H5TC4G63CFR-PBA / The H5TC4G63CFR-PBA is a high-performance 4Gbit DDR3L SDRAM memory IC developed by SK Hynix, designed for embedded systems, industrial electronics, and high-speed computing applications. It features a memory organization of 256M × 16 bits, enabling efficient parallel data transfer and high bandwidth performance.<br><br>The device operates using DDR3L technology (low-voltage DDR3) with a typical supply voltage of 1.35V, providing reduced power consumption while maintaining high-speed performance. It supports data rates up to approximately 1600 Mbps (800 MHz clock), making it suitable for applications requiring fast and reliable memory access.<br><br>Built on an advanced 8-bank architecture with 8n prefetch, the H5TC4G63CFR-PBA enables efficient concurrent memory operations and improved system throughput. It supports key features such as programmable CAS latency (CL5–CL13), burst lengths (4/8), auto-refresh, and self-refresh, ensuring stable and flexible memory management.<br><br>The device incorporates a fully synchronous interface with differential clocking (CK/CK#) and data strobes (DQS), ensuring signal integrity and reliable operation at high frequencies. It also includes advanced functions such as on-chip DLL alignment, data masking (DM), and on-die termination (ODT), improving performance and simplifying high-speed PCB design.<br><br>Packaged in a compact 96-ball FBGA form factor, the H5TC4G63CFR-PBA is optimized for high-density PCB layouts and space-constrained applications. It operates across commercial and industrial temperature ranges (up to +95°C), ensuring reliable performance in demanding environments.<br><br>The H5TC4G63CFR-PBA is widely used in applications such as embedded systems, networking equipment, industrial automation, consumer electronics, telecommunications, and FPGA/SoC memory expansion, where high-speed and low-power volatile memory is essential.
H5TC4G63CFR-PBA

Description: The H5TC4G63CFR-PBA is a high-performance 4Gbit DDR3L SDRAM memory IC developed by SK Hyni ...
Package: T&R | MOQ: 1000 | MPQ: 1000

IS46LR16320C-6BLA1 / The IS46LR16320C-6BLA1 is a high-performance 512Mbit Mobile DDR SDRAM (LPDDR) developed by Integrated Silicon Solution Inc. (ISSI), designed for low-power, high-speed embedded applications. It features a memory organization of 32M × 16 bits, enabling efficient parallel data transfer and high bandwidth operation.<br><br>This device operates at clock frequencies up to 166 MHz with a fast access time of approximately 5.5 ns, providing reliable performance for memory-intensive applications. It utilizes a double data rate (DDR) architecture, transferring data on both rising and falling edges of the clock to maximize throughput.<br><br>Designed for low-power systems, the IS46LR16320C-6BLA1 operates within a supply voltage range of 1.7V to 1.95V (typ. 1.8V), making it ideal for battery-powered and portable devices. It incorporates power-saving features and efficient memory management functions to reduce overall system consumption.<br><br> Internally, the memory is organized into 4 banks, allowing concurrent operations and improved data throughput. It supports advanced features such as burst read/write operations, programmable CAS latency, auto-refresh, self-refresh, and data masking, ensuring stable and efficient performance in dynamic environments.<br><br>The device uses a parallel interface with 16-bit data bus, and includes differential clocking and data strobe (DQS) signals to ensure signal integrity at high speeds. It is housed in a compact 60-ball TFBGA package, optimized for high-density PCB layouts and space-constrained designs.<br><br>With an operating temperature range of -40°C to +85°C, the IS46LR16320C-6BLA1 is suitable for industrial and automotive-grade applications.<br><br>The IS46LR16320C-6BLA1 is widely used in applications such as embedded systems, industrial automation, portable devices, networking equipment, automotive electronics, and IoT systems, where low power consumption and reliable high-speed volatile memory are essential.
IS46LR16320C-6BLA1

Description: The IS46LR16320C-6BLA1 is a high-performance 512Mbit Mobile DDR SDRAM (LPDDR) developed by ...
Package: | MOQ: | MPQ:

H5TC4G63AFR-PBA / The H5TC4G63AFR-PBA is a high-performance 4Gbit DDR3L SDRAM memory IC developed by SK Hynix, designed for embedded systems, industrial electronics, and high-speed computing applications. It features a memory organization of 256M × 16 bits, enabling efficient parallel data transfer and high bandwidth operation.<br><br>The device utilizes DDR3L (low-voltage DDR3) technology, operating at a typical supply voltage of 1.35V, which significantly reduces power consumption compared to standard DDR3 memory while maintaining high-speed performance. It supports data rates up to approximately 1600 Mbps (800 MHz clock), making it suitable for demanding applications requiring fast and reliable memory access.<br><br>Built on an advanced 8-bank architecture with 8n prefetch, the H5TC4G63AFR-PBA enables efficient concurrent operations and improved memory throughput. It supports key features such as programmable CAS latency, burst read/write operations, auto-refresh, and self-refresh, ensuring stable and efficient memory management in dynamic systems.<br><br>The device incorporates a fully synchronous interface with differential clocking and data strobe (DQS), ensuring signal integrity and reliable operation at high frequencies. Additional features such as on-die termination (ODT) and calibration functions help simplify high-speed PCB design and improve system stability.<br><br>Packaged in a compact 96-ball FBGA form factor, the H5TC4G63AFR-PBA is optimized for high-density PCB layouts and space-constrained applications.<br><br>The H5TC4G63AFR-PBA is widely used in applications such as embedded systems, networking equipment, industrial automation, consumer electronics, communication devices, and FPGA/SoC memory expansion, where high-speed and low-power volatile memory is essential.
H5TC4G63AFR-PBA

Description: The H5TC4G63AFR-PBA is a high-performance 4Gbit DDR3L SDRAM memory IC developed by SK Hyni ...
Package: T&R | MOQ: 250 | MPQ: 250

H5TC2G63FFR-PBA / The H5TC2G63FFR-PBA is a high-performance 2Gbit DDR3L SDRAM memory IC developed by SK Hynix, designed for embedded systems, industrial applications, and high-speed computing platforms. It features a memory organization of 128M × 16 bits, enabling efficient parallel data transfer and high bandwidth performance.<br><br>The device operates using DDR3L (low-voltage DDR3) technology with a typical supply voltage of 1.35V, offering reduced power consumption while maintaining high-speed operation. It supports data rates up to 1600 Mbps, making it suitable for demanding applications requiring fast and reliable memory access.<br><br>Built on an advanced multi-bank architecture (8 banks) with 8n prefetch, the H5TC2G63FFR-PBA enables efficient parallel operations and improved memory throughput. It supports key features such as burst read/write operations, programmable CAS latency, auto-refresh, and self-refresh, ensuring stable and efficient memory management.<br><br>The device utilizes a fully synchronous interface with differential clocking and data strobe (DQS), ensuring signal integrity and reliable operation at high frequencies. Additional features such as on-die termination (ODT), ZQ calibration, and DLL alignment enhance performance and simplify high-speed PCB design.<br><br>Packaged in a compact 96-ball FBGA form factor, the H5TC2G63FFR-PBA is optimized for high-density layouts and space-constrained applications. It is widely used in applications such as embedded systems, networking equipment, industrial automation, consumer electronics, and communication devices, where high-speed, low-power volatile memory is essential.
H5TC2G63FFR-PBA

Description: The H5TC2G63FFR-PBA is a high-performance 2Gbit DDR3L SDRAM memory IC developed by SK Hyni ...
Package: T&R | MOQ: 1000 | MPQ: 1000

H5TC2G63EFR-PBA / The H5TC2G63EFR-PBA is a high-performance 2Gbit DDR3L SDRAM memory IC developed by SK Hynix, designed for embedded systems, industrial electronics, and high-speed computing applications. It features a memory organization of 128M × 16 bits, enabling efficient parallel data transfer and high bandwidth operation.<br><br>The device utilizes DDR3L (low-voltage DDR3) technology, operating at a typical supply voltage of 1.35V, which significantly reduces power consumption compared to standard DDR3 memory while maintaining high-speed performance. It supports data rates up to approximately 1600 Mbps, making it suitable for demanding applications requiring fast and reliable memory access.<br><br>Built on an advanced 8-bank architecture with 8n prefetch, the H5TC2G63EFR-PBA allows efficient concurrent operations and improved memory throughput. It supports key features such as programmable CAS latency, burst read/write operations, auto-refresh, and self-refresh, ensuring stable and efficient memory management in dynamic systems.<br><br>The device incorporates a fully synchronous interface with differential clocking and data strobe (DQS), ensuring signal integrity and reliable operation at high frequencies. Additional features such as on-die termination (ODT), ZQ calibration, and DLL alignment further enhance performance and simplify high-speed PCB design.<br><br>Packaged in a compact 96-ball FBGA form factor, the H5TC2G63EFR-PBA is optimized for high-density layouts and space-constrained applications. It typically operates across commercial and industrial temperature ranges, making it suitable for robust environments.<br><br>The H5TC2G63EFR-PBA is widely used in applications such as embedded systems, industrial automation, networking equipment, consumer electronics, communication devices, and FPGA/SoC memory expansion, where high-speed, low-power volatile memory is essential.
H5TC2G63EFR-PBA

Description: The H5TC2G63EFR-PBA is a high-performance 2Gbit DDR3L SDRAM memory IC developed by SK Hyni ...
Package: T&R | MOQ: 1000 | MPQ: 1000

H5TC2G63AFR-PBA / The H5TC2G63AFR-PBA is a high-performance 2Gbit DDR3L SDRAM memory IC developed by SK Hynix, designed for embedded systems, industrial applications, and high-speed computing platforms. It features a memory organization of 128M × 16 bits, enabling efficient parallel data transfer and high bandwidth operation.<br><br>The device operates using DDR3L technology with a typical supply voltage of 1.35V, providing improved power efficiency compared to standard DDR3 memory while maintaining high-speed performance. It supports data rates up to 1600 Mbps, making it suitable for applications requiring fast memory access and high throughput.<br><br>Built on an advanced multi-bank architecture (typically 8 banks), the H5TC2G63AFR-PBA enables concurrent memory operations and optimized bandwidth. It supports features such as burst read/write operations, programmable CAS latency, auto-refresh, and self-refresh, ensuring reliable and efficient memory management in dynamic systems.<br><br>The device utilizes a fully synchronous interface with differential clocking and data strobes (DQS), ensuring signal integrity and stable operation at high frequencies. Additional features such as on-die termination (ODT), ZQ calibration, and DLL alignment enhance performance and simplify system design in high-speed environments.<br><br>Packaged in a compact 96-ball FBGA form factor, the H5TC2G63AFR-PBA is optimized for high-density PCB layouts and space-constrained applications. It is widely used in applications such as embedded systems, networking equipment, industrial automation, consumer electronics, and communication devices, where reliable high-speed volatile memory is essential.
H5TC2G63AFR-PBA

