All Products Isolated Amplifier

AD8418AWBRMZ-RL / The AD8418AWBRMZ-RL is a high-precision, bidirectional current sense amplifier designed for automotive and industrial applications. It features a fixed gain of 20 V/V, ultra-low input offset voltage (±200 µV max), minimal drift (~0.1 µV/°C), and a wide operating common-mode voltage range from –2 V to +70 V. With excellent common-mode rejection (up to 100 dB) and integrated EMI filtering, it delivers accurate current measurements even in noisy, high-voltage environments. The device supports single-supply operation (2.7 V–5.5 V), offers both unidirectional and bidirectional sensing via dual VREF pins, and is AEC-Q100 qualified for automotive use. Packaged in a compact 8-lead MSOP and supplied on tape and reel, the AD8418AWBRMZ-RL is ideal for motor control, battery management, and power system diagnostics.
AD8418AWBRMZ-RL

Description: The AD8418AWBRMZ-RL is a high-precision, bidirectional current sense amplifier designed fo ...
Package: T&R | MOQ: 3000 | MPQ: 3000

ADUM1200BRZ-RL7 / The ADUM1200BRZ-RL7 is a dual-channel digital isolator from Analog Devices, utilizing iCoupler® technology to provide reliable isolation in electronic systems. It offers a high isolation voltage of 2500 Vrms, ensuring robust protection against voltage transients. With a data rate of up to 10 Mbps and low propagation delays of 50 ns, it ensures fast and accurate signal transmission. The device operates over a supply voltage range of 2.7V to 5.5V and a temperature range of -40°C to 105°C, making it suitable for various industrial applications. Packaged in an 8-pin SOIC, the ADUM1200BRZ-RL7 is ideal for applications requiring compact size and reliable performance.
ADUM1200BRZ-RL7

Description: The ADUM1200BRZ-RL7 is a dual-channel digital isolator from Analog Devices, utilizing iCou ...
Package: T&R | MOQ: 1000 | MPQ: 1000

ISO7220ADR / General Purpose Digital Isolator 2500Vrms 2 Channel 1Mbps 25kV/µs CMTI 8-SOIC (0.154
ISO7220ADR

Description: General Purpose Digital Isolator 2500Vrms 2 Channel 1Mbps 25kV/µs CMTI 8-SOIC (0.154", 3. ...
Package: T&R | MOQ: 2500 | MPQ: 2500

ISO124U / Isolation Amplifier 1 Circuit 28-SOIC(8 Leads)
ISO124U

Description: Isolation Amplifier 1 Circuit 28-SOIC(8 Leads) ...
Package: TUBE | MOQ: 1000 | MPQ: 20

HCPL-7840-000E / Isolation Amplifier 1 Circuit Differential 8-DIP, 500 nA, 300 µV, 100KHz
HCPL-7840-000E

Description: Isolation Amplifier 1 Circuit Differential 8-DIP, 500 nA, 300 µV, 100KHz ...
Package: TUBE | MOQ: 1000 | MPQ: 50

ISO7221ADR / The ISO7221ADR is a dual-channel digital isolator based on capacitive isolation technology, designed to provide high-speed signal isolation with one forward and one reverse channel configuration. It supports data rates up to 25 Mbps and operates over a supply voltage range of 2.8V to 5.5V on both sides of the isolation barrier. The device provides isolation voltage up to 2500 Vrms and offers high common-mode transient immunity exceeding 25 kV/µs, ensuring reliable operation in noisy industrial environments. It features low propagation delay of approximately 10 ns and low pulse width distortion, enabling accurate high-speed data transmission. The IC consumes low power with typical supply current around 1.5–2 mA per channel and includes fail-safe default output functionality. Operating temperature range is -40°C to +125°C, and the SOIC-8 package enables compact PCB integration, making it suitable for SPI, UART, CAN interface isolation, industrial automation, and data acquisition systems.
ISO7221ADR

Description: The ISO7221ADR is a dual-channel digital isolator based on capacitive isolation technology ...
Package: T&R | MOQ: 2500 | MPQ: 2500

