All Products Relay

ALDP124W / The ALDP124W is a slim-type power relay manufactured by Panasonic, designed for applications requiring reliable switching of electrical circuits. It features a single-pole, single-throw normally open (1 Form A) contact configuration, with a nominal contact current rating of 5A. The relay operates with a coil voltage of 24V DC and has a coil resistance of 2.88 kΩ. It consumes a coil current of approximately 8.3 mA and requires a coil power of 200 mW. The operating temperature range for this relay is between -40°C and +85°C. Its compact dimensions are 20.5 mm in length, 7.2 mm in width, and 15.3 mm in height, making it suitable for applications with limited space. Typical applications include use in boilers, air conditioners, refrigerators, hot water units, microwave ovens, and fan heaters.
ALDP124W

Description: The ALDP124W is a slim-type power relay manufactured by Panasonic, designed for applicatio ...
Package: TRAY | MOQ: 1000 | MPQ: 100

G5V-2 DC3 / The Omron G5V-2 DC3 is a compact, general-purpose signal relay designed for reliable low-level switching applications. Measuring approximately 20.3mm in length, 10.1mm in width, and 8.4mm in height, it is suitable for high-density PCB mounting. This relay features a Double Pole Double Throw (DPDT) contact configuration, allowing control of two separate circuits with two possible outputs each. With a 3V DC coil voltage and a coil resistance of 18Ω, it consumes approximately 500mW of power. The G5V-2 DC3 supports a maximum switching voltage of 125VAC or 125VDC and has a contact current rating of up to 2A, making it versatile for various signal switching applications. It operates efficiently within a temperature range of -25°C to 65°C and is designed for through-hole PCB mounting.
G5V-2 DC3

Description: The Omron G5V-2 DC3 is a compact, general-purpose signal relay designed for reliable low-l ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G5V-2 DC9 / The Omron G5V-2 DC9 is a compact, general-purpose signal relay designed for reliable low-level switching applications. Measuring approximately 20.3mm in length, 10.1mm in width, and 8.4mm in height, it is ideal for high-density PCB mounting. This relay features a Double Pole Double Throw (DPDT) contact configuration, enabling control of two separate circuits with two possible outputs each. With a 9V DC coil voltage and a coil resistance of 162Ω, it consumes approximately 500mW of power. The G5V-2 DC9 supports a maximum switching voltage of 125VAC or 125VDC and has a contact current rating of up to 2A, making it versatile for various signal switching applications. It operates efficiently within a temperature range of -25°C to 65°C and is designed for through-hole PCB mounting.
G5V-2 DC9

Description: The Omron G5V-2 DC9 is a compact, general-purpose signal relay designed for reliable low-l ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6S-2 DC4.5 / The Omron G6S-2 DC4.5 is a compact, general-purpose telecom relay designed for reliable low-level switching applications. Measuring approximately 20.3mm in length, 10.1mm in width, and 8.4mm in height, it is ideal for high-density PCB mounting. This relay features a Double Pole Double Throw (DPDT) contact configuration, enabling control of two separate circuits with two possible outputs each. With a 4.5V DC coil voltage and a coil resistance of 145Ω, it consumes approximately 139.5mW of power. The G6S-2 DC4.5 supports a maximum switching voltage of 250VAC or 220VDC and has a contact current rating of up to 2A, making it versatile for various signal switching applications. It operates efficiently within a temperature range of -40°C to 85°C and is designed for through-hole PCB mounting.
G6S-2 DC4.5

Description: The Omron G6S-2 DC4.5 is a compact, general-purpose telecom relay designed for reliable lo ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G5V-2-H1 DC9 / The Omron G5V-2-H1 DC9 is a compact, general-purpose signal relay designed for applications requiring reliable low-level switching. Measuring approximately 20.5mm in length, 10mm in width, and 11.5mm in height, this relay is suitable for high-density PCB mounting. It features a Double Pole Double Throw (DPDT) contact configuration, allowing it to control two separate circuits with two possible outputs each. With a 9V DC coil voltage and a coil resistance of 540Ω, the relay consumes approximately 150mW of power. It supports a maximum switching voltage of 125VAC or 125VDC and a contact current rating of up to 1A, making it versatile for various signal switching applications. The relay operates efficiently within a temperature range of -25°C to 70°C and is designed for through-hole PCB mounting.
G5V-2-H1 DC9

Description: The Omron G5V-2-H1 DC9 is a compact, general-purpose signal relay designed for application ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G5V-1 DC6 / The Omron G5V-1 DC9 is a compact, general-purpose signal relay designed for reliable low-level switching applications. Measuring approximately 12.5mm in length, 7.5mm in width, and 10mm in height, it is ideal for high-density PCB mounting. This relay features a Single Pole Double Throw (SPDT) contact configuration, enabling control of one circuit with two possible outputs. With a 9V DC coil voltage and a coil resistance of 540Ω, it consumes approximately 150mW of power. The G5V-1 DC9 supports a maximum switching voltage of 125VAC or 60VDC and has a contact current rating of up to 1A, making it versatile for various signal switching applications. It operates efficiently within a temperature range of -40°C to 70°C and is designed for through-hole PCB mounting.
G5V-1 DC6