Description: The H5TC2G63AFR-PBA is a high-performance 2Gbit DDR3L SDRAM memory IC developed by SK Hyni ...
Package: T&R | MOQ: 1000 | MPQ: 1000

H5TC1G63EFR-PBA / The H5TC1G63EFR-PBA is a high-performance 1Gbit DDR3L SDRAM memory IC developed by SK Hynix, designed for high-speed embedded and computing applications. It features a memory organization of 64M × 16 bits, enabling efficient parallel data transfer and high bandwidth operation.<br><br>The device operates using DDR3L technology (low voltage DDR3) with a typical supply voltage of 1.35V, offering improved power efficiency compared to standard DDR3 memory while maintaining high-speed performance. It supports clock frequencies up to approximately 800 MHz (1600 Mbps data rate), making it suitable for demanding applications requiring fast data access.<br><br>Built on a multi-bank architecture (8 banks) with page burst access, the H5TC1G63EFR-PBA enables efficient memory operations and improved throughput. It supports advanced features such as auto-refresh, self-refresh, burst read/write operations, and programmable latency, ensuring reliable performance in dynamic memory environments.<br><br>The device utilizes a fully synchronous interface with differential clocking and data strobes, ensuring signal integrity and stable high-speed operation. It also includes features such as on-die termination (ODT), ZQ calibration, and data masking, which enhance reliability and simplify system design in high-frequency applications.<br><br>Packaged in a compact 96-ball FBGA form factor, the H5TC1G63EFR-PBA is optimized for high-density PCB layouts and space-constrained designs. It is widely used in applications such as embedded systems, networking equipment, industrial controllers, consumer electronics, and communication systems, where high-speed volatile memory and low power consumption are essential.
H5TC1G63EFR-PBA

Description: The H5TC1G63EFR-PBA is a high-performance 1Gbit DDR3L SDRAM memory IC developed by SK Hyni ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AS4C8M16SA-7TCN / The AS4C8M16SA-7TCN is a high-speed 128Mbit synchronous DRAM (SDRAM) developed by Alliance Memory, designed for embedded systems and high-performance digital applications. It features a memory organization of 8M × 16 bits, providing efficient parallel data access for processors, FPGAs, and SoC-based systems.<br><br>The device operates at a maximum clock frequency of 143 MHz with an access time of approximately 5.4 ns, enabling fast data transfer and low-latency performance in memory-intensive applications.<br><br>Built on a fully synchronous architecture, all inputs and outputs are registered on the rising edge of the clock signal, ensuring stable timing and predictable system behavior. Internally, the SDRAM is organized into 4 banks (2M × 16 per bank), allowing concurrent operations and improved bandwidth efficiency.<br><br>The AS4C8M16SA-7TCN supports burst-oriented read and write operations, programmable burst lengths, and selectable CAS latency, enabling flexible optimization for different system requirements. It also includes advanced features such as auto-refresh, self-refresh, and power-down modes, ensuring data integrity while reducing system power consumption.<br><br>Operating within a supply voltage range of 3.0V to 3.6V (typ. 3.3V), the device is compatible with standard embedded and digital systems. It is housed in a compact 54-pin TSOP-II package, making it suitable for space-constrained PCB designs.<br><br>The AS4C8M16SA-7TCN is widely used in applications such as embedded systems, industrial automation, networking equipment, consumer electronics, display controllers, and FPGA/SoC memory expansion, where reliable and high-speed volatile memory is required.
AS4C8M16SA-7TCN

Description: The AS4C8M16SA-7TCN is a high-speed 128Mbit synchronous DRAM (SDRAM) developed by Alliance ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AS4C64M16SA-7TCN / The AS4C64M16SA-7TCN is a high-density 1Gbit synchronous DRAM (SDRAM) developed by Alliance Memory, designed for embedded systems and high-performance digital applications requiring large-capacity volatile memory. It features a memory organization of 64M × 16 bits and a parallel interface for efficient high-speed data transfer.<br><br>The device operates at a maximum clock frequency of approximately 143 MHz with a typical access time of ~5.4 ns, enabling reliable performance in memory-intensive applications.<br><br>Built on a fully synchronous architecture, all inputs and outputs are registered on the clock edge, ensuring stable timing and predictable system behavior. Internally, the SDRAM utilizes a multi-bank (typically 4-bank) structure, allowing interleaved access and improved bandwidth efficiency.<br><br>The AS4C64M16SA-7TCN supports advanced memory features including programmable burst lengths (1, 2, 4, 8, full page), CAS latency (CL2/CL3), and sequential/interleaved burst modes, enabling flexible optimization for different system designs. It also includes auto-refresh, self-refresh, and power-down modes, ensuring data integrity while reducing overall system power consumption.<br><br>Operating within a supply voltage range of 3.0V to 3.6V (typ. 3.3V), the device is compatible with standard embedded and digital systems. It is housed in a compact 54-pin TSOP-II package, making it suitable for space-constrained PCB layouts.<br><br>The AS4C64M16SA-7TCN is widely used in applications such as embedded systems, industrial automation, networking equipment, display controllers, multimedia systems, and FPGA/SoC memory expansion, where reliable, high-speed, and high-capacity volatile memory is required.
AS4C64M16SA-7TCN

Description: The AS4C64M16SA-7TCN is a high-density 1Gbit synchronous DRAM (SDRAM) developed by Allianc ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AS4C64M16SA-6TCN / The AS4C64M16SA-6TCN is a high-density 1Gbit synchronous DRAM (SDRAM) developed by Alliance Memory, designed for embedded systems and high-performance digital applications requiring large volatile memory capacity. It features a memory organization of 64M × 16 bits, enabling efficient parallel data transfer and high bandwidth operation.<br><br>The device supports clock frequencies up to approximately 166 MHz, delivering fast data throughput and reliable performance for memory-intensive applications such as networking equipment, industrial control systems, and FPGA-based designs. It utilizes a fully synchronous architecture, where all inputs and outputs are registered on the clock edge, ensuring stable timing and predictable system behavior.<br><br>Internally, the SDRAM is organized into multiple banks (typically 4-bank architecture), allowing interleaved operations and improved memory efficiency. It supports burst read/write operations, programmable burst lengths, and selectable CAS latency, enabling flexible optimization for various system requirements.<br><br>Operating within a supply voltage range of 3.0V to 3.6V (typ. 3.3V), the AS4C64M16SA-6TCN is compatible with standard logic systems. It includes advanced features such as auto-refresh, self-refresh, and power-down modes, ensuring data integrity while reducing overall system power consumption.<br><br>With an access time in the low nanosecond range (~5 ns class) and high-speed synchronous operation, the device is well-suited for demanding real-time processing applications. It is housed in a compact 54-pin TSOP-II package, making it ideal for space-constrained PCB designs.<br><br>The AS4C64M16SA-6TCN is widely used in applications such as embedded systems, industrial automation, networking devices, multimedia systems, display controllers, and FPGA/SoC memory expansion, where high-capacity and high-speed volatile memory is essential.
AS4C64M16SA-6TCN

Description: The AS4C64M16SA-6TCN is a high-density 1Gbit synchronous DRAM (SDRAM) developed by Allianc ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AS4C4M16SA-7TCN / The AS4C4M16SA-7TCN is a high-speed 64Mbit synchronous DRAM (SDRAM) developed by Alliance Memory, designed for embedded systems and high-performance digital applications. It features a memory organization of 4M × 16 bits, enabling efficient parallel data access for processors, FPGAs, and SoC-based platforms.<br><br>The device operates at a maximum clock frequency of 143 MHz with an access time of approximately 5.4 ns, delivering reliable high-speed performance for buffering and real-time data processing applications.<br><br>Built on a fully synchronous architecture, all inputs and outputs are registered on the rising edge of the clock signal, ensuring stable timing and predictable operation. Internally, the SDRAM is organized into 4 banks, allowing concurrent operations and improved memory bandwidth.<br><br>The AS4C4M16SA-7TCN supports advanced features such as programmable burst lengths (1, 2, 4, 8, full page), CAS latency (CL2/CL3), and sequential/interleaved burst modes, enabling flexible system optimization. It also includes auto-refresh, self-refresh, and power-down modes, ensuring data integrity and reducing system power consumption.<br><br>Operating within a supply voltage range of 3.0V to 3.6V (typ. 3.3V), the device is compatible with standard logic systems and embedded designs.<br><br>Housed in a compact 54-pin TSOP-II surface-mount package, the AS4C4M16SA-7TCN is ideal for space-constrained PCB layouts. It operates over a commercial temperature range of 0°C to +70°C, ensuring stable performance in typical environments.<br><br>The AS4C4M16SA-7TCN is widely used in applications such as embedded systems, industrial controllers, networking equipment, display systems, consumer electronics, and FPGA/SoC memory expansion, where reliable and high-speed volatile memory is required.
AS4C4M16SA-7TCN

Description: The AS4C4M16SA-7TCN is a high-speed 64Mbit synchronous DRAM (SDRAM) developed by Alliance ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AS4C32M16SA-7TCN / The AS4C32M16SA-7TCN is a high-performance 512Mbit synchronous DRAM (SDRAM) developed by Alliance Memory, designed for embedded systems and high-speed digital applications. It features a memory organization of 32M × 16 bits and utilizes a parallel interface for efficient high-speed data access.<br><br>The device operates at a maximum clock frequency of approximately 143 MHz with a fast access time of around 5.4 ns, delivering reliable performance for buffering, data storage, and real-time processing applications.<br><br>Internally, the SDRAM is organized into 4 banks, allowing concurrent operations and improved memory bandwidth. It supports burst read/write operations, programmable burst lengths, and CAS latency configurations, enabling flexible optimization for different system requirements.<br><br>Operating within a supply voltage range of 3.0V to 3.6V, the AS4C32M16SA-7TCN is compatible with standard 3.3V systems. It also includes key features such as auto-refresh, self-refresh, and power-down modes, helping maintain data integrity while reducing system power consumption.<br><br>The device is housed in a compact 54-pin TSOP-II surface-mount package, making it suitable for space-constrained PCB designs. It operates over a commercial temperature range (0°C to +70°C), ensuring stable performance in typical environments.<br><br>The AS4C32M16SA-7TCN is widely used in applications such as embedded systems, industrial automation, networking equipment, display systems, consumer electronics, and FPGA/SoC memory expansion, where reliable and high-speed volatile memory is required.
AS4C32M16SA-7TCN

