voltages up to approximately <strong>±16.5V</strong>, improving robustness in harsh industrial environments. <br><br>This ADC incorporates integrated <strong>second-order anti-aliasing filters, track-and-hold amplifiers, precision reference, and oversampling digital filters</strong>, significantly reducing external component count while improving signal integrity and noise performance. <br><br>The device supports both <strong>parallel and serial interface modes</strong>, allowing flexible integration with FPGAs, DSPs, and microcontrollers. It also features selectable oversampling ratios that improve noise performance and effective resolution for precision measurement applications. <br><br>Operating from a <strong>5V analog supply</strong> with separate digital interface supplies, the AD7606BSTZ-RL provides low power consumption while maintaining high dynamic performance. It offers excellent AC and DC specifications, including high signal-to-noise ratio and low total harmonic distortion. <br><br>Packaged in a compact <strong>64-pin LQFP surface-mount package</strong>, the AD7606BSTZ-RL is optimized for high-density PCB layouts and industrial-grade reliability. <br><br>The <strong>AD7606BSTZ-RL</strong> is widely used in <strong>industrial automation, power line monitoring, motor control systems, protection relays, test and measurement equipment, medical instrumentation, and multi-channel data acquisition systems</strong>, where precise simultaneous analog signal sampling is required.
AD7606BSTZ-RL

Description: The AD7606BSTZ-RL is a high-performance 16-bit simultaneous sampling analog-to-dig ...
Package: T&R | MOQ: 1500 | MPQ: 1500

LTM4622IY / The LTM4622IY is a compact and highly integrated <strong>step-down DC/DC µModule regulator</strong> developed by <strong>Analog Devices</strong>, designed for high-efficiency point-of-load power conversion in embedded and industrial systems. It integrates the switching controller, power MOSFETs, inductors, and compensation circuitry into a single compact package, significantly simplifying power supply design. <br><br>The device supports either <strong>dual 2A outputs or a single 4A output configuration</strong>, offering flexibility for powering multiple voltage rails or higher-current loads from a single module. It operates over a wide input voltage range of approximately <strong>2.375V to 20V</strong>, making it suitable for distributed power architectures and intermediate bus systems. <br><br>The LTM4622IY provides adjustable output voltages from approximately <strong>0.6V to 5.5V</strong> and utilizes a <strong>current-mode control architecture</strong> to achieve fast transient response and stable operation with low output ripple. It supports current sharing and output tracking/sequencing functions for complex multi-rail FPGA and processor applications. <br><br>The module operates with high efficiency, typically above <strong>90%</strong> depending on load and configuration, helping reduce thermal dissipation and improve overall system reliability. It also supports selectable switching frequencies up to approximately <strong>1 MHz</strong>, enabling optimization between efficiency and external capacitor size. <br><br>Designed for robust operation, the LTM4622IY includes integrated protection features such as <strong>overcurrent protection, overvoltage protection, thermal shutdown, soft-start control, and undervoltage lockout</strong>, ensuring reliable operation in demanding environments. <br><br>Packaged in a compact <strong>25-ball BGA µModule package</strong>, the LTM4622IY minimizes PCB footprint and simplifies layout while maintaining excellent thermal performance and EMI characteristics. <br><br>The <strong>LTM4622IY</strong> is widely used in <strong>telecommunications equipment, FPGA and DSP power supplies, industrial automation, embedded computing systems, medical instrumentation, and distributed power systems</strong>, where compact and efficient multi-output power regulation is required.
LTM4622IY

Description: The LTM4622IY is a compact and highly integrated step-down DC/DC µModule regulato ...
Package: TRAY | MOQ: 260 | MPQ: 260