Description: The Omron G5V-1 DC9 is a compact, general-purpose signal relay designed for reliable low-l ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G5V-1 DC9 / The Omron G5V-1 DC9 is a compact, general-purpose signal relay designed for reliable low-level switching applications. Measuring approximately 12.5mm in length, 7.5mm in width, and 10mm in height, it is ideal for high-density PCB mounting. This relay features a Single Pole Double Throw (SPDT) contact configuration, enabling control of one circuit with two possible outputs. With a 9V DC coil voltage and a coil resistance of 540Ω, it consumes approximately 150mW of power. The G5V-1 DC9 supports a maximum switching voltage of 125VAC or 60VDC and has a contact current rating of up to 1A, making it versatile for various signal switching applications. It operates efficiently within a temperature range of -40°C to 70°C and is designed for through-hole PCB mounting.
G5V-1 DC9

Description: The Omron G5V-1 DC9 is a compact, general-purpose signal relay designed for reliable low-l ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G5V-1-2 DC5 / The Omron G5V-1-2 DC5 is a compact, general-purpose signal relay designed for reliable low-level switching applications. Measuring approximately 12.5mm in length, 7.5mm in width, and 10mm in height, it is ideal for high-density PCB mounting. This relay features a Single Pole Double Throw (SPDT) contact configuration, enabling control of one circuit with two possible outputs. With a 5V DC coil voltage and a coil resistance of 167Ω, it consumes approximately 150mW of power. The G5V-1-2 DC5 supports a maximum switching voltage of 125VAC or 60VDC and has a contact current rating of up to 1A, making it versatile for various signal switching applications. It operates efficiently within a temperature range of -40°C to 70°C and is designed for through-hole PCB mounting.
G5V-1-2 DC5

Description: The Omron G5V-1-2 DC5 is a compact, general-purpose signal relay designed for reliable low ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G5V-13 DC12 / The Omron G5V-13 DC12 is a compact, general-purpose signal relay designed for applications requiring reliable low-level switching. Measuring approximately 12.5mm in length, 7.5mm in width, and 10mm in height, this relay is suitable for high-density PCB mounting. It features a Single Pole Double Throw (SPDT) contact configuration, allowing it to control one circuit with two possible outputs. With a 12V DC coil voltage and a coil resistance of 960Ω, the relay consumes approximately 150mW of power. It supports a maximum switching voltage of 125VAC or 60VDC and a contact current rating of up to 1A, making it versatile for various signal switching applications. The relay operates efficiently within a temperature range of -40°C to 70°C and is designed for through-hole PCB mounting.
G5V-13 DC12

Description: The Omron G5V-13 DC12 is a compact, general-purpose signal relay designed for applications ...
Package: TUBE | MOQ: 500 | MPQ: 500

G5V-13 DC5 / The Omron G5V-13 DC5 is a compact, general-purpose signal relay designed for applications requiring reliable low-level switching. Measuring approximately 12.5mm in length, 7.5mm in width, and 10mm in height, this relay is suitable for high-density PCB mounting. It features a Single Pole Double Throw (SPDT) contact configuration, allowing it to control one circuit with two possible outputs. With a 5V DC coil voltage and a coil resistance of 167Ω, the relay consumes approximately 150mW of power. It supports a maximum switching voltage of 125VAC or 60VDC and a contact current rating of up to 1A, making it versatile for various signal switching applications. The relay operates efficiently within a temperature range of -40°C to 70°C and is designed for through-hole PCB mounting.
G5V-13 DC5

Description: The Omron G5V-13 DC5 is a compact, general-purpose signal relay designed for applications ...
Package: TUBE | MOQ: 500 | MPQ: 500

G5V-1-2 DC12 / The Omron G5V-1-2 DC12 is a compact, general-purpose signal relay designed for applications requiring reliable low-level switching. Measuring approximately 12.5mm in length, 7.5mm in width, and 10mm in height, this relay is suitable for high-density PCB mounting. It features a Single Pole Double Throw (SPDT) contact configuration, allowing it to control one circuit with two possible outputs. With a 12V DC coil voltage and a coil resistance of 960Ω, the relay consumes approximately 150mW of power. It supports a maximum switching voltage of 125VAC or 60VDC and a contact current rating of up to 1A, making it versatile for various signal switching applications. The relay operates efficiently within a temperature range of -40°C to 70°C and is designed for through-hole PCB mounting.
G5V-1-2 DC12

Description: The Omron G5V-1-2 DC12 is a compact, general-purpose signal relay designed for application ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G5V-1 DC3 / The Omron G5V-1 DC3 is a compact, general-purpose signal relay designed for applications requiring reliable low-level switching. Measuring approximately 12.5mm in length, 7.5mm in width, and 10mm in height, this relay is suitable for high-density PCB mounting. It features a Single Pole Double Throw (SPDT) contact configuration, allowing it to control one circuit with two possible outputs. With a 3V DC coil voltage and a coil resistance of 60Ω, the relay consumes approximately 150mW of power. It supports a maximum switching voltage of 125VAC or 60VDC and a contact current rating of up to 1A, making it versatile for various signal switching applications. The relay operates efficiently within a temperature range of -40°C to 70°C and is designed for through-hole PCB mounting.
G5V-1 DC3