Description: The AS4C32M16SA-7TCN is a high-performance 512Mbit synchronous DRAM (SDRAM) developed by A ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AS4C32M16SA-6TCN / The AS4C32M16SA-6TCN is a high-performance 512Mbit synchronous DRAM (SDRAM) developed by Alliance Memory, designed for embedded systems and high-speed digital applications. It features a memory organization of 32M × 16 bits and utilizes a parallel interface for fast and efficient data access.<br><br>This device supports high-speed operation with clock frequencies up to 166 MHz (speed grade dependent), enabling high bandwidth and low-latency performance in memory-intensive systems. It operates using a fully synchronous architecture, where all inputs and outputs are referenced to the clock signal, ensuring stable and predictable timing behavior.<br><br>Internally, the SDRAM is organized into 4 banks, allowing interleaved access and improved data throughput. It supports burst read/write operations, programmable burst lengths (1, 2, 4, 8, full page), and selectable CAS latency (CL2/CL3), providing flexibility for different system designs.<br><br>The AS4C32M16SA-6TCN operates within a supply voltage range of 3.0V to 3.6V (typ. 3.3V) and features an access time of approximately 5.4 ns, ensuring fast response in high-speed applications. It also includes advanced memory management features such as auto-refresh, self-refresh, power-down modes, and data masking, helping to maintain data integrity and reduce power consumption.<br><br>Packaged in a compact 54-pin TSOP-II surface-mount form factor, the device is well-suited for space-constrained PCB designs. It typically operates over a commercial temperature range of 0°C to +70°C, ensuring reliable performance in standard environments.<br><br>The AS4C32M16SA-6TCN is widely used in applications such as embedded systems, industrial automation, networking equipment, consumer electronics, display systems, and FPGA/SoC memory expansion, where reliable, high-speed volatile memory is required.
AS4C32M16SA-6TCN

Description: The AS4C32M16SA-6TCN is a high-performance 512Mbit synchronous DRAM (SDRAM) developed by A ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AS4C2M32SA-7TCN / The AS4C2M32SA-7TCN is a high-speed 64Mbit synchronous DRAM (SDRAM) developed by Alliance Memory, designed for embedded systems and high-performance digital applications. It features a memory organization of 2M × 32 bits, providing efficient parallel data access for processors, FPGAs, and SoC platforms.<br><br>The device operates at a maximum clock frequency of 143 MHz with an access time of approximately 5.5 ns, enabling fast data transfer and low-latency performance in memory-intensive systems.<br><br>Built on a fully synchronous architecture, all inputs and outputs are registered on the rising edge of the clock signal, ensuring stable timing and predictable operation. Internally, the SDRAM is organized into four banks (quad-bank architecture), allowing concurrent operations and improved memory bandwidth.<br><br>The AS4C2M32SA-7TCN supports advanced memory features such as programmable burst lengths (1, 2, 4, 8, or full page), CAS latency (CL2/CL3), and sequential/interleaved burst modes, enabling flexible optimization for different system requirements.<br><br>Operating within a supply voltage range of 3.0V to 3.6V (typ. 3.3V), the device is compatible with standard logic systems. It also includes auto-refresh and self-refresh modes, reducing system overhead and maintaining data integrity during idle periods.<br><br>Packaged in a compact 86-pin TSOP-II surface-mount form factor, the AS4C2M32SA-7TCN is suitable for space-constrained PCB designs. It operates over a commercial temperature range of 0°C to +70°C, ensuring stable performance in typical environments.<br><br>The AS4C2M32SA-7TCN is widely used in applications such as embedded systems, industrial controllers, networking equipment, display systems, consumer electronics, and FPGA/SoC memory expansion, where reliable and high-speed volatile memory is required.
AS4C2M32SA-7TCN

Description: The AS4C2M32SA-7TCN is a high-speed 64Mbit synchronous DRAM (SDRAM) developed by Alliance ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AS4C16M8SA-7TCN / The AS4C16M8SA-7TCN is a high-speed 128Mbit synchronous DRAM (SDRAM) developed by Alliance Memory, designed for embedded systems and high-performance digital applications. It features a memory organization of 16M × 8 bits, enabling efficient parallel data access for microprocessors, FPGAs, and SoC-based systems.<br><br>The device operates at a maximum clock frequency of approximately 143 MHz with an access time around 5.4 ns, providing fast data throughput and low latency performance suitable for memory-intensive applications.<br><br>Built on a fully synchronous architecture, all inputs and outputs are registered on the clock edge, ensuring stable timing and predictable system behavior. The internal structure consists of multiple banks (typically 4 banks), allowing concurrent operations and improved bandwidth utilization.<br><br>The AS4C16M8SA-7TCN supports burst read and write operations, programmable burst lengths (1, 2, 4, 8, or full page), and selectable CAS latency (CL2/CL3), providing flexibility for different system requirements. It also includes advanced features such as auto-refresh, self-refresh, and power-down modes, helping reduce system power consumption while maintaining data integrity.<br><br>Operating within a supply voltage range of 3.0V to 3.6V, the device is compatible with standard 3.3V systems. It uses a parallel interface (LVTTL compatible), making it suitable for high-speed communication with digital processing units.<br><br>Packaged in a compact 54-pin TSOP-II surface-mount form factor, the AS4C16M8SA-7TCN is optimized for space-constrained PCB designs. It operates over a commercial temperature range of 0°C to +70°C, ensuring reliable performance in typical environments.<br><br>The AS4C16M8SA-7TCN is widely used in applications such as embedded systems, industrial controllers, networking equipment, display systems, consumer electronics, and FPGA/SoC memory expansion, where reliable, high-speed volatile memory is required.
AS4C16M8SA-7TCN

Description: The AS4C16M8SA-7TCN is a high-speed 128Mbit synchronous DRAM (SDRAM) developed by Alliance ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AS4C16M16SA-7TCN / The AS4C16M16SA-6TCN is a high-speed 256Mbit synchronous DRAM (SDRAM) developed by Alliance Memory, designed for embedded systems and high-performance digital applications. It features a memory organization of 16M × 16 bits and utilizes a parallel interface for fast data access.<br><br>The device operates at clock frequencies up to 166 MHz with a fast access time of approximately 5 ns, enabling high-speed data transfer and low latency performance in memory-intensive systems.<br><br>Internally, the SDRAM is organized into 4 banks, allowing concurrent operations and improved bandwidth. It supports burst-oriented read and write operations, where data is accessed sequentially after an initial address is specified, optimizing throughput for high-speed applications.<br><br>Operating within a supply voltage range of 3.0V to 3.6V, the AS4C16M16SA-6TCN is compatible with standard 3.3V systems. It also supports programmable CAS latency (CL2/CL3), synchronous clock operation, and efficient pipelined architecture for reliable performance.<br><br>Packaged in a 54-pin TSOP-II surface-mount form factor, the device is optimized for space-constrained PCB designs and cost-effective embedded solutions. It operates within a commercial temperature range of 0°C to +70°C, ensuring stable performance in typical environments.<br><br>The AS4C16M16SA-6TCN is widely used in applications such as embedded systems, industrial controllers, networking equipment, consumer electronics, display systems, and FPGA/SoC memory expansion, where reliable and high-speed volatile memory is required.
AS4C16M16SA-7TCN

Description: The AS4C16M16SA-6TCN is a high-speed 256Mbit synchronous DRAM (SDRAM) developed by Allianc ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AS4C16M16SA-6TCN / The AS4C16M16SA-6TCN is a high-speed 256Mbit synchronous DRAM (SDRAM) developed by Alliance Memory, designed for embedded systems and high-performance digital applications. It features a memory organization of 16M × 16 bits and utilizes a parallel interface for fast data access.<br><br>The device operates at clock frequencies up to 166 MHz with a fast access time of approximately 5 ns, enabling high-speed data transfer and low latency performance in memory-intensive systems.<br><br>Internally, the SDRAM is organized into 4 banks, allowing concurrent operations and improved bandwidth. It supports burst-oriented read and write operations, where data is accessed sequentially after an initial address is specified, optimizing throughput for high-speed applications.<br><br>Operating within a supply voltage range of 3.0V to 3.6V, the AS4C16M16SA-6TCN is compatible with standard 3.3V systems. It also supports programmable CAS latency (CL2/CL3), synchronous clock operation, and efficient pipelined architecture for reliable performance.<br><br>Packaged in a 54-pin TSOP-II surface-mount form factor, the device is optimized for space-constrained PCB designs and cost-effective embedded solutions. It operates within a commercial temperature range of 0°C to +70°C, ensuring stable performance in typical environments.<br><br>The AS4C16M16SA-6TCN is widely used in applications such as embedded systems, industrial controllers, networking equipment, consumer electronics, display systems, and FPGA/SoC memory expansion, where reliable and high-speed volatile memory is required.
AS4C16M16SA-6TCN

Description: The AS4C16M16SA-6TCN is a high-speed 256Mbit synchronous DRAM (SDRAM) developed by Allianc ...
Package: T&R | MOQ: 1000 | MPQ: 1000

IR2104PBF / The IR2104PBF is a high-voltage, high-speed half-bridge gate driver IC developed by Infineon Technologies, designed to drive both high-side and low-side N-channel MOSFETs or IGBTs in power switching applications. It integrates two output channels, enabling efficient control of half-bridge configurations in power electronics systems.<br><br>The device supports a high-side floating channel up to 600V, making it suitable for high-voltage applications such as motor drives, inverters, and power conversion systems. It operates with a gate drive supply range of 10V to 20V and is compatible with standard 3.3V, 5V, and 15V logic inputs, allowing easy interfacing with microcontrollers and digital control circuits.<br><br>The IR2104PBF features peak output currents of approximately 210 mA (source) and 360 mA (sink), enabling fast switching of power transistors. It includes internally fixed dead-time and cross-conduction prevention logic, ensuring safe operation by preventing shoot-through conditions in half-bridge circuits.<br><br>Additional integrated features such as undervoltage lockout (UVLO), shutdown control input, and matched propagation delays improve system reliability and simplify circuit design. The device also offers fast switching characteristics with typical propagation delays of ~680 ns (turn-on) and ~150 ns (turn-off).<br><br>Housed in a standard PDIP-8 package, the IR2104PBF is easy to implement in both prototyping and industrial designs. It is widely used in applications such as motor control systems, DC-AC inverters, SMPS (switch-mode power supplies), UPS systems, and power conversion circuits, where reliable high/low-side gate driving is required.
IR2104PBF

Description: The IR2104PBF is a high-voltage, high-speed half-bridge gate driver IC developed by Infine ...
Package: TUBE | MOQ: 1000 | MPQ: 50

