All Products LCD Driver

XPT2046 / The XPT2046 is a 4-wire resistive touch screen controller that incorporates a 12-bit 125 kHz sampling SAR type A/D converter. The XPT2046 operates down to 2.2V supply voltage and supports digital I/O interface voltage from 1.5V to VCC in order to connect low voltage uP. The XPT2046 can detect the pressed screen location by performing two A/D conversions. In addition to location, the XPT2046 also measures touch screen pressure.On-chip VREF can be utilized for analog auxiliary input, temperature measurement and battery monitoring withthe ability to measure voltage from 0V to 5V. The XPT2046 also has an on-chip temperature sensor The XPT2046 is available in 16pin QFN thin package(0.75mm in height) and has the operating temperature range of -40°C to +85°C
XPT2046

Description: The XPT2046 is a 4-wire resistive touch screen controller that incorporates a 12-bit 125 k ...
Package: T&R | MOQ: 1000 | MPQ: 1000

HT1621B / Built-in 256kHz RC oscillator, External 32.768kHz crystal or 256kHz frequency source input, Selection of 1/2 or 1/3 bias, and selection of 1/2 or 1/3 or 1/4 duty LCD applications, Internal time base frequency sources, Two selectable buzzer frequencies (2kHz/4kHz), Power down command reduces power consumption, Built-in time base generator and WDT, Time base or WDT overflow output, 8 kinds of time base/WDT clock sources, 32x4 LCD driver, Built-in 32x4 bit display RAM, 3-wire serial interface, Internal LCD driving frequency source, Software configuration feature, Data mode and command mode instructions, R/W address auto increment, Three data accessing modes, VLCD pin for adjusting LCD operating voltage, HT1621B 44-pin LQFP package
HT1621B

Description: Built-in 256kHz RC oscillator, External 32.768kHz crystal or 256kHz frequency source input ...
Package: TUBE | MOQ: 2010 | MPQ: 30

AMT630A / AMT630A is a CVBS to 24Bit LCD Panel Driver IC for Intercom Systems, Car Cam Display, CCTV Monitor, etc... Composite video signal(CVBS) input, Multiple standards supported: NTSC and NTSC-Japan, PAL (B, D, G, H, I, M, N, etc.), SECAM, Three analog inputs: 3xCVBS, Digital AGC,ACC, 9-Bit 1-Channel A/D converters with fixed sampling clock, Only one crystal (27 MHz) required for all standards, Video noise reduction.
AMT630A

Description: AMT630A is a CVBS to 24Bit LCD Panel Driver IC for Intercom Systems, Car Cam Display, CCTV ...
Package: T&R | MOQ: 2500 | MPQ: 2500

PCF85176H/1,518 / The PCF85176 is a peripheral device which interfaces to almost any Liquid Crystal Display (LCD)1 with low multiplex rates. It generates the drive signals for any static or multiplexed LCD containing up to four backplanes and up to 40 segments.
PCF85176H/1,518

Description: The PCF85176 is a peripheral device which interfaces to almost any Liquid Crystal Display ...
Package: T&R | MOQ: 1500 | MPQ: 1500