ADUM3160BRWZ / The ADUM3160BRWZ is a USB digital isolator based on iCoupler® technology, designed to provide galvanic isolation for full-speed (12 Mbps) and low-speed (1.5 Mbps) USB communication. It operates with separate supply voltages on each side ranging from 3.0V to 5.5V, enabling flexible system integration. The device provides isolation voltage up to 2500 Vrms and high common-mode transient immunity exceeding 25 kV/µs, ensuring reliable operation in noisy environments. It features automatic speed detection, upstream/downstream isolation, and supports bidirectional USB signaling with low propagation delay. Typical supply current is approximately 8–15 mA depending on data rate. The IC includes internal edge encoding/decoding and does not require external clocking. Operating temperature range is -40°C to +105°C, and the wide-body SOIC-16 package provides reinforced insulation, making it suitable for medical equipment, industrial USB interfaces, and isolated data acquisition systems.
ADUM3160BRWZ

Description: The ADUM3160BRWZ is a USB digital isolator based on iCoupler® technology, designed to pro ...
Package: TUBE | MOQ: 564 | MPQ: 47

AMC1200BDWVR / The AMC1200BDWVR is a precision isolation amplifier designed for current sensing and voltage measurement in high-voltage environments, featuring galvanic isolation up to 4250 Vpeak. It operates with a differential input voltage range of ±250 mV optimized for shunt resistor applications and provides a fixed gain of 8 with ±0.5% accuracy. The device supports a bandwidth of approximately 100 kHz and offers high common-mode rejection ratio of about 108 dB, ensuring accurate signal transmission in noisy environments. It operates with supply voltages of 2.7V to 5.5V and consumes typical supply current around 5.4 mA. The amplifier features low offset voltage (~200 µV), low nonlinearity (0.075% max), and high transient immunity of at least 10 kV/µs. Operating temperature range is -40°C to +105°C, and the wide-body SOIC-8 package ensures reinforced isolation spacing, making it suitable for motor control, power inverters, and industrial current sensing applications.
AMC1200BDWVR

Description: The AMC1200BDWVR is a precision isolation amplifier designed for current sensing and volta ...
Package: T&R | MOQ: 1000 | MPQ: 1000

ADUM1201ARZ / The ADUM1201ARZ is a dual-channel digital isolator based on iCoupler® technology, providing galvanic isolation up to 2500 Vrms between input and output. It supports data rates up to 25 Mbps and operates over a supply voltage range of 2.7V to 5.5V on both sides, enabling flexible interfacing. The device features low propagation delay of approximately 45 ns, low pulse width distortion (<5 ns), and high common-mode transient immunity exceeding 25 kV/µs. Typical supply current is around 1.5 mA per channel at 1 Mbps. It includes two independent channels with configurable direction (1 forward, 1 reverse), and operates over a temperature range of -40°C to +105°C. The SOIC-8 package ensures compact integration, making it suitable for industrial communication, SPI/I2C isolation, and data interface protection applications.
ADUM1201ARZ

Description: The ADUM1201ARZ is a dual-channel digital isolator based on iCoupler® technology, providi ...
Package: T&R | MOQ: 1000 | MPQ: 1000

ACPL-C87B-000E / The ACPL-C87B-000E is a precision optically isolated voltage sensor and isolation amplifier designed for accurate voltage measurement in high-noise environments. It operates over a supply voltage range of 3V to 5.5V and features a differential output with a bandwidth of approximately 100 kHz. The device supports an input voltage range of 0 to 2V with very high input impedance (~1 GΩ), enabling precise scaled voltage sensing. It offers high gain accuracy of ±0.5%, low non-linearity (0.1% max), and low input offset voltage (~300 µV typical), with input bias current around 1.5 nA . The isolation rating reaches up to 5000 Vrms with common-mode transient immunity of 15 kV/µs, ensuring robust performance in industrial environments . Typical supply current is about 10.5 mA, and the device operates over a temperature range of -40°C to +105°C . Packaged in a stretched SOIC-8 form factor, it is widely used in motor drives, renewable energy systems, and isolated data acquisition applications.
ACPL-C87B-000E

Description: The ACPL-C87B-000E is a precision optically isolated voltage sensor and isolation amplifie ...
Package: TUBE | MOQ: 320 | MPQ: 80