ADXL345BCCZ-RL / The ADXL345BCCZ-RL is a compact, ultra-low power 3-axis digital MEMS accelerometer developed by Analog Devices, designed for motion detection, orientation sensing, and vibration monitoring applications. It provides high-resolution measurement (13-bit) with selectable ranges of ±2g, ±4g, ±8g, and ±16g, enabling precise detection of both small movements and high-impact events.<br><br>The device measures both static acceleration (gravity) for tilt sensing and dynamic acceleration caused by motion, shock, or vibration. Its high sensitivity (~4 mg/LSB) allows detection of inclination changes of less than 1°, making it suitable for precision orientation applications.<br><br>The ADXL345 features flexible digital communication via I2C and SPI interfaces, ensuring easy integration with microcontrollers, embedded systems, and platforms such as Arduino, ESP32, and STM32. It operates over a wide supply voltage range of 2.0V to 3.6V and supports adjustable bandwidth from 0.05 Hz to 1.6 kHz, allowing optimization between power consumption and performance.<br><br>Advanced embedded functions include activity/inactivity detection, single/double tap sensing, free-fall detection, and a 32-level FIFO buffer, reducing processor load and enabling intelligent motion-based power management.<br><br>With its small size, low power consumption, and integrated motion processing features, the ADXL345BCCZ-RL is widely used in applications such as mobile devices, gaming controllers, wearable electronics, industrial monitoring systems, vibration analysis, and IoT motion sensing applications, where accurate and efficient motion detection is required.
ADXL345BCCZ-RL

Description: The ADXL345BCCZ-RL is a compact, ultra-low power 3-axis digital MEMS accelerometer develop ...
Package: T&R | MOQ: 500 | MPQ: 500

R307S / The R307S is a compact and high-performance optical fingerprint sensor module designed for biometric authentication and identification applications. It integrates an optical sensor, DSP processor, and fingerprint recognition algorithm into a single module, enabling fast and accurate fingerprint capture, processing, and matching.<br><br>The module operates within a supply voltage range of approximately 4.2V to 6.0V and typically consumes around 50–75 mA, making it suitable for embedded and portable systems. It supports both UART (TTL) and optional USB interfaces, allowing easy integration with microcontrollers such as Arduino, ESP32, STM32, and Raspberry Pi.<br><br>The R307S features a 500 DPI optical resolution and high-speed performance, with fingerprint scanning times under 0.3 seconds and verification speeds around 0.2 seconds, ensuring quick and reliable user authentication. It supports both 1:1 verification and 1:N identification modes, with onboard flash memory capable of storing up to 1000 fingerprint templates.<br><br>The module includes an integrated LED indicator and advanced image processing capabilities, allowing accurate detection even under varying environmental conditions. It also offers configurable security levels and very low false acceptance and rejection rates, making it suitable for secure systems.<br><br>With its all-in-one design, ease of integration, and reliable performance, the R307S is widely used in applications such as access control systems, attendance machines, smart locks, safes, IoT security devices, and embedded biometric authentication systems, where secure and fast identity verification is required.
R307S

Description: The R307S is a compact and high-performance optical fingerprint sensor module designed for ...
Package: TRAY | MOQ: 100 | MPQ: 100

PN5321A3HN/C106,55 / The PN5321A3HN/C106,55 is a highly integrated 13.56 MHz NFC/RFID controller IC developed by NXP Semiconductors, designed for contactless communication applications including smart cards, access control, and mobile NFC systems. It combines analog and digital RF functionality with an embedded microcontroller core, reducing the processing load on the host system.<br><br>This device supports multiple communication standards including ISO/IEC 14443 Type A/B, MIFARE®, FeliCa, and NFC (ISO/IEC 18092), enabling compatibility with a wide range of contactless cards and NFC devices. It can operate in multiple modes such as reader/writer, card emulation, and peer-to-peer communication, making it highly versatile for modern NFC applications.<br><br>The PN5321A3HN/C106,55 supports flexible host interfaces including SPI, I2C, and UART, allowing easy integration with microcontrollers, embedded systems, and industrial controllers. It operates within a supply voltage range of 2.7V to 5.5V, ensuring compatibility with a wide variety of digital platforms.<br><br>With integrated RF front-end circuitry, modulation/demodulation blocks, and protocol handling (CRC, parity, framing), the IC minimizes external component requirements and simplifies system design. It supports data transfer rates up to 424 kbit/s and typical communication distances up to 50 mm, depending on antenna design.<br><br>Packaged in a compact HVQFN-40 surface-mount form factor, the PN5321A3HN/C106,55 is suitable for space-constrained designs. It is widely used in applications such as contactless payment terminals, access control systems, ticketing, smart cards, IoT security, mobile devices, and industrial NFC systems, where reliable and secure short-range wireless communication is required.
PN5321A3HN/C106,55

Description: The PN5321A3HN/C106,55 is a highly integrated 13.56 MHz NFC/RFID controller IC developed b ...
Package: T&R | MOQ: 490 | MPQ: 490

MFRC522-MOD / The MFRC522 Module is a compact and widely used 13.56 MHz RFID/NFC reader module based on the MFRC522 chip from NXP Semiconductors. It is designed for easy integration into embedded systems, providing a complete contactless communication solution with minimal external components.<br><br>This module supports ISO/IEC 14443 Type A and MIFARE® protocols, allowing it to read and write various contactless smart cards and RFID tags such as MIFARE Classic, Ultralight, and other compatible cards. It is commonly used for identification, authentication, and access control applications.<br><br>The MFRC522 module communicates via a SPI interface, ensuring fast and reliable data exchange with microcontrollers such as Arduino, ESP8266, ESP32, Raspberry Pi, and STM32 platforms. It typically operates at 3.3V logic levels, making it suitable for low-voltage embedded systems.<br><br>The module includes an onboard antenna, crystal oscillator, and passive components, simplifying hardware design. It supports data transfer rates up to 848 kbps and offers a typical reading distance of up to 3–5 cm, depending on antenna design and tag type.<br><br>With its small PCB form factor and standard pin header interface, the MFRC522 module is easy to use in prototyping and production environments. It is widely used in applications such as access control systems, attendance tracking, contactless payment prototypes, IoT security, smart locks, and RFID-based identification systems.
MFRC522-MOD

Description: The MFRC522 Module is a compact and widely used 13.56 MHz RFID/NFC reader module based on ...
Package: TRAY | MOQ: 100 | MPQ: 100

MFRC522 01HN1,157 / The MFRC52201HN1,157 is a highly integrated 13.56 MHz RFID/NFC reader and writer IC developed by NXP Semiconductors, designed for contactless communication systems. It supports ISO/IEC 14443 Type A and MIFARE® protocols, making it widely used in access control, payment systems, and identification applications.<br><br>The device integrates a complete RF front-end, including a transmitter capable of directly driving an antenna and a receiver for demodulating and decoding signals from contactless cards and tags. This eliminates the need for additional RF circuitry and simplifies system design.<br><br>The MFRC52201HN1,157 supports multiple host interfaces including SPI, I2C, and UART, enabling flexible integration with microcontrollers, embedded systems, and industrial controllers. It operates with a supply voltage range of 2.5V to 3.3V and supports data transfer rates up to 848 kbit/s, ensuring efficient communication with RFID/NFC devices.<br><br>The IC includes a digital processing unit that handles framing, error detection (CRC, parity), and protocol management, reducing the workload on the host processor. It also supports a wide range of MIFARE products such as Classic, Ultralight, DESFire, and Plus cards.<br><br>Packaged in a compact 32-pin HVQFN surface-mount form factor, the MFRC52201HN1,157 is optimized for space-constrained designs. It operates over a temperature range of -25°C to +85°C, making it suitable for both consumer and industrial environments.<br><br>The MFRC52201HN1,157 is widely used in applications such as RFID readers, contactless payment terminals, access control systems, smart cards, NFC-enabled devices, public transportation systems, and IoT security applications, where reliable and efficient contactless communication is required.
MFRC522 01HN1,157

Description: The MFRC52201HN1,157 is a highly integrated 13.56 MHz RFID/NFC reader and writer IC develo ...
Package: TRAY | MOQ: 490 | MPQ: 490

TTP223-BA6 / The TTP223-BA6 is a compact and low-power capacitive touch sensor IC developed by Tontek, designed to replace traditional mechanical push buttons with a reliable touch interface. It supports single-key touch detection, making it ideal for simple user interface applications.<br><br>The device operates within a wide supply voltage range of 2.0V to 5.5V, allowing compatibility with various embedded systems and microcontrollers. It features ultra-low power consumption, typically around 1.5 µA in low-power mode, making it highly suitable for battery-powered applications.<br><br>The TTP223-BA6 provides a stable and noise-immune touch detection mechanism, capable of detecting human touch through insulating materials such as plastic or glass. Sensitivity can be adjusted externally using capacitance (0–50 pF), enabling flexible design optimization.<br><br>It supports configurable output modes via pin options, including active high/low output and toggle or momentary operation, allowing designers to adapt behavior according to application requirements. Additionally, it includes auto-calibration functionality, ensuring consistent performance over time and environmental changes.<br><br>With a response time of approximately 60 ms (touch mode) and up to 220 ms in low-power mode, the IC ensures responsive yet stable operation.<br><br>Housed in a small SOT-23-6 package, the TTP223-BA6 is widely used in applications such as touch switches, consumer electronics, home appliances, control panels, IoT devices, and human-machine interfaces (HMI) where reliable and maintenance-free touch input is required.
TTP223-BA6

Description: The TTP223-BA6 is a compact and low-power capacitive touch sensor IC developed by Tontek, ...
Package: T&R | MOQ: 3000 | MPQ: 3000

TTY6759 / The TTY6759 is a capacitive touch sensor controller IC developed by Tontek, designed for human-machine interface (HMI) applications requiring reliable and responsive touch input. It supports up to 10 capacitive touch keys, making it suitable for multi-button touch panels and control interfaces.<br><br>The device operates within a supply voltage range of 2.7V to 5.5V and features low power consumption (~1.8 mA active, µA-level standby), making it ideal for energy-efficient embedded systems.<br><br>The TTY6759 supports I2C / 3-wire communication interface, allowing easy integration with microcontrollers and embedded processors. It provides stable touch detection with built-in filtering and noise immunity, ensuring accurate performance even in electrically noisy environments.<br><br>With fast startup time (<1 second) and robust touch sensing capability, the IC can detect finger proximity through insulating materials such as glass or plastic, enabling sleek and durable touch panel designs.<br><br>Packaged in a compact SOP-16 surface-mount form factor, the TTY6759 is widely used in applications such as home appliances, control panels, industrial interfaces, consumer electronics, smart devices, and touch-based user interfaces, where reliable capacitive touch sensing is required.
TTY6759

Description: The TTY6759 is a capacitive touch sensor controller IC developed by Tontek, designed for h ...
Package: T&R | MOQ: 2000 | MPQ: 2000

HX711 / The HX711 is a high-precision 24-bit analog-to-digital converter (ADC) developed by Avia Semiconductor, specifically designed for weigh scale and industrial control applications. It integrates a low-noise programmable gain amplifier (PGA) and a high-resolution ADC, making it ideal for directly interfacing with load cells and strain gauges.<br><br>The device features two selectable input channels, with programmable gain options of 32, 64, and 128, allowing flexible adaptation to different sensor sensitivities. Channel A supports gains of 128 or 64, while Channel B provides a fixed gain of 32 for auxiliary measurements.<br><br>The HX711 operates with a simple 2-wire serial interface (clock and data), eliminating the need for complex communication protocols and making it easy to integrate with microcontrollers such as Arduino, ESP8266, and STM32 platforms. It supports selectable output data rates of 10 SPS or 80 SPS, balancing between noise performance and speed.<br><br>The device includes an on-chip regulator and oscillator, reducing external component requirements and simplifying circuit design. It operates within a supply voltage range of 2.6V to 5.5V, making it suitable for both battery-powered and standard embedded systems.<br><br>With its high resolution, low noise, and integrated amplification, the HX711 is widely used in applications such as digital weighing scales, industrial measurement systems, force sensors, pressure measurement, and IoT-based weight monitoring systems, where accurate and stable signal conversion is essential.
HX711