MAX2769ETI+T / The MAX2769ETI+T is a highly integrated <strong>universal GNSS receiver and RF front-end IC</strong> developed by <strong>Analog Devices (Maxim Integrated)</strong>, designed for satellite navigation applications requiring high sensitivity, low power consumption, and compact implementation. It supports multiple satellite systems including <strong>GPS, GLONASS, and Galileo</strong> within a single-chip architecture. <br><br>The device utilizes a <strong>single-conversion low-IF receiver architecture</strong> and integrates the complete RF signal chain, including a <strong>dual-input low-noise amplifier (LNA), mixer, programmable gain amplifier (PGA), voltage-controlled oscillator (VCO), fractional-N synthesizer, crystal oscillator, and multibit ADC</strong>. This high level of integration significantly reduces external component count and simplifies system design. <br><br>The MAX2769ETI+T delivers excellent receiver sensitivity with a cascaded noise figure as low as approximately <strong>1.4 dB</strong>, enabling reliable satellite signal reception even in weak-signal environments. It also eliminates the need for external IF SAW filters through the use of integrated monolithic filtering technology. <br><br>The device supports a wide range of reference clock frequencies and provides a <strong>programmable IF frequency</strong> using its integrated fractional-N synthesizer. It offers flexible digital outputs including <strong>1-bit, 2-bit I/Q outputs or 3-bit I-channel output</strong>, allowing compatibility with various baseband processing architectures. <br><br>The MAX2769ETI+T operates from a supply voltage range of <strong>2.7V to 3.3V</strong> and includes a low-power operating mode with supply current around <strong>10 mA</strong>, making it suitable for portable and battery-powered navigation devices. <br><br>Packaged in a compact <strong>28-pin Thin QFN surface-mount package (5mm × 5mm)</strong>, the MAX2769ETI+T is optimized for space-constrained PCB layouts while maintaining strong RF performance and thermal efficiency. <br><br>The <strong>MAX2769ETI+T</strong> is widely used in <strong>portable navigation devices, telematics systems, asset tracking units, automotive navigation, UAVs, marine electronics, and embedded GNSS applications</strong>, where high-performance satellite signal reception is required.
MAX2769ETI+T

Description: The MAX2769ETI+T is a highly integrated universal GNSS receiver and RF front-end I ...
Package: T&R | MOQ: 2500 | MPQ: 2500

LTM2882IY-3#PBF / The LTM2882IY-3#PBF is a highly integrated <strong>isolated RS-485/RS-422 µModule transceiver</strong> developed by <strong>Analog Devices</strong>, designed to provide reliable high-speed communication with robust galvanic isolation for industrial and embedded systems. It combines signal isolation, power isolation, and transceiver functionality into a compact single package. <br><br>The device integrates a complete <strong>RS-485/RS-422 transceiver with isolated DC/DC converter</strong>, eliminating the need for external optocouplers, transformers, or isolated power supplies. It supports both <strong>full-duplex and half-duplex communication configurations</strong>, making it suitable for flexible serial communication architectures. <br><br>The LTM2882IY-3#PBF provides a high isolation rating of approximately <strong>2500VRMS</strong>, protecting sensitive low-voltage circuitry from high-voltage transients and ground loop disturbances commonly found in industrial environments. <br><br>This transceiver supports data rates up to approximately <strong>20 Mbps</strong>, enabling fast and reliable long-distance serial communication. It also features high <strong>common-mode transient immunity (CMTI)</strong>, ensuring stable data transfer in electrically noisy systems. <br><br>The integrated isolated power supply simplifies PCB layout and reduces component count while maintaining excellent EMI performance. The device operates from a single <strong>3V to 5.5V supply voltage</strong> and includes built-in protection features such as <strong>ESD protection, thermal shutdown, and fail-safe receiver operation</strong>. <br><br>Packaged in a compact <strong>32-ball BGA µModule surface-mount package</strong>, the LTM2882IY-3#PBF is optimized for space-constrained and high-reliability industrial designs. <br><br>The <strong>LTM2882IY-3#PBF</strong> is widely used in <strong>industrial automation, isolated fieldbus networks, motor control systems, data acquisition equipment, instrumentation, and factory communication interfaces</strong>, where robust isolated RS-485 communication is required.
LTM2882IY-3#PBF

Description: The LTM2882IY-3#PBF is a highly integrated isolated RS-485/RS-422 µModule transce ...
Package: TRAY | MOQ: 64 | MPQ: 64