Description: The Omron G5V-1 DC3 is a compact, general-purpose signal relay designed for applications r ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6AK-274P-ST-US DC24 / The Omron G6AK-274P-ST-US-DC24 is a compact, dual-coil latching signal relay designed for low-profile PCB applications. Measuring 20.2mm in length, 10.1mm in width, and 8.4mm in height, this relay is suitable for high-density mounting. It features a DPDT (2 Form C) contact configuration, allowing it to control two separate circuits simultaneously. With a 24V DC coil voltage and a coil resistance of 3.2kΩ, the relay consumes approximately 180mW of power. It supports a maximum switching voltage of 250VAC or 220VDC and a contact current rating of up to 2A, making it versatile for various signal switching applications. The relay operates efficiently within a temperature range of -40°C to 70°C and is designed for through-hole PCB mounting.
G6AK-274P-ST-US DC24

Description: The Omron G6AK-274P-ST-US-DC24 is a compact, dual-coil latching signal relay designed for ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6AK-234P-ST-US DC5 / The Omron G6AK-234P-ST-US DC5 is a compact, dual-coil latching signal relay designed for low-profile PCB applications. Measuring 20.2mm in length, 10.1mm in width, and 8.4mm in height, this relay is suitable for high-density mounting. It features a DPDT (2 Form C) contact configuration, allowing it to control two separate circuits simultaneously. With a 5V DC coil voltage and a coil resistance of 139Ω, the relay consumes approximately 180mW of power. It supports a maximum switching voltage of 250VAC or 220VDC and a contact current rating of up to 1A, making it versatile for various signal switching applications. The relay operates efficiently within a temperature range of -40°C to 70°C and is designed for through-hole PCB mounting.
G6AK-234P-ST-US DC5

Description: The Omron G6AK-234P-ST-US DC5 is a compact, dual-coil latching signal relay designed for l ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6AK-274P-ST-US DC12 / The G6AK-274P-ST-US DC12 from Omron is a high-sensitivity SPDT power relay designed for through-hole mounting applications. It operates with a 12 VDC coil voltage and 230 mW coil power consumption. The relay is capable of switching up to 10 A at 30 VDC and 7 A at 125 VAC, making it ideal for use in industrial control systems, home appliances, and HVAC systems. Built with silver alloy contacts, it offers reliable and long-lasting operation. The relay features a 1000 VAC dielectric strength for effective insulation and fast switching times (with 10 ms operate time and 5 ms release time). Designed to function across a wide temperature range of -40°C to +85°C, this relay is suitable for a variety of environments where performance and durability are critical.
G6AK-274P-ST-US DC12

Description: The G6AK-274P-ST-US DC12 from Omron is a high-sensitivity SPDT power relay designed for th ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6EK-134P-ST-US DC5 / The G6EK-134P-ST-US DC5 from Omron is a high-sensitivity SPDT power relay designed for through-hole mounting applications that require high-power switching. It operates with a 5 VDC coil voltage and a 100 mW coil power consumption. Capable of switching 10 A at 30 VDC and 7 A at 125 VAC, the relay is suited for a wide range of applications, including industrial control systems, home appliances, and HVAC systems. The silver alloy contacts ensure reliable performance, and the 1000 VAC dielectric strength provides effective isolation between the coil and contacts. With fast switching times of 10 ms for the operate time and 5 ms for the release time, this relay is designed for fast and efficient operation in harsh environments with an operating temperature range of -40°C to +85°C.
G6EK-134P-ST-US DC5

Description: The G6EK-134P-ST-US DC5 from Omron is a high-sensitivity SPDT power relay designed for thr ...
Package: TUBE | MOQ: 125 | MPQ: 25

G6A-274P-ST15-US DC24 / The G6A-274P-ST15-US DC24 from Omron is a high-sensitivity SPDT power relay designed for through-hole mounting in high-power circuits. It operates at 24 VDC with a coil power consumption of 230 mW, and it can switch 10 A at 30 VDC and 7 A at 125 VAC. The relay features silver alloy contacts, providing durability and reliable switching over time. With a 1000 VAC dielectric strength, it offers effective insulation and safety. The relay’s fast switching speeds (with 10 ms operate time and 5 ms release time) make it well-suited for industrial control systems, home appliances, and HVAC systems. Designed to operate within -40°C to +85°C, it is durable enough for use in challenging environments.
G6A-274P-ST15-US DC24

Description: The G6A-274P-ST15-US DC24 from Omron is a high-sensitivity SPDT power relay designed for t ...
Package: T&R | MOQ: 500 | MPQ: 500

G6A-274P-ST-US DC5 / The G6A-274P-ST-US DC5 from Omron is a high-sensitivity SPDT power relay designed for through-hole mounting in high-power applications. It operates with a 5 VDC coil voltage and consumes 100 mW of coil power. This relay is capable of handling 10 A at 30 VDC and 7 A at 125 VAC, making it suitable for a wide variety of applications, such as industrial control systems, home appliances, and HVAC equipment. Featuring silver alloy contacts, the relay ensures long-term durability and reliability. The 1000 VAC dielectric strength allows for effective isolation, while the fast switching times (10 ms operate, 5 ms release) provide high-performance operation. It is designed to operate in temperatures ranging from -40°C to +85°C, making it ideal for harsh and demanding environments.
G6A-274P-ST-US DC5