Description: The HX711 is a high-precision 24-bit analog-to-digital converter (ADC) developed by Avia S ...
Package: T&R | MOQ: 2000 | MPQ: 2000

W66DP2RQQAGJ / The W66DP2RQQAGJ is a high-performance 8Gbit LPDDR4X SDRAM memory IC developed by Winbond Electronics, designed for advanced embedded and mobile applications requiring high bandwidth and low power consumption. It features a memory organization of 256M × 32 bits, enabling efficient handling of large data streams in modern digital systems.<br><br>This device supports LPDDR4X technology with clock frequencies up to 1.866 GHz, delivering high-speed data transfer suitable for applications such as industrial computing, networking systems, and high-performance embedded platforms.<br><br>Operating with dual supply voltages of approximately 1.06–1.17V (core) and 1.7–1.95V (I/O), the W66DP2RQQAGJ provides improved energy efficiency compared to previous memory generations while maintaining stable high-speed operation.<br><br>The device uses a LVSTL_06 interface and advanced DDR architecture, offering fast access time (~3.5 ns) and efficient write cycle performance (~18 ns), ensuring responsiveness in time-critical applications.<br><br>With an operating temperature range of -40°C to +105°C, the W66DP2RQQAGJ is suitable for industrial and automotive-grade environments. It is packaged in a compact 200-ball TFBGA form factor, enabling high-density PCB layouts and space-constrained designs.<br><br>The W66DP2RQQAGJ is widely used in applications such as embedded systems, industrial automation, networking equipment, AI/edge computing devices, automotive electronics, and high-performance consumer electronics, where high-speed volatile memory and low power consumption are critical.<br><br>Equivalent Parts: K4F6E304HB-MGCJ, K4F6E3S4HM-MGCJ, K4F6E304HB-MGCH, MT53E256M32D2DS-046, MT53E256M32D2NP-046, MT53E256M32D1DS-046, H9HKNNN8KUMLHR-NME, H9HKNNN8KUMLXR-NME, H9HKNNN8KUMLHR-NEH, NT6AN256T32AV-J1, NT6AN256T32CM-J1, W66DP2RQQAGJG, W66CP6RBQAFJ
W66DP2RQQAGJ

Description: The W66DP2RQQAGJ is a high-performance 8Gbit LPDDR4X SDRAM memory IC developed by Winbond ...
Package: TRAY | MOQ: 144 | MPQ: 144

W664GG6RB-06 / The W664GG6RB-06 is a high-performance 4Gbit DDR4 SDRAM memory IC developed by Winbond Electronics, designed for high-speed data processing and embedded system applications. It features a memory organization of 256M × 16 bits, providing efficient data storage and transfer for modern digital systems.<br><br>The device supports DDR4 technology with data rates up to 3200 Mbps (1600 MHz clock), enabling high bandwidth and fast data access suitable for demanding applications such as industrial controllers, networking devices, and advanced embedded platforms.<br><br>Operating with a low supply voltage of approximately 1.2V (1.14V – 1.26V), the W664GG6RB-06 offers improved energy efficiency compared to previous DDR generations while maintaining high performance. It incorporates an 8-bank architecture with 8n prefetch, ensuring optimized memory throughput and efficient parallel access.<br><br>The device features a POD_12 interface, differential clocking, and advanced DDR4 functions such as on-die termination (ODT), data bus inversion, ZQ calibration, and programmable latency control, ensuring signal integrity and reliable operation in high-speed environments.<br><br>With a typical access time of ~18 ns and fast write cycles (~15 ns), the memory is suitable for latency-sensitive applications. It operates over a temperature range of 0°C to +95°C, making it suitable for commercial and industrial-grade systems.<br><br>Packaged in a compact 96-ball VFBGA form factor, the W664GG6RB-06 is optimized for high-density PCB designs and space-constrained applications. It is widely used in embedded systems, industrial automation, networking equipment, consumer electronics, and high-performance computing modules where fast and reliable volatile memory is required.<br><br> Equivalent: NT5AD256M16E4-JR, NT5AD256M16E4-JR TR, MT40A256M16LY-062E, MT40A256M16GE-062E, MT40A256M16TB-062E, K4A4G165WE-BCRC, K4A4G165WF-BCTD, K4A4G165WB-BCRC, H5AN4G6NBJR-UHC, H5AN4G6NAFR-UHC, H5AN4G6NBMR-UHC
W664GG6RB-06

Description: The W664GG6RB-06 is a high-performance 4Gbit DDR4 SDRAM memory IC developed by Winbond Ele ...
Package: TRAY | MOQ: 198 | MPQ: 198

W634GU6RB-09 / The W634GU6RB-09 is a high-performance 4Gbit DDR3L SDRAM memory IC developed by Winbond Electronics, designed for embedded systems and high-speed data processing applications. It features a memory organization of 256M × 16 bits, enabling efficient handling of large data streams in modern digital systems.<br><br>The device operates at clock frequencies up to 1.066 GHz, delivering high bandwidth suitable for demanding applications such as industrial controllers, networking equipment, and multimedia systems. It utilizes a parallel interface and DDR3L architecture with 8n prefetch, allowing efficient data transfer and improved system performance.<br><br>Operating at a low supply voltage range of 1.283V to 1.45V (typ. 1.35V), the W634GU6RB-09 reduces power consumption compared to standard DDR3 memory while maintaining high-speed operation. It offers an access time of approximately 20 ns and fast write cycles (~15 ns), making it suitable for time-critical applications.<br><br>The device is housed in a compact 96-ball VFBGA package, optimized for high-density PCB layouts and space-constrained designs. It supports industrial operating conditions (up to +95°C), ensuring reliable performance in harsh environments.<br><br>The W634GU6RB-09 is widely used in applications such as embedded systems, industrial automation, networking devices, consumer electronics, and automotive electronics, where high-speed volatile memory and low power consumption are essential. <br><br> Equivalent Part: MT41K256M16TW-107, MT41K256M16HA-107, MT41K256M16LY-107, K4B4G1646E-BYK0, K4B4G1646D-BCK0, K4B4G1646Q-BYK0, H5TC4G63CFR-PBA, H5TC4G63AFR-PBA, H5TC4G63DJR-PBA, NT5CC256M16DP-DI, NT5CC256M16ER-DI, IS43TR16256BL-125KBL, IS43TR16256AL-125KBL, W634GU6RB-11, W634GU6RB09I/-09TR, W634GU6QB-09
W634GU6RB-09

Description: The W634GU6RB-09 is a high-performance 4Gbit DDR3L SDRAM memory IC developed by Winbond El ...
Package: TRAY | MOQ: 198 | MPQ: 198

W632GU6RB-11 / The W632GU6RB-11 is a high-performance 2Gbit DDR3L SDRAM memory IC developed by Winbond Electronics, designed for embedded systems and high-speed data processing applications. It features a memory organization of 128M × 16 bits, providing efficient data handling for modern processors and digital systems.<br><br>Operating at a clock frequency of up to 933 MHz, the device enables high-speed data transfer and supports bandwidth-intensive applications such as industrial control systems, networking equipment, and multimedia devices. The parallel memory interface ensures fast communication with microcontrollers, SoCs, and FPGA platforms.<br><br>The W632GU6RB-11 operates at a low supply voltage range of approximately 1.283V to 1.45V (DDR3L standard ~1.35V), reducing power consumption while maintaining stable performance. It provides an access time of around 20 ns and write cycle time of ~15 ns, making it suitable for time-critical operations.<br><br>With its 8-bank architecture and DDR3L technology, the device delivers high efficiency and improved data throughput compared to earlier memory generations. It also supports advanced DDR features such as burst operation, on-die termination, and high-speed clocking for signal integrity.<br><br>Packaged in a compact 96-ball VFBGA (7.5 × 13 mm) surface-mount format, the W632GU6RB-11 is optimized for high-density PCB designs.<br><br>This memory IC is widely used in applications such as embedded systems, industrial automation, networking devices, consumer electronics, and automotive electronics, where reliable, high-speed volatile memory is essential.<br><br> Equivalent Parts: MT41K128M16JT-125, MT41K128M16HA-125, MT41K128M16TW-125, K4B2G1646E-BCK0, K4B2G1646Q-BYK0, K4B2G1646D-BCK0, H5TC2G63FFR-PBA, H5TC2G63AFR-PBA, H5TC2G63EFR-PBA, NT5CC128M16DP-DI, NT5CC128M16JR-DI, IS43TR16128BL-125KBL, IS43TR16128AL-125KBL, AS4C128M16D3L-12BCN, W632GU6RB-09, W632GU6RB-12, W632GU6NB-11, W631GU6RB-11
W632GU6RB-11

Description: The W632GU6RB-11 is a high-performance 2Gbit DDR3L SDRAM memory IC developed by Winbond El ...
Package: TUBE | MOQ: 198 | MPQ: 198

W632GU6RB-09 / The W632GU6RB-09 is a high-performance 2Gbit DDR3L SDRAM memory IC developed by Winbond Electronics, designed for embedded systems and high-speed data processing applications. It features a memory organization of 128M × 16 bits and utilizes DDR3L technology for improved power efficiency and bandwidth.<br><br>Operating at speeds up to 1066 MHz clock frequency (DDR3-2133 data rate class), the device enables fast data transfer and efficient system performance. It incorporates an 8-bank architecture and 8n prefetch design, allowing high throughput and optimized memory access for modern processors.<br><br>The W632GU6RB-09 operates with a low supply voltage range of approximately 1.283V to 1.45V (DDR3L standard 1.35V), reducing power consumption compared to standard DDR3 while maintaining stable performance. It supports a parallel interface, making it suitable for high-speed communication with microcontrollers, SoCs, and FPGA platforms.<br><br>The device features typical access time of ~20 ns and fast write cycles (~15 ns), ensuring responsiveness in time-critical applications. Additional capabilities include on-die termination (ODT), ZQ calibration, programmable CAS latency, and differential clock/data strobe architecture for signal integrity and reliability.<br><br>Housed in a compact 96-ball VFBGA (7.5 × 13 mm) package, the W632GU6RB-09 is optimized for high-density PCB designs. It is widely used in applications such as embedded systems, industrial controllers, networking equipment, consumer electronics, and automotive systems, where high-speed volatile memory and low power consumption are essential.<br><br> Equivalent Parts: MT41K128M16JT-125, MT41K128M16HA-125, MT41K128M16TW-125, K4B2G1646E-BYK0, K4B2G1646Q-BYK0, K4B2G1646D-BCK0, H5TC2G63FFR-PBA, H5TC2G63AFR-PBA, H5TC2G63EFR-PBA, NT5CC128M16DP-DI, NT5CC128M16JR-DI, IS43TR16128BL-125KBL, IS43TR16128AL-125KBL, AS4C128M16D3L-12BCN, W632GU6RB-11, W632GU6RB-12, W632GU6RB09I, W632GU6RB09J, W632GU6NB-09
W632GU6RB-09