178308-2 / The 178308-2 is a durable and high-performance <strong>PCB mount wire-to-board header connector</strong> developed by <strong>TE Connectivity</strong>, designed for reliable power and signal transmission in industrial and embedded electronic systems. It belongs to the <strong>Dynamic 3000 Series</strong>, which is widely used in applications requiring secure locking and robust electrical performance. <br><br>The connector features a <strong>20-position dual-row configuration</strong> with a <strong>3.81 mm pitch</strong>, enabling compact yet high-current interconnection for power and signal circuits. Its <strong>right-angle through-hole mounting structure</strong> allows efficient PCB space utilization and strong mechanical stability. <br><br>The 178308-2 utilizes a <strong>fully shrouded header design</strong> with polarization and retention mechanisms, helping prevent incorrect mating and improving vibration resistance in demanding environments. It supports wire-to-board connectivity and is compatible with mating Dynamic Series receptacle housings. <br><br>Designed with <strong>gold-plated copper alloy contacts</strong>, the connector provides reliable conductivity and long-term corrosion resistance. It supports operating voltages up to <strong>250V AC/DC</strong> and current ratings up to approximately <strong>15A</strong>, making it suitable for mixed power and signal applications. <br><br>The housing material is constructed from <strong>glass-filled polyester with UL94V-0 flammability rating</strong>, ensuring strong thermal and mechanical durability. The connector also supports an operating temperature range of approximately <strong>-55°C to +105°C</strong>, enabling stable performance in industrial conditions. <br><br>The <strong>178308-2</strong> is widely used in <strong>industrial automation systems, power supply equipment, control units, robotics, communication devices, and embedded electronic applications</strong>, where reliable and secure wire-to-board interconnection is required.
178308-2

Description: The 178308-2 is a durable and high-performance PCB mount wire-to-board header conn ...
Package: TUBE | MOQ: 500 | MPQ: 25

178307-2 / The AD977ABRSZ is a high-performance <strong>16-bit successive approximation (SAR) analog-to-digital converter</strong> developed by <strong>Analog Devices</strong>, designed for precision data acquisition and measurement applications. It features a <strong>single-channel input architecture</strong>, enabling accurate conversion of analog signals into high-resolution digital data. <br><br>This ADC operates with a throughput rate of up to <strong>200 kSPS</strong>, providing fast and reliable signal sampling suitable for real-time systems. It utilizes a <strong>serial interface (SPI-compatible)</strong>, allowing easy integration with microcontrollers, DSPs, and embedded platforms. <br><br>The AD977ABRSZ supports a <strong>single 5V power supply</strong> for both analog and digital sections, simplifying power design while maintaining stable operation. It includes an <strong>internal 2.5V bandgap reference</strong> as well as support for an external reference, offering flexibility in system accuracy and design optimization. <br><br>Designed with a <strong>switched-capacitor SAR architecture</strong>, the device delivers excellent DC and AC performance, including low integral nonlinearity and high signal-to-noise ratio (around <strong>85 dB</strong>), ensuring precise conversion results. <br><br>The ADC supports multiple input ranges, including <strong>bipolar (±10V, ±5V, ±3.3V) and unipolar (0V to 10V, 0V to 5V, 0V to 4V)</strong>, making it adaptable to various signal conditioning requirements. <br><br>Operating across an industrial temperature range of <strong>-40°C to +85°C</strong>, the AD977ABRSZ ensures reliable performance in demanding environments. It also features low power consumption of approximately <strong>100 mW</strong>, supporting energy-efficient system designs. <br><br>Packaged in a compact <strong>28-pin SSOP surface-mount package</strong>, the AD977ABRSZ is well-suited for space-constrained PCB layouts while maintaining strong electrical performance. <br><br>The <strong>AD977ABRSZ</strong> is widely used in <strong>industrial automation, test and measurement equipment, data acquisition systems, medical instrumentation, and sensor interface applications</strong>, where high-resolution and accurate analog-to-digital conversion is essential.
178307-2

Description: The AD977ABRSZ is a high-performance 16-bit successive approximation (SAR) analog- ...
Package: BULK | MOQ: 504 | MPQ: 504