Description: The G6A-274P-ST-US DC5 from Omron is a high-sensitivity SPDT power relay designed for thro ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6A-274P-ST40-US DC24 / The G6A-274P-ST40-US DC24 from Omron is a high-sensitivity SPDT power relay designed for through-hole mounting applications in high-power circuits. Operating at 24 VDC with a coil power consumption of 230 mW, this relay can handle up to 10 A at 30 VDC and 7 A at 125 VAC, making it suitable for industrial control systems, home appliances, and HVAC equipment. The relay features silver alloy contacts for enhanced durability and long life, with 1000 VAC dielectric strength for effective isolation. It has fast switching times, with an operate time of 10 ms and a release time of 5 ms, and can operate in a temperature range of -40°C to +85°C, ensuring reliability in demanding conditions.
G6A-274P-ST40-US DC24

Description: The G6A-274P-ST40-US DC24 from Omron is a high-sensitivity SPDT power relay designed for t ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6E-134PL-ST-US DC5 / The G6E-134PL-ST-US DC5 from Omron is a high-sensitivity SPDT power relay designed for through-hole mounting applications that require high-power switching. It operates with a 5 VDC coil voltage and consumes 100 mW of power. This relay can handle 10 A at 30 VDC and 7 A at 125 VAC, making it ideal for a wide range of applications, including industrial control systems, home appliances, and HVAC equipment. The silver alloy contacts provide long-term durability, while the 1000 VAC dielectric strength ensures safe and effective operation. The relay offers fast switching times of 10 ms (operate) and 5 ms (release), and it can function in an operating temperature range of -40°C to +85°C, making it suitable for demanding environments.
G6E-134PL-ST-US DC5

Description: The G6E-134PL-ST-US DC5 from Omron is a high-sensitivity SPDT power relay designed for thr ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6A-274P-ST-US DC24 / The G6A-274P-ST-US DC24 from Omron is a high-sensitivity SPDT power relay designed for through-hole mounting in applications requiring high power switching. It operates with a 24 VDC coil voltage and 230 mW coil power consumption, making it suitable for various industrial control and home appliance applications. The relay supports 10 A at 30 VDC and 7 A at 125 VAC, providing reliable and robust switching for medium-power circuits. With silver alloy contacts, it ensures durability over a long operational life. The relay is built with a 1000 VAC dielectric strength and fast switching times of 10 ms (operate) and 5 ms (release). Operating within the temperature range of -40°C to +85°C, it is suitable for use in harsh environments, offering high reliability and efficiency in industrial and HVAC systems.
G6A-274P-ST-US DC24

Description: The G6A-274P-ST-US DC24 from Omron is a high-sensitivity SPDT power relay designed for thr ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6A-274P-ST-US DC12 / The G6A-274P-ST-US DC12 from Omron is a high-sensitivity SPDT power relay designed for through-hole mounting applications in industrial control systems and home appliances. It operates with a 12 VDC coil voltage and 180 mW power consumption, making it suitable for medium-power switching applications. The relay is rated for 10 A at 30 VDC and 7 A at 125 VAC, providing reliable high-power switching. With a contact material made from silver alloy, it ensures long-term durability. The 1000 VAC dielectric strength and fast switching times (10 ms operate and 5 ms release) provide dependable performance. Designed to operate in temperatures ranging from -40°C to +85°C, this relay is suitable for use in high-demand environments such as HVAC systems and power equipment.
G6A-274P-ST-US DC12

Description: The G6A-274P-ST-US DC12 from Omron is a high-sensitivity SPDT power relay designed for thr ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6A-274P-ST40-US DC5 / The G6A-274P-ST40-US DC5 from Omron is a high-sensitivity SPDT power relay designed for through-hole mounting in applications that require high power handling. With a 5 VDC coil voltage and 140 mW power consumption, it provides efficient switching for power systems. The relay is rated for up to 10 A at 30 VDC and 7 A at 125 VAC, making it suitable for industrial control systems, home appliances, and HVAC systems. The silver alloy contacts ensure durability and reliability, while the 1000 VAC dielectric strength provides safe and effective isolation. The relay has a fast switching time, with 10 ms operation and 5 ms release, suitable for high-speed operations. With an operating temperature range of -40°C to +85°C, it performs well in demanding environments.
G6A-274P-ST40-US DC5

Description: The G6A-274P-ST40-US DC5 from Omron is a high-sensitivity SPDT power relay designed for th ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6JU-2P-Y DC5 / The G6JU-2P-Y DC5 from Omron is a high-sensitivity SPDT relay designed for surface-mount applications. It operates with a 5 VDC coil voltage and a low 130 mW power consumption, making it suitable for low-power applications. With a contact rating of 1 A at 30 VDC and 0.3 A at 125 VAC, this relay is ideal for telecommunications, medical devices, and industrial control systems. The gold-clad silver alloy contacts provide long-term reliability, while the 3 ms operate and 3 ms release times ensure efficient switching. The wide operating temperature range of -40°C to +85°C makes it suitable for use in various environments, offering high performance and durability.
G6JU-2P-Y DC5

Description: The G6JU-2P-Y DC5 from Omron is a high-sensitivity SPDT relay designed for surface-mount a ...
Package: T&R | MOQ: 1000 | MPQ: 1000