Description: The W632GU6RB-09 is a high-performance 2Gbit DDR3L SDRAM memory IC developed by Winbond El ...
Package: TUBE | MOQ: 198 | MPQ: 198

W634GU6RB-11 / The W634GU6RB-11 is a high-performance 4Gbit DDR3L SDRAM memory IC developed by Winbond Electronics, designed for embedded systems and high-speed data processing applications. It features a memory organization of 256M × 16 bits and operates using DDR3L technology for improved power efficiency and performance.<br><br>Operating at a clock frequency of up to 933 MHz (DDR3-1866 equivalent data rate), the device enables fast data transfer and efficient system operation. It supports a parallel memory interface and includes multiple internal banks, allowing high bandwidth and optimized memory access for modern embedded processors.<br><br>The W634GU6RB-11 operates at a low supply voltage range of approximately 1.283V to 1.45V, reducing power consumption compared to standard DDR3 memory while maintaining stable performance. It offers an access time of around 20 ns and supports fast write cycles (~15 ns), making it suitable for time-critical applications.<br><br>Packaged in a compact 96-ball VFBGA (7.5 × 13 mm) form factor, the device is optimized for space-constrained PCB designs and high-density memory layouts. It operates over a wide temperature range (up to industrial grade), ensuring reliable performance in demanding environments.<br><br>The W634GU6RB-11 is widely used in applications such as embedded systems, industrial controllers, networking equipment, consumer electronics, automotive systems, and high-performance computing modules, where fast, reliable volatile memory is required.<br><br> Equivalent Part: MT41K256M16TW-107, MT41K256M16HA-107, MT41K256M16LY-107, K4B4G1646E-BCK0, K4B4G1646Q-BYK0, K4B4G1646D-BCK0, H5TC4G63AFR-PBA, H5TC4G63CFR-PBA, H5TC4G63DJR-PBA, NT5CC256M16DP-DI, NT5CC256M16ER-DI, IS43TR16256BL-125KBL, IS43TR16256AL-125KBL, AS4C256M16D3L-12BCN, AS4C256M16D3L-12BCN, NDL46PFI-9MAT, W634GU6RB-09, W634GU6RB-12, W634GU6QB-11, W634GU8RB-11
W634GU6RB-11

Description: The W634GU6RB-11 is a high-performance 4Gbit DDR3L SDRAM memory IC developed by Winbond El ...
Package: TRAY | MOQ: 198 | MPQ: 198

GD25Q64ESIG / The GD25Q64ESIG is a high-performance 64Mbit (8MB) SPI NOR Flash memory developed by GigaDevice, designed for reliable code storage and data retention in embedded and consumer electronic systems. It supports standard SPI as well as Dual and Quad SPI (QSPI) interfaces, enabling high-speed data transfer and efficient system performance.<br><br>Operating within a supply voltage range of 2.7V to 3.6V, the device is optimized for low-power applications while maintaining stable operation across an industrial temperature range of -40°C to +85°C. The memory supports clock frequencies up to 133 MHz, allowing fast read access and execute-in-place (XIP) capability for embedded firmware execution.<br><br>The GD25Q64ESIG features a flexible memory architecture with 256-byte programmable pages and multiple sector/block erase options, enabling efficient memory management. It also offers high endurance of up to 100,000 program/erase cycles and long data retention of up to 20 years, ensuring reliability in long-term applications.<br><br>Additional features include write protection mechanisms, security registers, suspend/resume operations, and unique device ID, enhancing system security and flexibility.<br><br>Packaged in a compact SOP-8 surface-mount form factor, the GD25Q64ESIG is widely used in applications such as firmware storage, IoT devices, industrial control systems, automotive electronics, networking equipment, and consumer electronics, where fast, reliable non-volatile memory is essential.<br><br> Equivalent Parts : W25Q64JVSIQ, W25Q64JVSSIQ, W25Q64FVSSIG, MT25QL64ABA, MT25QL64ABA1ESE, N25Q064A13ESE, S25FL064L, S25FL064P, MX25L6406E, MX25R6435F, AT25DF641, AT25SF641, IS25LP064A, EN25Q64, XM25QH64C(ESP32 Second source), GD25Q64CSIG, GD25Q64BSIG, GD25X64EYSG
GD25Q64ESIG

Description: The GD25Q64ESIG is a high-performance 64Mbit (8MB) SPI NOR Flash memory developed by GigaD ...
Package: T&R | MOQ: 2000 | MPQ: 2000

GD25Q32ESIG / The GD25Q32ESIG is a high-performance 32Mbit (4MB) SPI NOR Flash memory developed by GigaDevice, designed for code storage and data retention in embedded systems and consumer electronics. It supports standard SPI as well as Dual and Quad SPI interfaces, enabling high-speed data transfer and efficient system performance.<br><br>Operating within a supply voltage range of 2.7V to 3.6V, the device is optimized for low-power applications while maintaining stable performance across industrial environments. It supports clock frequencies up to 133 MHz, providing fast read access and enabling execute-in-place (XIP) capabilities for firmware execution.<br><br>The memory architecture includes 256-byte programmable pages, sector and block erase options, and a total organization of 4M × 8, allowing flexible and efficient memory management. Typical page program time is around a few milliseconds, supporting fast write operations.<br><br>Additional features include low power consumption, high endurance, data retention up to decades, write protection mechanisms, and support for suspend/resume operations, making it suitable for reliable long-term storage.<br><br>Packaged in a compact SOP-8 surface-mount form factor, the GD25Q32ESIG is widely used in applications such as firmware storage, IoT devices, industrial control systems, consumer electronics, networking equipment, and embedded systems, where reliable non-volatile memory and high-speed access are essential.
GD25Q32ESIG

Description: The GD25Q32ESIG is a high-performance 32Mbit (4MB) SPI NOR Flash memory developed by GigaD ...
Package: T&R | MOQ: 2000 | MPQ: 2000

GD25Q16ESIG / The GD25Q16ESIG is a high-performance 16Mbit (2MB) SPI NOR Flash memory developed by GigaDevice, designed for code storage and data retention in embedded and consumer electronics applications. It supports standard SPI as well as Dual and Quad SPI interfaces, enabling higher data throughput and flexible system integration.<br><br>Operating within a supply voltage range of 2.7V to 3.6V, the device is optimized for low-power designs while maintaining stable performance across industrial temperature ranges. It supports clock frequencies up to 133 MHz, allowing fast read operations and efficient firmware execution.<br><br>The memory architecture includes 256-byte programmable pages, 4KB sectors, and multiple block erase options, providing flexible memory management for embedded systems. It also supports advanced features such as suspend/resume operations, write protection, security registers with OTP locks, and unique device ID for enhanced system security.<br><br>With endurance of up to 100,000 program/erase cycles and data retention of up to 20 years, the GD25Q16ESIG ensures long-term reliability in demanding applications. Its compact SOP-8 package makes it suitable for space-constrained PCB designs.<br><br>The GD25Q16ESIG is widely used in applications such as firmware storage, IoT devices, industrial control systems, consumer electronics, networking equipment, and embedded systems, where reliable non-volatile memory and fast access speeds are essential.
GD25Q16ESIG

Description: The GD25Q16ESIG is a high-performance 16Mbit (2MB) SPI NOR Flash memory developed by GigaD ...
Package: T&R | MOQ: 2000 | MPQ: 2000

GD25Q128ESIG / The GD25Q128ESIG is a high-performance 128Mbit (16MB) SPI NOR Flash memory developed by GigaDevice, designed for code storage and data retention in embedded systems and consumer electronics. It supports standard SPI as well as Dual and Quad SPI interfaces, enabling high-speed data transfer and efficient system performance.<br><br>Operating within a supply voltage range of 2.7V to 3.6V, the device is optimized for low-power applications while maintaining reliable performance across an industrial temperature range of -40°C to +85°C.<br><br>The GD25Q128ESIG supports clock frequencies up to 133 MHz, delivering fast read access and high throughput for firmware execution and data storage. It features flexible erase options including sector, block, and chip erase, along with a 256-byte page program architecture, enabling efficient memory management.<br><br>With endurance up to 100,000 program/erase cycles and long data retention (up to 20 years), the device ensures long-term reliability in demanding applications. Additional features such as hardware write protection, security registers, suspend/resume operations, and unique ID support enhance system security and flexibility.<br><br>Packaged in a compact SOP-8 surface-mount format, the GD25Q128ESIG is widely used in applications such as firmware storage, IoT devices, industrial control systems, automotive electronics, networking equipment, and consumer electronics, where reliable non-volatile memory and fast access speeds are essential.
GD25Q128ESIG

Description: The GD25Q128ESIG is a high-performance 128Mbit (16MB) SPI NOR Flash memory developed by Gi ...
Package: T&R | MOQ: 2000 | MPQ: 2000

IRM-3638T / The IRM-3638T is a compact infrared (IR) remote control receiver module developed by Everlight Electronics, designed for reliable reception of IR signals in consumer and industrial electronics. It operates at a 38 kHz carrier frequency, which is the most commonly used standard for IR remote control systems.<br><br>The module integrates a PIN photodiode and preamplifier in a single package, along with an internal band-pass filter tuned to the carrier frequency. This allows it to directly demodulate IR signals and output clean digital pulses that can be easily processed by microcontrollers.<br><br>Operating with a supply voltage range of 2.7V to 5.5V and low current consumption (~0.5–1 mA), the IRM-3638T is suitable for low-power and embedded applications. It offers a typical reception distance of up to 14 meters, along with strong immunity to ambient light and electrical noise, ensuring stable performance even in challenging environments.<br><br>The device features a wide reception angle (approximately ±35° to ±45°) and high sensitivity at a peak wavelength of 940 nm, making it compatible with standard IR transmitters used in remote controls.<br><br>Packaged in a through-hole DIP-3 form factor, the IRM-3638T is easy to integrate into PCB designs and prototyping environments. It is widely used in applications such as TVs, set-top boxes, air conditioners, consumer electronics, home automation systems, and Arduino-based IR projects where reliable remote signal reception is required.
IRM-3638T

Description: The IRM-3638T is a compact infrared (IR) remote control receiver module developed by Everl ...
Package: BULK | MOQ: 1500 | MPQ: 1500