AD977ABRSZ / The AD977ABRSZ is a high-performance <strong>16-bit successive approximation (SAR) analog-to-digital converter</strong> developed by <strong>Analog Devices</strong>, designed for precision data acquisition and measurement applications. It features a <strong>single-channel input architecture</strong>, enabling accurate conversion of analog signals into high-resolution digital data. <br><br>This ADC operates with a throughput rate of up to <strong>200 kSPS</strong>, providing fast and reliable signal sampling suitable for real-time systems. It utilizes a <strong>serial interface (SPI-compatible)</strong>, allowing easy integration with microcontrollers, DSPs, and embedded platforms. <br><br>The AD977ABRSZ supports a <strong>single 5V power supply</strong> for both analog and digital sections, simplifying power design while maintaining stable operation. It includes an <strong>internal 2.5V bandgap reference</strong> as well as support for an external reference, offering flexibility in system accuracy and design optimization. <br><br>Designed with a <strong>switched-capacitor SAR architecture</strong>, the device delivers excellent DC and AC performance, including low integral nonlinearity and high signal-to-noise ratio (around <strong>85 dB</strong>), ensuring precise conversion results. <br><br>The ADC supports multiple input ranges, including <strong>bipolar (±10V, ±5V, ±3.3V) and unipolar (0V to 10V, 0V to 5V, 0V to 4V)</strong>, making it adaptable to various signal conditioning requirements. <br><br>Operating across an industrial temperature range of <strong>-40°C to +85°C</strong>, the AD977ABRSZ ensures reliable performance in demanding environments. It also features low power consumption of approximately <strong>100 mW</strong>, supporting energy-efficient system designs. <br><br>Packaged in a compact <strong>28-pin SSOP surface-mount package</strong>, the AD977ABRSZ is well-suited for space-constrained PCB layouts while maintaining strong electrical performance. <br><br>The <strong>AD977ABRSZ</strong> is widely used in <strong>industrial automation, test and measurement equipment, data acquisition systems, medical instrumentation, and sensor interface applications</strong>, where high-resolution and accurate analog-to-digital conversion is essential.
AD977ABRSZ

Description: The AD977ABRSZ is a high-performance 16-bit successive approximation (SAR) analog- ...
Package: TUBE | MOQ: 47 | MPQ: 47

AUIPS6041GTR / The AUIPS6041GTR is an automotive-grade <strong>intelligent high-side power switch</strong> developed by <strong>Infineon Technologies</strong>, designed for controlling resistive, inductive, and capacitive loads in harsh environments. It belongs to the PROFET™ family and integrates advanced protection and diagnostic features within a compact IC. <br><br>This device features a <strong>single-channel N-channel high-side configuration</strong> with a typical output current capability of approximately <strong>1.6A</strong>, making it suitable for driving relays, solenoids, lamps, and other automotive loads. It operates over a load voltage range of <strong>6V to 28V</strong>, supporting standard automotive supply systems. <br><br>The AUIPS6041GTR offers a low <strong>RDS(on) of approximately 110–130 mΩ</strong>, ensuring efficient power delivery with reduced heat dissipation. Its integrated architecture eliminates the need for external protection components, simplifying PCB design and improving system reliability. <br><br>Designed for robustness, the device includes comprehensive protection mechanisms such as <strong>current limiting, over-temperature shutdown with auto-restart, open-load detection, short-circuit protection, and reverse battery protection</strong>. These features ensure safe operation even under fault conditions. <br><br>The IC also provides <strong>diagnostic feedback via a dedicated pin</strong>, allowing system controllers to detect fault conditions and improve system monitoring capabilities. Its high immunity to electrical noise and transient conditions makes it suitable for demanding automotive environments. <br><br>Qualified to <strong>AEC-Q100 standards</strong>, the AUIPS6041GTR operates over a wide temperature range of <strong>-40°C to +150°C</strong>, ensuring reliable performance in extreme conditions. <br><br>Packaged in a compact <strong>SOIC-8 surface-mount package</strong>, the AUIPS6041GTR is ideal for space-constrained automotive and industrial designs. <br><br>The <strong>AUIPS6041GTR</strong> is widely used in <strong>automotive body electronics, load control systems, industrial automation, power distribution modules, and embedded control applications</strong>, where protected and intelligent high-side switching is required.
AUIPS6041GTR

Description: The AUIPS6041GTR is an automotive-grade intelligent high-side power switch ...
Package: T&R | MOQ: 2500 | MPQ: 2500