G6E-134P-ST-US DC24 / The G6E-134P-ST-US DC24 from Omron is a high-sensitivity SPDT power relay designed for through-hole mounting in various industrial control systems and home appliances. It operates with a 24 VDC coil voltage and 250 mW power consumption, making it ideal for power switching applications. The relay can handle up to 10 A at 30 VDC and 7 A at 125 VAC, providing reliable switching for high-power devices. The 1000 VAC dielectric strength and fast switching times (10 ms operate, 5 ms release) ensure efficient and secure operation. The wide operating temperature range of -40°C to +85°C allows it to perform in demanding environments, such as HVAC systems and power equipment.
G6E-134P-ST-US DC24

Description: The G6E-134P-ST-US DC24 from Omron is a high-sensitivity SPDT power relay designed for thr ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6E-134P-ST-US DC12 / The G6E-134P-ST-US DC12 from Omron is a high-sensitivity SPDT power relay designed for through-hole mounting in industrial control systems and home appliances. It operates with a 12 VDC coil voltage and 250 mW power consumption, providing an efficient solution for power switching. The relay can handle up to 10 A at 30 VDC and 7 A at 125 VAC, offering significant power handling capability. With a 1000 VAC dielectric strength and fast switching times of 10 ms (operate) and 5 ms (release), the relay is built for reliable operation in demanding environments. The wide operating temperature range of -40°C to +85°C ensures it can be used in various industrial and HVAC applications.
G6E-134P-ST-US DC12

Description: The G6E-134P-ST-US DC12 from Omron is a high-sensitivity SPDT power relay designed for thr ...
Package: TUBE | MOQ: 1250 | MPQ: 25

G6J-2P-Y DC24 / The G6J-2P-Y DC24 from Omron is a high-sensitivity SPDT relay designed for surface-mount applications. Operating with a 24 VDC coil voltage and 170 mW power consumption, it is suitable for low-power applications requiring reliable switching. With a contact rating of 1 A at 30 VDC and 0.3 A at 125 VAC, the relay can be used effectively in a variety of electronic devices. The gold-clad silver alloy contacts offer durability, and the fast 3 ms switching time ensures efficiency in telecommunication, medical, and industrial systems. With a wide operating temperature range of -40°C to +85°C, this relay is ideal for demanding environments.
G6J-2P-Y DC24

Description: The G6J-2P-Y DC24 from Omron is a high-sensitivity SPDT relay designed for surface-mount a ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6J-2FS-Y-TR DC12 / The G6J-2FS-Y-TR DC12 from Omron is a high-sensitivity SPDT relay designed for surface-mount applications. With a 12 VDC coil voltage and 150 mW power consumption, it is suitable for low-power applications. The relay offers a contact rating of 1 A at 30 VDC and 0.3 A at 125 VAC, ensuring reliable switching in various telecommunication and industrial control systems. The gold-clad silver alloy contacts ensure durability and efficiency, while the fast 3 ms switching time makes it ideal for high-speed operations. The wide operating temperature range of -40°C to +85°C ensures it functions reliably in demanding environments.
G6J-2FS-Y-TR DC12

Description: The G6J-2FS-Y-TR DC12 from Omron is a high-sensitivity SPDT relay designed for surface-mou ...
Package: T&R | MOQ: 400 | MPQ: 400

G6KU-2F-Y-TR DC3 / The G6KU-2F-Y-TR DC3 from Omron is a compact, ultra-miniature DPDT relay designed for surface-mount applications, making it perfect for space-constrained electronic systems. Operating with a 3 VDC coil voltage and consuming just 70 mW of power, it is well-suited for low-power applications. The relay offers a contact rating of 1 A at 30 VDC and 0.3 A at 125 VAC, ensuring reliable switching for various devices. With gold-clad silver alloy contacts, it is durable and efficient. The 3 ms switching time and wide operating temperature range (-40°C to +85°C) make it versatile for use in telecommunications, medical devices, measurement instruments, and industrial control.
G6KU-2F-Y-TR DC3

Description: The G6KU-2F-Y-TR DC3 from Omron is a compact, ultra-miniature DPDT relay designed for surf ...
Package: T&R | MOQ: 900 | MPQ: 900

G6SK-2F-TR DC12 / The G6SK-2F-TR DC12 from Omron is a high-sensitivity SPDT relay designed for surface-mount applications, offering compactness and reliability in various electronic systems. With a 12 VDC coil voltage and 100 mW power consumption, it is ideal for low-power designs. The relay supports a contact rating of 1 A at 30 VDC and 0.3 A at 125 VAC, making it suitable for use in telecommunications, medical devices, measurement instruments, and industrial control systems. With gold-clad silver alloy contacts, this relay provides reliable switching and fast operation with 3 ms switching times. It also offers a wide operating temperature range (-40°C to +85°C) for use in demanding environments.
G6SK-2F-TR DC12

Description: The G6SK-2F-TR DC12 from Omron is a high-sensitivity SPDT relay designed for surface-mount ...
Package: T&R | MOQ: 800 | MPQ: 800