EL357N(B)(TA)-G / The EL357N(B)(TA)-G is a compact phototransistor-output optocoupler developed by Everlight Electronics, designed to provide electrical isolation between input and output circuits in a wide range of electronic applications. It integrates an infrared LED optically coupled to an NPN phototransistor, enabling reliable signal transmission while maintaining galvanic isolation.<br><br>This device offers a high isolation voltage of up to 3750 Vrms, ensuring safe operation in systems where circuits operate at different voltage levels. The current transfer ratio (CTR) for the B-rank variant typically falls within a defined range (higher than base grade), allowing stable signal amplification and switching performance.<br><br>The EL357N(B)(TA)-G supports collector-emitter voltages up to 80V and output currents up to 50mA, making it suitable for general-purpose switching and signal isolation tasks. It features fast switching characteristics (rise/fall times in microseconds), ensuring efficient operation in digital and control circuits.<br><br>Packaged in a small SOP-4 surface-mount form factor and supplied in tape-and-reel (TA) format, the device is optimized for automated assembly and compact PCB designs.<br><br>The EL357N(B)(TA)-G is widely used in applications such as switching power supplies, DC-DC converters, industrial control systems, microcontroller interfacing, signal isolation, and communication equipment, where reliable electrical isolation and noise immunity are essential.
EL357N(B)(TA)-G

Description: The EL357N(B)(TA)-G is a compact phototransistor-output optocoupler developed by Everlight ...
Package: T&R | MOQ: 3000 | MPQ: 3000

LT1097S8#TRPBF / The LT1097S8#TRPBF is a low-power, high-precision operational amplifier developed by Analog Devices, designed for applications requiring excellent accuracy and stability with minimal power consumption. It is a single-channel general-purpose op-amp optimized for precision analog signal processing.<br><br>The device operates over a wide supply voltage range from 2.4V to 40V, making it suitable for both low-voltage portable systems and higher-voltage industrial applications. It features a low input offset voltage (≈10 µV typical) and very low input bias current (~50 pA), ensuring high accuracy in sensitive measurement circuits.<br><br>With a gain bandwidth product of approximately 700 kHz and a low supply current around 350 µA, the LT1097 achieves an excellent balance between performance and power efficiency. Its low noise characteristics and high common-mode rejection make it ideal for precision signal conditioning.<br><br>The amplifier is designed to provide stable performance over an industrial temperature range of -40°C to +85°C, and its SOIC-8 surface-mount package enables easy integration into compact PCB designs.<br><br>The LT1097S8#TRPBF is widely used in applications such as precision instrumentation, sensor signal conditioning, thermocouple amplifiers, data acquisition systems, active filters, and industrial control systems, where low power consumption and high accuracy are critical.
LT1097S8#TRPBF

Description: The LT1097S8#TRPBF is a low-power, high-precision operational amplifier developed by Analo ...
Package: T&R | MOQ: 2500 | MPQ: 2500

HMC438MS8GETR / The HMC438MS8GETR is a high-performance RF frequency divider (prescaler) developed by Analog Devices, designed for use in high-frequency communication and signal processing systems. It is a divide-by-5 static frequency divider built using advanced InGaP GaAs HBT technology, offering excellent noise performance and wide bandwidth operation.<br><br>This device supports input frequencies from DC up to 7 GHz, making it suitable for a broad range of RF and microwave applications. It operates from a single +5V supply and delivers typical output power around -1 dBm, with low additive phase noise of approximately -153 dBc/Hz at 100 kHz offset, ensuring high signal integrity in frequency synthesis systems.<br><br>The HMC438MS8GETR features a compact MSOP-8 surface-mount package with exposed pad for improved thermal performance and RF grounding. It requires minimal external components, simplifying integration into RF front-end designs.<br><br>Designed primarily as a prescaler for phase-locked loop (PLL) systems, it is widely used in applications such as wireless infrastructure, point-to-point radios, VSAT systems, fiber optics, and test & measurement equipment.<br><br>With its wide frequency range, low phase noise, and robust RF performance, the HMC438MS8GETR is an ideal solution for engineers developing high-frequency communication systems requiring precise frequency division and signal conditioning.
HMC438MS8GETR

Description: The HMC438MS8GETR is a high-performance RF frequency divider (prescaler) developed by Anal ...
Package: T&R | MOQ: 500 | MPQ: 500

ADF4001BRUZ / The ADDF4001BRUZ is a high-performance integer-N phase-locked loop (PLL) frequency synthesizer from Analog Devices, designed for RF and clock generation applications requiring precise frequency control. It integrates a low-noise digital phase detector, programmable reference divider, and dual-modulus prescaler, enabling flexible frequency synthesis for communication systems.<br><br>The device supports input frequencies up to 200 MHz, making it suitable for high-speed clock generation and RF applications. It operates over a supply voltage range of 2.7V to 5.5V, providing compatibility with a wide range of digital and mixed-signal systems.<br><br>The ADF4001 features a serial interface (SPI-compatible), allowing easy programming and integration with microcontrollers, DSPs, and FPGA-based systems. Its architecture supports programmable division ratios, enabling accurate generation of output frequencies based on a reference clock source.<br><br>Designed for low phase noise and high stability, the device is widely used in RF communication systems, wireless infrastructure, instrumentation, and clock synchronization applications. It can be combined with external VCOs (voltage-controlled oscillators) to create complete frequency synthesis solutions.<br><br>Packaged in a compact TSSOP-16 surface-mount form factor and operating over an industrial temperature range of -40°C to +85°C, the ADDF4001BRUZ is well-suited for demanding environments requiring reliable timing and frequency control.
ADF4001BRUZ

Description: The ADDF4001BRUZ is a high-performance integer-N phase-locked loop (PLL) frequency synthes ...
Package: TUBE | MOQ: 96 | MPQ: 96

AD5791BRUZ / The AD5791BRUZ is an ultra-high precision 20-bit digital-to-analog converter (DAC) from Analog Devices, designed for applications requiring exceptional accuracy, stability, and resolution. It provides a single-channel, unbuffered voltage output with true 20-bit resolution, making it ideal for high-end instrumentation and scientific systems.<br><br>The device operates from a wide bipolar supply range (up to ±16.5V, 33V total), allowing flexible output configurations including bipolar signal generation. It achieves outstanding performance with ±1 LSB integral nonlinearity (INL) and guaranteed monotonic behavior, ensuring highly accurate analog signal conversion.<br><br>Featuring a high-speed SPI-compatible serial interface (up to 35 MHz), the AD5791BRUZ enables fast communication with microcontrollers, DSPs, and FPGA systems. It offers a typical settling time of around 1 µs, ultra-low noise (~7.5 nV/√Hz), and extremely low temperature drift (~0.05 ppm/°C), making it suitable for precision-critical environments.<br><br>The DAC includes advanced features such as power-on reset, output clamp control, and external reference inputs for flexible system design. Its architecture ensures minimal glitch energy and excellent long-term stability, reducing calibration requirements in high-precision systems.<br><br>Housed in a compact TSSOP-20 surface-mount package, the AD5791BRUZ is widely used in applications such as test and measurement equipment, medical instrumentation, industrial automation, aerospace systems, and high-precision data acquisition where ultra-high resolution and accuracy are essential.
AD5791BRUZ

Description: The AD5791BRUZ is an ultra-high precision 20-bit digital-to-analog converter (DAC) from An ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AD5781BRUZ / The AD5781BRUZ is an ultra-high precision 18-bit digital-to-analog converter (DAC) developed by Analog Devices, designed for demanding industrial, instrumentation, and scientific applications requiring exceptional accuracy and stability. It features a single-channel, unbuffered voltage output architecture with true 18-bit resolution and excellent linearity performance.<br><br>The device operates from a wide bipolar supply range (up to ±16.5V), enabling high dynamic range and flexible output configurations. It uses an R-2R ladder architecture and delivers outstanding performance with ±0.5 LSB integral nonlinearity (INL) and guaranteed monotonic behavior, ensuring highly accurate analog signal generation.<br><br>The AD5781BRUZ supports a high-speed SPI-compatible serial interface (up to 35 MHz), allowing seamless integration with microcontrollers, DSPs, and FPGA systems. It also features fast settling time (~1 µs), low noise (~7.5 nV/√Hz), and extremely low temperature drift (~0.05 ppm/°C), making it ideal for precision measurement systems.<br><br>Additional features include power-on reset, output clamp functionality, and compatibility with a wide range of external reference voltages, enabling flexible system design. The device operates over an extended industrial temperature range of -40°C to +125°C, ensuring reliability in harsh environments.<br><br>Housed in a compact TSSOP-20 surface-mount package, the AD5781BRUZ is widely used in applications such as test and measurement equipment, medical instrumentation, industrial automation, aerospace systems, data acquisition, and precision calibration systems where ultra-high resolution and accuracy are critical.
AD5781BRUZ

Description: The AD5781BRUZ is an ultra-high precision 18-bit digital-to-analog converter (DAC) develop ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AD5725BRSZ-REEL / The AD5725BRSZ-REEL is a high-performance quad-channel 12-bit digital-to-analog converter (DAC) developed by Analog Devices, designed for precision analog output generation in industrial and instrumentation applications. It features four independent DAC channels with buffered voltage outputs, enabling simultaneous multi-channel signal control.<br><br>The device operates over a wide supply range from +5V to ±15V, supporting both unipolar and bipolar output configurations via external reference inputs. This flexibility allows designers to configure output ranges according to system requirements without relying on additional offset circuitry.<br><br>Built on an R-2R architecture, the AD5725 provides excellent linearity (±0.5 LSB INL) and guaranteed monotonic performance, ensuring accurate and stable analog signal generation. It features a parallel interface, allowing fast data transfer and simultaneous updates across all channels via the LDAC pin.<br><br>With a typical settling time of 10 µs, the device is suitable for time-sensitive applications such as control loops and signal generation. It also includes features such as double-buffered inputs, asynchronous clear (to zero or mid-scale), and readback functionality for enhanced system control.<br><br>Packaged in a 28-pin SSOP surface-mount format and supplied in tape-and-reel configuration, the AD5725BRSZ-REEL is ideal for automated manufacturing environments. It is widely used in applications such as industrial automation, process control systems, programmable logic controllers (PLCs), and test & measurement equipment where multi-channel precision DAC performance is required.
AD5725BRSZ-REEL

Description: The AD5725BRSZ-REEL is a high-performance quad-channel 12-bit digital-to-analog converter ...
Package: T&R | MOQ: 1500 | MPQ: 1500