LTC1386IS#PBF / The LTC1386IS#PBF is a compact and energy-efficient <strong>RS-232/EIA-TIA-562 full-duplex transceiver</strong> developed by <strong>Analog Devices</strong>, designed for reliable serial communication in low-power embedded systems. It integrates <strong>two drivers and two receivers (2Tx/2Rx)</strong>, enabling bidirectional data transmission between logic-level devices and RS-232 compatible interfaces. <br><br>This device operates from a single <strong>3.3V supply voltage (3.0V to 3.6V)</strong>, making it ideal for modern low-voltage systems. It incorporates an internal <strong>charge pump circuit</strong> that generates the required RS-232 voltage levels using only a few external capacitors, reducing component count and PCB space. <br><br>The LTC1386IS#PBF supports data rates up to approximately <strong>120 kbps</strong> and features <strong>full-duplex communication capability</strong>, ensuring stable and efficient serial data exchange. It also offers a very low supply current, typically around <strong>200 µA</strong>, making it suitable for battery-powered and portable applications. <br><br>Designed for robustness, the device provides strong protection features including <strong>ESD protection up to ±10kV</strong> and the ability to withstand input voltages up to <strong>±25V without damage</strong>, ensuring reliable operation in electrically noisy environments. <br><br>The IC operates across an industrial temperature range of <strong>-40°C to +85°C</strong> and offers a typical receiver hysteresis of <strong>400 mV</strong>, improving noise immunity in communication lines. <br><br>Packaged in a space-saving <strong>16-pin SOIC surface-mount package</strong>, the LTC1386IS#PBF is optimized for compact PCB layouts and high-density designs. <br><br>The <strong>LTC1386IS#PBF</strong> is widely used in <strong>notebook computers, handheld devices, industrial communication systems, instrumentation equipment, and embedded serial interfaces</strong>, where low-power and reliable RS-232 communication is required.
LTC1386IS#PBF

Description: The LTC1386IS#PBF is a compact and energy-efficient RS-232/EIA-TIA-562 full-duplex ...
Package: TUBE | MOQ: 500 | MPQ: 50

TL331KDBV / The TL331KDBV is a versatile <strong>single differential voltage comparator</strong> developed by <strong>Texas Instruments</strong>, designed for general-purpose analog signal comparison in a wide range of electronic systems. It provides reliable switching between two input voltage levels, making it suitable for detection, thresholding, and control applications. <br><br>This device operates over a wide supply voltage range of <strong>2V to 36V (single supply)</strong> or dual supplies, offering excellent flexibility for both low-voltage and higher-voltage system designs. It features a <strong>low supply current of approximately 0.4 mA</strong>, enabling efficient operation in power-sensitive applications. <br><br>The TL331KDBV includes a <strong>low input offset voltage (typically around 2–5 mV)</strong> and low input bias current, ensuring accurate comparison performance in precision circuits. Its <strong>common-mode input voltage range includes ground</strong>, allowing direct sensing of low-level signals without additional circuitry. <br><br>The output stage is configured as an <strong>open-collector output</strong>, which allows wired-AND connections and compatibility with <strong>TTL, CMOS, and MOS logic levels</strong>. This makes it easy to interface with microcontrollers and digital logic systems. <br><br>The device supports a <strong>differential input voltage range up to the supply voltage (±36V)</strong> and offers stable operation with low output saturation voltage, ensuring clean switching behavior in comparator circuits. <br><br>Packaged in a compact <strong>SOT-23-5 surface-mount form factor</strong>, the TL331KDBV is ideal for space-constrained PCB layouts and high-density electronic designs. <br><br>The <strong>TL331KDBV</strong> is widely used in <strong>industrial control systems, battery monitoring, oscillators, window comparators, signal conditioning, and embedded applications</strong>, where reliable and cost-effective voltage comparison is required.
TL331KDBV

Description: The TL331KDBV is a versatile single differential voltage comparator devel ...
Package: T&R | MOQ: 3000 | MPQ: 3000