G6SK-2F DC5 / The G6SK-2F DC5 from Omron is a high-sensitivity SPDT relay designed for surface-mount applications, offering compactness and high reliability for a wide range of electronic devices. It operates with a 5 VDC coil voltage and consumes 75 mW of power, making it efficient for low-power designs. With gold-clad silver alloy contacts, the relay offers 1 A at 30 VDC and 0.3 A at 125 VAC, ideal for use in telecommunications, measurement instruments, medical devices, and industrial control systems. The fast switching time of 3 ms and wide operating temperature range (-40°C to +85°C) make this relay versatile and reliable in demanding environments.
G6SK-2F DC5

Description: The G6SK-2F DC5 from Omron is a high-sensitivity SPDT relay designed for surface-mount app ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6KU-2G-Y-TR DC3 / The G6KU-2G-Y-TR DC3 from Omron is a compact, ultra-miniature DPDT relay designed for surface-mount applications, making it ideal for space-constrained electronic systems. Operating with a 3 VDC coil voltage and consuming just 70 mW of power, it is suitable for low-power applications. The relay offers a contact rating of 1 A at 30 VDC and 0.3 A at 125 VAC, and it ensures reliable switching with gold-clad silver alloy contacts. It features fast switching times of 3 ms and is rated for 30 VA (AC) and 30 W (DC) switching capacity. The wide temperature range (-40°C to +85°C) ensures versatility in diverse environments, from telecommunications to medical and industrial equipment.
G6KU-2G-Y-TR DC3

Description: The G6KU-2G-Y-TR DC3 from Omron is a compact, ultra-miniature DPDT relay designed for surf ...
Package: T&R | MOQ: 900 | MPQ: 900

G6SK-2F-TR DC5 / The G6SK-2F-TR DC5 from Omron is a high-sensitivity SPDT relay designed for surface-mount applications, making it an ideal solution for compact and high-density circuits. It operates with a 5 VDC coil voltage and features 75 mW power consumption, ensuring efficiency in low-power designs. With gold-clad silver alloy contacts, the relay supports 1 A at 30 VDC and 0.3 A at 125 VAC, making it suitable for use in telecommunications, medical devices, measurement systems, and industrial control. The fast switching time of 3 ms and reliable contact material ensure durability, while its wide operating temperature range (-40°C to +85°C) makes it a versatile component for various demanding environments.
G6SK-2F-TR DC5

Description: The G6SK-2F-TR DC5 from Omron is a high-sensitivity SPDT relay designed for surface-mount ...
Package: T&R | MOQ: 400 | MPQ: 400

G6J-2P-Y DC5 / The G6J-2P-Y DC5 from Omron is a high-sensitivity SPDT relay designed for surface-mount applications, offering compactness and high reliability in various devices. It operates with a 5 VDC coil voltage and consumes 75 mW of power, making it efficient for low-power applications. The relay supports 1 A at 30 VDC and 0.3 A at 125 VAC, ideal for telecommunications, measurement systems, and medical devices. The gold-clad silver alloy contacts ensure long-lasting durability, and with fast switching times (3 ms max), it offers efficient operation. The wide operating temperature range (-40°C to +85°C) makes this relay suitable for various industrial and electronic environments.
G6J-2P-Y DC5

Description: The G6J-2P-Y DC5 from Omron is a high-sensitivity SPDT relay designed for surface-mount ap ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6J-2FS-Y DC5 / The G6J-2FS-Y DC5 from Omron is a high-sensitivity SPDT relay designed for surface-mount applications, making it ideal for compact and high-density circuit boards. Operating with a 5 VDC coil voltage, it has a low power consumption of 75 mW. With gold-clad silver alloy contacts, it ensures reliable switching in applications such as telecommunications, measurement instruments, and medical devices. This relay offers high switching capacity of 1 A at 30 VDC and 0.3 A at 125 VAC, with fast switching times of 3 ms. Its compact design and wide temperature range (-40°C to +85°C) make it a robust and reliable component for various demanding applications.
G6J-2FS-Y DC5

Description: The G6J-2FS-Y DC5 from Omron is a high-sensitivity SPDT relay designed for surface-mount a ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6SK-2F DC3 / The G6SK-2F DC3 from Omron is an ultra-miniature DPDT relay designed for surface-mount applications. It operates with a 3 VDC coil voltage and has a low power consumption of 100 mW. With a high switching capacity of 1 A at 30 VDC and 0.3 A at 125 VAC, it is ideal for use in telecommunications, industrial automation, and precision measurement applications. The gold-clad silver alloy contacts ensure high reliability and a long lifespan, while the fast switching time of 3 ms max enhances efficiency. With a compact design and wide operating temperature range (-40°C to +85°C), it is well-suited for demanding electronic systems and environments.
G6SK-2F DC3

Description: The G6SK-2F DC3 from Omron is an ultra-miniature DPDT relay designed for surface-mount app ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6KU-2F-Y DC5 / The G6KU-2F-Y DC5 from Omron is an ultra-miniature DPDT relay designed for surface-mount applications, making it ideal for high-density PCB designs. It operates with a 5 VDC coil voltage and features low power consumption of 90 mW. With a high switching capacity of 1 A at 30 VDC and 0.3 A at 125 VAC, it is typically used in telecommunications, industrial automation, and precision measurement systems. The gold-clad silver alloy contacts provide enhanced reliability and durability, while the fast switching time (3 ms max) ensures efficient performance. Its compact design and wide operating temperature range (-40°C to +85°C) make it well-suited for use in demanding applications.
G6KU-2F-Y DC5

