ADIS16507-2BMLZ
The image is for illustrative purposes only; please refer to the product data sheet for precise specifications.
GET QUOTE NOW!
| Part Number | ADIS16507-2BMLZ |
|---|---|
| Manufacturer |
 Analog Devices
|
| Description | The ADIS16507-2BMLZ is a precision 6 degrees of freedom MEMS inertial measurement unit (IMU) from Analog Devices, integrating a triaxial gyroscope and a triaxial accelerometer in a compact industrial-grade sensor module. It is designed for accurate motion sensing, stabilization, navigation, robotics, and platform control applications. This device provides a gyroscope measurement range of ±500°/s and an accelerometer measurement range of ±40g, making it suitable for dynamic systems that require reliable angular rate and acceleration data. The ADIS16507-2BMLZ includes factory calibration for key parameters such as sensitivity, bias, alignment, linear acceleration effects, and point of percussion, helping reduce system-level calibration effort and improving measurement consistency across operating conditions. Communication is handled through a SPI digital interface, allowing straightforward integration with microcontrollers, DSPs, FPGAs, and embedded processing platforms. Its register-based architecture supports efficient data collection, configuration, and diagnostics. The module operates across an extended temperature range of -40°C to +105°C, supporting demanding industrial and embedded environments. It is supplied in a 100-BGA surface-mount module with an approximate body size of 15mm × 15mm. The ADIS16507-2BMLZ is commonly used in navigation systems, autonomous equipment, robotics, UAVs, platform stabilization, vibration monitoring, motion control, and industrial instrumentation, where compact size and precision inertial sensing are required. |
| Product Group | Accelerometer |
| MOQ | 2 pcs |
| SPQ | 84 pcs |
| Figure/Case | 100-BGA Module |
| Package | TRAY Pack |
 PDF Datasheet | |
| Ship From | Hong Kong |
| Shipment Way | DHL / Fedex / TNT / UPS / Others |
| Delivery Term | Ex-Works |
| Send RFQ | sales@signalhk.com |