AD5676BRUZ / The AD5676BRUZ is a high-precision, multi-channel 16-bit digital-to-analog converter (DAC) from Analog Devices, designed for applications requiring accurate and simultaneous analog output generation. It features 8 independent DAC channels, making it ideal for multi-channel control and data acquisition systems.<br><br>The device operates from a supply voltage range of 2.7V to 5.5V and provides buffered voltage outputs with rail-to-rail capability. It uses a string DAC architecture, ensuring excellent linearity with ±3 LSB integral nonlinearity (INL) for high-accuracy applications.<br><br>The AD5676BRUZ supports a high-speed SPI-compatible serial interface, requiring a 24-bit data word for communication, allowing easy integration with microcontrollers, DSPs, and FPGA systems. It also features simultaneous update capability via the LDAC pin, enabling synchronized output changes across all channels.<br><br>Additional features include power-on reset, multiple power-down modes for reduced power consumption, and programmable gain (×1 / ×2) for flexible output scaling. The device operates over an extended temperature range of -40°C to +125°C, making it suitable for industrial environments.<br><br>Housed in a compact TSSOP-20 surface-mount package, the AD5676BRUZ is widely used in applications such as industrial automation, data acquisition systems, programmable voltage sources, instrumentation, and multi-channel control systems where precision, reliability, and multi-output capability are essential.
AD5676BRUZ

Description: The AD5676BRUZ is a high-precision, multi-channel 16-bit digital-to-analog converter (DAC) ...
Package: T&R | MOQ: 1000 | MPQ: 1000

AD5546BRUZ / The AD5546BRUZ is a precision 16-bit digital-to-analog converter (DAC) from Analog Devices, designed for high-accuracy signal generation in industrial and instrumentation applications. It features a current-output architecture based on an R-2R ladder, delivering excellent linearity and low noise performance.<br><br>This device operates from a single supply voltage range of 2.7V to 5.5V and supports a high-speed parallel interface, enabling fast data updates and integration with microcontrollers, DSPs, and FPGA-based systems. The DAC provides a typical settling time of approximately 500 ns, making it suitable for high-speed applications.<br><br>The AD5546BRUZ includes an integrated feedback resistor (RFB), simplifying current-to-voltage conversion when used with an external operational amplifier. Its multiplying DAC capability allows flexible output ranges, including unipolar and bipolar configurations (e.g., ±10V output when properly configured).<br><br>With ±1 LSB DNL and ±2 LSB INL performance, the device ensures high precision and stability across its operating temperature range of -40°C to +125°C.<br><br>Housed in a compact TSSOP-28 surface-mount package, the AD5546BRUZ is widely used in applications such as automatic test equipment (ATE), industrial automation, programmable gain control, waveform generation, and precision instrumentation where accurate and fast analog output is required.
AD5546BRUZ

Description: The AD5546BRUZ is a precision 16-bit digital-to-analog converter (DAC) from Analog Devices ...
Package: TUBE | MOQ: 50 | MPQ: 50

AD5543BRMZ-REEL7 / The AD5543BRMZ-REEL7 is a precision 16-bit digital-to-analog converter (DAC) from Analog Devices, designed for high-accuracy and low-power signal conversion in industrial and instrumentation applications. It features a current-output architecture based on an R-2R ladder, delivering excellent linearity and resolution for precise analog signal generation.<br><br>This device operates from a single 5V supply and uses an external reference voltage, allowing flexible scaling of the output current. It provides a full-scale output current of approximately 2 mA and includes an integrated feedback resistor (RFB), enabling easy conversion to a voltage output when used with an external operational amplifier.<br><br>The AD5543 supports a high-speed 3-wire serial interface (SPI-compatible), making it easy to interface with microcontrollers, DSPs, and FPGA systems. It offers fast settling time of around 500 ns and low power consumption (~10 µA typical), making it suitable for both high-speed and low-power designs.<br><br>With its compact MSOP-8 package and robust performance over an operating temperature range of -40°C to +85°C, the AD5543BRMZ-REEL7 is ideal for space-constrained and industrial environments.<br><br>Typical applications include automatic test equipment (ATE), precision instrumentation, programmable gain and calibration systems, industrial control, and data acquisition systems where accurate and stable analog output is required.
AD5543BRMZ-REEL7

Description: The AD5543BRMZ-REEL7 is a precision 16-bit digital-to-analog converter (DAC) from Analog D ...
Package: t&r | MOQ: 1000 | MPQ: 1000

AD5061BRJZ-2500RL7 / The AD5061BRJZ-2500RL7 is a high-precision, low-power 16-bit digital-to-analog converter (DAC) from Analog Devices, part of the nanoDAC® family. It features a single-channel buffered voltage output and operates over a wide supply range of 2.7V to 5.5V, making it ideal for both portable and industrial applications.<br><br>This device utilizes an R-2R ladder architecture and provides excellent linearity with ±0.5 LSB INL/DNL, ensuring accurate digital-to-analog signal conversion. It supports a high-speed 3-wire serial interface compatible with SPI, QSPI, MICROWIRE, and DSP standards, allowing seamless integration into embedded systems.<br><br>The AD5061BRJZ-2500RL7 includes advanced features such as power-on reset (to mid-scale or zero-scale), low glitch energy, and a fast settling time of approximately 4 µs. It also supports multiple power-down modes, reducing current consumption to very low levels for energy-efficient designs.<br><br>Housed in a compact SOT-23-8 package, this DAC is optimized for space-constrained PCB designs. It is widely used in applications such as process control, data acquisition systems, programmable voltage sources, industrial automation, and precision instrumentation where accurate analog output is required.
AD5061BRJZ-2500RL7

Description: The AD5061BRJZ-2500RL7 is a high-precision, low-power 16-bit digital-to-analog converter ( ...
Package: T&R | MOQ: 500 | MPQ: 500

AD5061BRJZ-1500RL7 / The AD5061BRJZ-1500RL7 is a high-precision <strong>16-bit NanoDAC® digital-to-analog converter (DAC)</strong> from <strong>Analog Devices</strong>, designed for applications that require accurate voltage generation, low power consumption, and compact PCB implementation. Its combination of precision performance and small package size makes it suitable for industrial, instrumentation, communication, and embedded control systems. <br><br>This device features a <strong>16-bit resolution</strong> and provides a buffered voltage output capable of delivering highly accurate analog signals from digital input data. The integrated precision architecture enables excellent linearity and stable output performance across a wide operating range. <br><br>The AD5061BRJZ-1500RL7 communicates through a <strong>3-wire SPI-compatible serial interface</strong>, allowing simple integration with microcontrollers, DSPs, FPGAs, and embedded processing platforms. Its serial interface minimizes pin count while maintaining fast and reliable digital control. <br><br>The converter operates from a <strong>2.7V to 5.5V single supply voltage</strong> and incorporates an internal precision reference architecture optimized for low-power operation. This enables efficient implementation in battery-powered and energy-sensitive applications. <br><br>Designed for precision signal generation, the device offers <strong>low offset error, excellent differential nonlinearity (DNL), low glitch energy, and low noise performance</strong>, making it suitable for calibration systems, programmable voltage sources, process control equipment, and measurement instruments. <br><br>The component is supplied in a compact <strong>6-pin SOT-23 surface-mount package</strong>, providing significant board-space savings while maintaining high-performance analog characteristics. <br><br>The <strong>AD5061BRJZ-1500RL7</strong> is widely used in <strong>industrial automation, data acquisition systems, instrumentation, programmable power supplies, process control equipment, communication systems, portable test equipment, and embedded analog output applications</strong>, where accurate digital-to-analog conversion and low power consumption are essential.
AD5061BRJZ-1500RL7

Description: The AD5061BRJZ-1500RL7 is a high-precision 16-bit NanoDAC® digital-to-analog conv ...
Package: T&R | MOQ: 3000 | MPQ: 500

PCM5102PWR / The PCM5102PWR is a high-performance stereo digital-to-analog converter (DAC) developed by Texas Instruments, designed for premium audio applications requiring high fidelity and low noise. It supports high-resolution audio up to 32-bit / 384 kHz, delivering exceptional sound quality for modern digital audio systems.<br><br>The device accepts standard I2S, left-justified, and right-justified digital audio formats, allowing seamless integration with microcontrollers, DSPs, and processors such as Raspberry Pi, ESP32, and other embedded platforms. It features an integrated line driver, enabling direct connection to audio outputs without the need for external op-amps.<br><br>The PCM5102PWR incorporates advanced architecture including integrated PLL (Phase-Locked Loop), which eliminates the need for an external system clock (MCLK), simplifying system design. It also features low out-of-band noise and high signal-to-noise ratio (SNR ≈ 112 dB), ensuring clean and accurate audio reproduction.<br><br>Operating from a 3.3V supply, the device offers excellent power efficiency and low power consumption, making it suitable for both portable and fixed audio applications. It also includes built-in mute and de-emphasis functions for improved audio performance.<br><br>Packaged in a compact TSSOP-20 form factor, the PCM5102PWR is widely used in applications such as Hi-Fi audio systems, digital media players, USB DACs, embedded audio solutions, smart speakers, and IoT audio devices where high-quality digital-to-analog conversion is required.
PCM5102PWR

Description: The PCM5102PWR is a high-performance stereo digital-to-analog converter (DAC) developed by ...
Package: T&R | MOQ: 2000 | MPQ: 2000

MAX98357AETE+T / The MAX98357AETE+T is a compact digital Class-D audio amplifier with an integrated DAC, developed by Analog Devices (formerly Maxim Integrated), designed for direct I2S audio input applications. It simplifies audio system design by eliminating the need for a separate digital-to-analog converter and analog amplification stages.<br><br>The device accepts standard I2S digital audio signals and converts them internally to drive a speaker directly, delivering up to 3.2W output power into a 4Ω load. Its filterless Class-D architecture enables high efficiency (typically >90%), reducing heat dissipation and minimizing external component requirements.<br><br>Operating within a supply voltage range of 2.5V to 5.5V, the MAX98357A is ideal for portable and embedded systems such as IoT devices, smart speakers, and development boards like ESP32 and Raspberry Pi. It features automatic sample rate detection, configurable left/right channel selection, and built-in digital volume control.<br><br>The device also integrates protection features including thermal shutdown and short-circuit protection, ensuring reliable performance in various operating conditions. Its low electromagnetic interference (EMI) design simplifies PCB layout and compliance with regulatory standards.<br><br>Housed in a small TQFN-16 package, the MAX98357AETE+T is widely used in applications such as smart home devices, voice-enabled systems, portable speakers, embedded audio solutions, and digital media players where compact size and digital audio integration are essential.
MAX98357AETE+T

Description: The MAX98357AETE+T is a compact digital Class-D audio amplifier with an integrated DAC, de ...
Package: T&R | MOQ: 3000 | MPQ: 3000













info@signalhk.com

+852 2417 2366

Room 1304, 13/F, Allways Centre, 468 Jaffe Road, Causeway Bay, Hong Kong.


SIGNAL-HK WIKI BLOG

Copyright © 2008-2024 Signal HK Limited. All Rights Reserved.Designated trademarks and brands are the property of their respective owners.
Use of this Website constitutes acceptance of Signal HK Limited Terms of Use and Privacy Policy

Cookie Policy | MSN EQV Parts |