Description: The G6KU-2F-Y DC5 from Omron is an ultra-miniature DPDT relay designed for surface-mount a ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6KU-2F-Y-TR DC5 / The G6KU-2F-Y-TR DC5 from Omron is an ultra-miniature DPDT relay designed for surface-mount applications, making it ideal for high-density PCB designs. It operates with a 5 VDC coil voltage and has a low power consumption of 90 mW. With a high switching capacity of 1 A at 30 VDC and 0.3 A at 125 VAC, it is commonly used in telecommunications, industrial automation, and precision measurement applications. The gold-clad silver alloy contacts ensure high reliability and a long lifespan, while the fast switching time of 3 ms max provides efficient operation. Its compact design and wide operating temperature range (-40°C to +85°C) make it a robust solution for various demanding environments.
G6KU-2F-Y-TR DC5

Description: The G6KU-2F-Y-TR DC5 from Omron is an ultra-miniature DPDT relay designed for surface-moun ...
Package: T&R | MOQ: 900 | MPQ: 900

G6KU-2F-Y-TR DC4.5 / The G6KU-2F-Y-TR DC4.5 from Omron is an ultra-miniature DPDT relay designed for surface-mount applications, making it ideal for high-density PCB designs. It operates with a 4.5 VDC coil voltage and has a low power consumption of 100 mW. With a high switching capacity of 1 A at 30 VDC and 0.3 A at 125 VAC, it is commonly used in telecommunications, industrial automation, and precision measurement applications. The gold-clad silver alloy contacts ensure high reliability and a long lifespan, while the fast switching time of 3 ms max provides efficient operation. Its compact design and wide operating temperature range (-40°C to +85°C) make it a robust solution for various demanding environments.
G6KU-2F-Y-TR DC4.5

Description: The G6KU-2F-Y-TR DC4.5 from Omron is an ultra-miniature DPDT relay designed for surface-mo ...
Package: T&R | MOQ: 900 | MPQ: 900

G6KU-2F-Y DC3 / The G6KU-2F-Y DC3 from Omron is an ultra-miniature DPDT relay designed for surface-mount applications, featuring a 3 VDC coil voltage and low power consumption of 100 mW. This compact relay is ideal for telecommunications, industrial automation, and precision measurement instruments, thanks to its high switching reliability and gold-clad silver alloy contacts. With a fast switching time of 3 ms max and a wide operating temperature range (-40°C to +85°C), it ensures efficient and stable performance in various electronic systems.
G6KU-2F-Y DC3

Description: The G6KU-2F-Y DC3 from Omron is an ultra-miniature DPDT relay designed for surface-mount a ...
Package: T&R | MOQ: 500 | MPQ: 500

G6S-2F-Y DC24 / The G6S-2F-Y DC24 from Omron is a miniature DPDT relay designed for surface-mount applications, making it ideal for high-density PCB designs. It operates with a 24 VDC coil voltage and has a low power consumption of 200 mW. With a high switching capacity of 2 A at 30 VDC and 0.5 A at 125 VAC, it is commonly used in telecommunications, industrial automation, and precision measurement applications. The gold-clad silver alloy contacts ensure high reliability and a long lifespan, while the fast switching time of 3 ms max provides efficient operation. Its compact design and wide operating temperature range (-40°C to +85°C) make it a robust solution for various demanding environments.
G6S-2F-Y DC24

Description: The G6S-2F-Y DC24 from Omron is a miniature DPDT relay designed for surface-mount applicat ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6S-2 DC24 / The G6S-2 DC24 from Omron is a compact DPDT relay designed for through-hole mounting, featuring a 24 VDC coil voltage and low power consumption of 200 mW. With a high switching capacity of up to 2 A at 30 VDC and 0.5 A at 125 VAC, it is well-suited for telecommunications, industrial automation, and precision measurement instruments. The gold-clad silver alloy contacts ensure high reliability and long operational life, while the fast switching time of 3 ms max makes it ideal for high-speed applications. Its small footprint and wide operating temperature range (-40°C to +85°C) allow for use in various environments, making it a versatile choice for demanding applications.
G6S-2 DC24

Description: The G6S-2 DC24 from Omron is a compact DPDT relay designed for through-hole mounting, feat ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6K-2G-TR DC12 / The G6K-2G-TR DC12 from Omron is a miniature DPDT relay designed for surface-mount applications, featuring a 12 VDC coil voltage and low power consumption of 100 mW. It is widely used in telecommunications, industrial automation, medical devices, and precision measurement instruments. With its compact size, fast switching speed (3 ms max), and gold-clad silver alloy contacts, it ensures high switching reliability and long lifespan. The wide operating temperature range (-40°C to +85°C) makes it highly adaptable for use in various environments.
G6K-2G-TR DC12

Description: The G6K-2G-TR DC12 from Omron is a miniature DPDT relay designed for surface-mount applica ...
Package: T&R | MOQ: 900 | MPQ: 900