DRV8301DCA / The DRV8301DCA is a highly integrated <strong>three-phase gate driver IC</strong> developed by <strong>Texas Instruments</strong>, designed for driving external MOSFETs in brushless DC (BLDC) and PMSM motor control applications. It functions as a <strong>pre-driver with three half-bridge gate drivers</strong>, enabling precise control of high- and low-side N-channel MOSFETs. <br><br>This device operates from a wide supply voltage range of approximately <strong>6V to 60V</strong> and supports gate drive capabilities up to <strong>1.7A source and 2.3A sink current</strong>, providing strong drive strength for efficient power stage switching. <br><br>The DRV8301DCA integrates <strong>dual current shunt amplifiers</strong> with programmable gain and offset, allowing accurate bidirectional current sensing for advanced motor control algorithms. It also includes a built-in <strong>switching buck converter (up to 1.5A output)</strong>, enabling direct powering of microcontrollers or system logic without additional regulators. <br><br>For enhanced system control and diagnostics, the device features an <strong>SPI interface</strong> that allows configuration of parameters such as gain settings, slew rate, and protection thresholds. It also provides detailed fault reporting through dedicated pins and registers. <br><br>The IC incorporates comprehensive protection features including <strong>overcurrent protection (OCP), undervoltage lockout (UVLO), overvoltage protection, and thermal shutdown</strong>, ensuring safe operation in demanding environments. <br><br>Using a <strong>bootstrap gate driver architecture with 100% duty cycle support</strong>, the DRV8301DCA enables efficient and continuous motor operation, while built-in handshake mechanisms prevent shoot-through conditions during switching. <br><br>Packaged in a thermally optimized <strong>56-pin HTSSOP surface-mount package</strong>, the device is suitable for compact and high-performance motor control designs. <br><br>The <strong>DRV8301DCA</strong> is widely used in <strong>robotics, e-bikes, power tools, industrial automation systems, pumps, and BLDC motor control applications</strong>, where efficient and intelligent motor driving is required.
DRV8301DCA

Description: The DRV8301DCA is a highly integrated three-phase gate driver IC develope ...
Package: TUBE | MOQ: 400 | MPQ: 40

DRV8870DDAR / The DRV8870DDAR is a compact and efficient <strong>brushed DC motor driver with integrated H-bridge</strong> developed by <strong>Texas Instruments</strong>, designed for driving DC motors and inductive loads in industrial and consumer applications. It integrates four N-channel MOSFETs, enabling <strong>bidirectional motor control</strong> using a simple logic interface. <br><br> This device supports a wide operating voltage range of <strong>6.5V to 45V</strong> and can deliver up to <strong>3.6A peak output current</strong>, making it suitable for medium-power motor control systems such as appliances, printers, and automation equipment. <br><br> The DRV8870DDAR features a <strong>PWM control interface</strong>, allowing precise adjustment of motor speed and torque. It also includes <strong>integrated current regulation</strong> based on an external sense resistor, enabling accurate current limiting and improved system protection during startup and stall conditions. <br><br> Designed for reliability, the device incorporates multiple protection mechanisms such as <strong>undervoltage lockout (UVLO), overcurrent protection (OCP), thermal shutdown (TSD), and automatic fault recovery</strong>, ensuring safe operation in demanding environments. <br><br> The driver also supports a <strong>low-power sleep mode</strong>, reducing power consumption when the motor is inactive, which is particularly beneficial for energy-efficient designs. <br><br> Packaged in a thermally enhanced <strong>8-pin HSOP PowerPAD surface-mount package</strong>, the DRV8870DDAR offers excellent heat dissipation and compact PCB integration. <br><br> The <strong>DRV8870DDAR</strong> is widely used in <strong>printers, household appliances, industrial equipment, robotics, and general-purpose motor control systems</strong>, where reliable and efficient DC motor driving is required.
DRV8870DDAR

Description: The DRV8870DDAR is a compact and efficient brushed DC motor driver with integrated ...
Package: T&R | MOQ: 2500 | MPQ: 2500













info@signalhk.com

+852 2417 2366

Room 1304, 13/F, Allways Centre, 468 Jaffe Road, Causeway Bay, Hong Kong.


SIGNAL-HK WIKI BLOG

Copyright © 2008-2024 Signal HK Limited. All Rights Reserved.Designated trademarks and brands are the property of their respective owners.
Use of this Website constitutes acceptance of Signal HK Limited Terms of Use and Privacy Policy

Cookie Policy | MSN EQV Parts |