G6S-2F-TR DC24 / The G6S-2F-TR DC24 from Omron is a miniature DPDT relay designed for surface-mount applications. It features a 24 VDC coil voltage, low power consumption of 200 mW, and a maximum contact rating of 2 A for DC circuits and 0.5 A for AC circuits. Its fast switching time (3 ms max) and high insulation resistance (1000 MΩ min) make it an excellent choice for telecommunications, industrial control, and medical equipment. The compact and lightweight design allows for easy integration into high-density PCB layouts, while its wide operating temperature range (-40°C to +85°C) ensures stable performance in various environmental conditions.
G6S-2F-TR DC24

Description: The G6S-2F-TR DC24 from Omron is a miniature DPDT relay designed for surface-mount applica ...
Package: T&R | MOQ: 400 | MPQ: 400

G6K-2F-Y-TR DC4.5 / The G6K-2F-Y-TR DC4.5 from Omron is a miniature DPDT relay designed for surface-mount applications, featuring a 4.5 VDC coil voltage and low power consumption of 75 mW. It is ideal for use in telecommunications, industrial automation, medical devices, and measurement equipment. With fast response times (3 ms max) and high switching reliability, it is well-suited for high-density PCB designs. The compact size and wide operating temperature range (-40°C to +85°C) ensure stable performance in various electronic systems.
G6K-2F-Y-TR DC4.5

Description: The G6K-2F-Y-TR DC4.5 from Omron is a miniature DPDT relay designed for surface-mount appl ...
Package: T&R | MOQ: 900 | MPQ: 900

G6K-2F-Y-TR DC12 / The G6K-2F-Y-TR DC12 from Omron is a miniature DPDT relay designed for surface-mount applications. It features a 12 VDC coil voltage, a 1 A contact rating for DC, and 0.3 A for AC switching, making it ideal for telecommunications, industrial automation, and precision measurement devices. Its ultra-compact size, fast response time, and low power consumption make it highly suitable for high-density PCB designs. The relay operates within a wide temperature range of -40°C to +85°C, ensuring reliability in demanding environments.
G6K-2F-Y-TR DC12

Description: The G6K-2F-Y-TR DC12 from Omron is a miniature DPDT relay designed for surface-mount appli ...
Package: T&R | MOQ: 900 | MPQ: 900

G6K-2G DC24 / The G6K-2G DC24 from Omron is a miniature SPDT relay designed for low-power switching applications with a 24 VDC coil voltage. It features a 1 A contact rating for both AC and DC circuits, making it ideal for telecommunications equipment, industrial control systems, and consumer electronics. With its compact size, fast switching speed, and wide operating temperature range of -40°C to +85°C, it is well-suited for space-constrained and high-reliability applications.
G6K-2G DC24

Description: The G6K-2G DC24 from Omron is a miniature SPDT relay designed for low-power switching appl ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6K-2P DC4.5 / The G6K-2P DC4.5 from Omron is a miniature SPDT relay designed for low-power switching with a 4.5 VDC coil voltage. It features a 1 A contact rating for both AC and DC circuits, making it suitable for a wide range of applications such as automotive systems, consumer electronics, and control circuits. With its compact design and fast switching capabilities, it provides reliable performance in high-density and space-constrained applications. The relay also operates within a wide temperature range of -40°C to +85°C, ensuring versatility and reliability in various environments.
G6K-2P DC4.5

Description: The G6K-2P DC4.5 from Omron is a miniature SPDT relay designed for low-power switching wit ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6K-2G-Y DC3 / The G6K-2G-Y DC3 from Omron is a miniature SPDT relay that operates with a 3 VDC coil voltage. It is designed for low-power switching applications, offering a 0.5 A contact rating for both AC and DC circuits. This relay is typically used in automotive systems, consumer electronics, and control circuits, providing reliable switching with fast operate and release times. Its compact design and wide operating temperature range of -40°C to +85°C make it an ideal choice for a variety of applications.
G6K-2G-Y DC3

Description: The G6K-2G-Y DC3 from Omron is a miniature SPDT relay that operates with a 3 VDC coil volt ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6K-2G-Y DC5 / The G6K-2G-Y DC5 from Omron is a miniature SPDT relay designed for low-power applications with a 5 VDC coil voltage. It offers a 1 A contact rating for both AC and DC circuits, making it suitable for use in automotive systems, consumer electronics, and control circuits. With its compact size, reliable switching, and wide operating temperature range of -40°C to +85°C, this relay is ideal for demanding environments. It also features fast operate and release times, ensuring high-speed switching in various applications.
G6K-2G-Y DC5

Description: The G6K-2G-Y DC5 from Omron is a miniature SPDT relay designed for low-power applications ...
Package: TUBE | MOQ: 1250 | MPQ: 50

G6K-2P-Y DC4.5 / The G6K-2P-Y DC4.5 from Omron is a miniature SPDT relay designed for low-power applications with a 4.5 VDC coil voltage. It features a 1 A contact rating for both AC and DC switching, making it ideal for use in automotive systems, consumer electronics, and control circuits. With a 5 ms operate time and wide operating temperature range of -40°C to +85°C, the relay ensures efficient and reliable switching in compact designs.
G6K-2P-Y DC4.5

Description: The G6K-2P-Y DC4.5 from Omron is a miniature SPDT relay designed for low-power application ...
Package: TUBE | MOQ: 1250 | MPQ: 50
